INSTALLER / CONSUMER
SAFETY INFORMATION
Please read this manual
before installing and using
the heater.
WARNING:
If the information in
this manual is not followed
exactly, a fire or explosion may
result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other
•
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
•
do not use any phone in your
building.
Immediately call your gas supplier
•
from a neighbour's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas
•
supplier, call the fire department.
Installation and service must be
•
performed by a qualified installer,
service agency or the gas supplier.
Installer: Leave this manual
with the heater.
Consumer: Retain this
manual for future reference.
This is an unvented gas-fired
heater. It uses air (oxygen) from
the room in which it is installed.
Provisions for adequate
combustion and ventilation air
must be provided. Refer to the
Installation section on page 3.
User's Operation and Installation Manual
Unvented
Gas-Fired Room Heater
Models: RMC-LC10NG,
RMC-LC20NG(F),
RMC-LC30NG(F),
RMC-LC10NG(T),
RMC-LC20NG(T),(F), RMC-LC20LP(T),(F) - 20,000 Btu/hr
RMC-LC30NG(T),(F), RMC-LC30LP(T),(F) - 30,000 Btu/hr
(F)=Fan, (T)=Thermostat Gas Control
Models: RMC-LI10NG,
RMC-LI18NG(F),
RMC-LI30NG(F),
RMC-LI06NG,
RMC-LI10NG (T) ,
RMC-LI18NG (T),(F) ,
RMC-LI30NG (T),(F) ,
(F)=Fan, (T)=Thermostat Gas Control
Blue Flame Heaters
RMC-LC10LP
RMC-LC20LP(F)
RMC-LC30LP(F)
RMC-LC10LP(T)
Infra-Red Heaters
RMC-LI10LP
RMC-LI18LP(F)
RMC-LI30LP(F)
RMC-LI06LP
RMC-LI10LP (T)
RMC-LI18LP (T),(F) - 18,000 Btu/hr
RMC-LI30LP (T),(F) - 30,000 Btu/hr
- 10,000 Btu/hr.
- 20,000 Btu/hr
- 30,000 Btu/hr
- 10,000 Btu/hr.
- 10,000 Btu/hr
- 18,000 Btu/hr
- 30,000 Btu/hr
- 6,000 Btu/hr.
- 10,000 Btu/hr
07/05 Rev 3.
