Quick Start Guide
Thunderbolt™ 3/USB-C I/O Card

Installation Instructions

Before installing the Thunderbolt 3/USB-C I/O card, make sure
the Falcon-NEO has the latest software
The latest version can be found on the Falcon-NEO's knowledge base
page at: https://www.logicube.com/knowledge/forensic-falcon-neo/.
Instructions on how to update the software and firmware can also be
found on the same page above.
The Falcon-NEO Thunderbolt 3/USB-C I/O Card is not hot-swappable. Always turn
the Falcon-NEO off before connecting or disconnecting the I/O card to/from the
Falcon-NEO. Drives or enclosures connected to the I/O card can be hot-swapped.
The I/O card does not currently support imaging in TDM from Mac
computers. Please refer to our AppNote on how to image Macs with the
Falcon-NEO. This AppNote can be found on our Falcon-NEO support
page at:
http://www.logicube.com/knowledge/forensic-falcon-neo/

To install the Thunderbolt 3/USB-C I/O card:

1. Turn the Falcon-NEO OFF and disconnect the AC adapter/power supply from the back of the
Falcon-NEO.
2. Turn the Falcon-NEO upside-down and use the included screwdriver to remove the desired I/O
port door:
TBT-QSG-v1.3
Revised Date: 10/10/2019
Logicube, Inc. • 19755 Nordhoff Pl.,Chatsworth, CA 91311 USA• tel:+1-818-700-8488• fax:+1-818-435-0088
AND
firmware installed.
www.logicube.com
Page 1 of 5
