- Page 1 S T I G A P A R K S I LE N T GEBRUIKSAANWIJZING NL ... 6 INSTRUCTIONS FOR USE EN . 20 MODE D’EMPLOI FR...33 8211-0072-80...
- Page 2 Unlimited, President Ranger, Comfort E (Prestige) B, C...
-
Page 6: Safety Instructions
1 GENERAL This symbol indicates WARNING. Seri- ous personal injury and/or damage to property may result if the instructions are not followed carefully. You must read these instructions for use and the accompanying pamphlet “SAFETY INSTRUCTIONS” careful- ly, before starting up the machine. 1.1 SYMBOLS The following symbols appear on the machine. - Page 7 a. Always store petrol in containers that are made especially for this purpose. b. Only fill or top up with petrol outdoors, and never smoke when filling or topping up. c. Fill with petrol before starting the motor. Never remove the filler cap or fill with petrol while the engine is running or still warm.
-
Page 8: Maintenance And Storage
b. Putting the gear in neutral and activating the parking brake. c. Stopping the engine and removing the key. • Only use accessories that are approved by the machine’s manufacturer. • The machine may not be used without accessories/tools being installed in the machine’s tool mounts. -
Page 9: Product Identity
For consumer use: two years from purchase date. For professional use: 300 hours or three months, whichever comes first. For Stiga Park and Stiga Villa, it is possible to have a one year extension to the guarantee if the condi- tions in the service book are satisfied. - Page 10 Use these identification terms during all contact with service workshops and when purchasing spare parts. As soon as possible after acquiring the machine, the above number should be written in on the last page of this publication. 7 ENVIRONMENT For environmental reasons, we recommend that particular attention is given to the following points: •...
-
Page 11: Steering Wheel
10.2Engine casing (2:U) In order to access the fuel cock, battery and engine, the machine has an engine casing that can be opened. The engine cas- ing is locked with a rubber strap. The engine casing is opened as follows: 1. -
Page 12: Safety System
11.3 Safety system The machine is equipped with an electrical safety system. The safety system interrupts certain activ- ities that can entail a danger of incorrect manoeu- vres. For example, the engine cannot be started if the clutch-parking brake pedal is depressed. The operation of the safety system must always be checked every time before use. -
Page 13: Areas Of Use
Risk of burns and crushing in- juries. 12 AREAS OF USE The machine may only be used for the following tasks using the genuine STIGA accessories stated. Work Accessories, STIGA genuine Mowing Using mowing decks:... -
Page 14: Starting And Operation
NOTE! Before using a trailer – contact your insur- ance company. NOTE! This machine is not intended to be driven on public roads. 13 STARTING AND OPERATION The machine may not be operated un- less the engine casing is closed and locked. -
Page 15: Maintenance
14.1Service programme In order to keep the machine in good condition as regards reliability and operational safety as well as from an environmental perspective, STIGA’s Ser- vice programme should be followed. The contents of this programme can be found in the attached service log. -
Page 16: Fuel Filter
Front: 0.6 bar (9 psi). Rear: 0.4 bar (6 psi). 14.4 Changing engine oil This section contains tables covering the different engines that are included in STIGA’s range. To fa- cilitate reading, mark the data that applies to the relevant machine/engine. 14.4.1Change intervals The table below states hours of operation and cal- endar months. -
Page 17: Spark Plug
The battery must be fully charged be- fore being used for the first time. The battery must always be stored fully charged. If the battery is stored while discharged, serious damage will occur. 14.8.1 Charging with the engine The battery can be charged using the engine’s gen- erator as follows: 1. - Page 18 14.12Lubrication All lubrication points in accordance with the table below must be lubricated every 50 hours of opera- tion as well as after every wash. Object Action Centre point 4 grease nipples. Use a grease gun filled with universal grease. Pump until the grease emerges.
