- Page 1 Fixed Frame screen...
-
Page 2: Table Of Contents
Contents To the Owner …………………………………1 General Notes …………………………………2 Contents in the Box …………………………………3 Prepare works before installation …………………………………4 Frame assembly …………………………………5 Attaching Screen Surface to Frame …………………………………7 Mounting the Screen …………………………………11 Screen Care …………………………………13 Warranty …………………………………13... -
Page 3: To The Owner
To the owner Thank you for choosing a Hivilux fixed frame screen for your home. This deluxe model delivers superior performance for video. Please take a moment to review this manual; it will help ensure you easy and quick installation. Some important notes will help you understand... -
Page 4: General Notes
General Notes 1.P lease read the user manual carefully, this will help you finish installation quickly. 2. Please make sure that no other objects such as power switches, outlets, furniture, ladders, windows,etc. occupy the space designated to hang the screen. 3. -
Page 5: Contents In The Box
Contents in the Box Open the box, you will find the following parts, Please make sure all parts listed below are included before proceeding with the installation. Quantity Name Picture Frame Screenfabric Glassfiberstick Accessoriesbox Installationinstructions Fixed Frame screen... -
Page 6: Prepare Works Before Installation
Prepare works before installation Tools needed Work area Protectedareas Operatingareas Protective clothing ☞ △... -
Page 7: Frame Assembly
Frame assembly Frames Screen Material Paper Corner Accessories box 2)Insert 2pcs center joint connectors to the channels 1） O pen up the box, take out all the parts inside. of horizontal frame piece (don’t tighten the screws at this time. 3）... - Page 8 Note: Once all eight corner braces and frame rails are in place you want to check each corner to make sure the corners are aligned properly. There should be an even point at each corner where the frame rails jointogether. You will have a 1mm gap at the miter cuts in the back where the frame rails join together.
-
Page 9: Attaching Screen Surface To Frame
Attaching Screen Surface to Frame Protective clothing 1 )Take out the screen fabric from roller and unroll the material on clean area. Tension Rod(Horizontal)X4 Tension Rod(Vertical)X2 2) Insert the screen tension rods through the sleeves according to their corresponding lengths on each edge of the screen as seen below. - Page 10 Note: 1. making sure the red alignment marks are properly matched. 2 .The silver fix plate clicked into place to show that it fixed well during the installation, if needing to adjust the silver fix plate or take out it, please refer to the following way.
- Page 11 If you choose the screen with spring structure , please follow the steps below to install. 1) Place the screen material on the back of the built frame and slip the tension rods into the grooves running along each side on the back of the frame on all four corner and pull the fixed frame spring to buckle and pull the tension rods and screen surface to finish the assembling of the screen.
- Page 12 Note: 1. making sure the red alignment marks are properly matched. 2 .During installation, if you need to adjust or dismantle the fixed screen spring, please follow the bellowed procedures and use the special drag hook to do it.
-
Page 13: Mounting The Screen
Mounting the Screen Center Support Bar Screen over 135” in size include a support bar. Insert the Center Support Bar into the upper top groove on the back of the frame (not the one where the fix plate inserts) with the bottom end near the approximate center point of the frame and place it in at an angle so that both ends of the bar are in alignment with the groove. - Page 14 Mounting the Screen 1. Locate your desired installation location with a stud finder (recommen ded) and mark the drill-hole area of where the screen is to be installed. 2. Drill a hole with the proper bit size according to the wood screws included. 3.
-
Page 15: Screen Care
Screen Care The surface of your screen is delicate. Special attention to these instructions should be followed when cleaning. 1. A draftsman-style brush may be used to lightly whisk away any loose dirt or dust particles. 2 .For tougher spots, use a solution of mild detergent and water. Rub lightly using a sponge. - Page 16 WWW.HIVILUX.DE...
