Sterling Designer Pivot Shower Doors 1500D Specifications

Features
• Heavy-duty, anodized aluminum-framed glass doors
• Full length handle for easy operation
• Aluminum components extruded from alloy 6063-T5
• Tempered glass ensures maximum safety and
durability
• Threshold directs water back into the shower and
minimizes soap or lint build up
• Pivot bushings provide silent operation
• Installs left- or right-handed
• Adjustable wall jamb allows for out-of-plumb
conditions up to 1" (2.5 cm) per side
• A width adjustment of 6" (15.2 cm) per model
reduces inventory requirements
• Full length magnet provides secure door closure
• Stainless steel hardware prevents rusting or corrosion
Codes/Standards Applicable
Specified model meets or exceeds the following:
• ANSI Z97.1 (tempered glass)
Specified Model
Model Width (A)*
(Min/Max)
1500D-42** 42" (106.7 cm) / 36" (91.4 cm)
1500D-48** 48" (121.9 cm) / 42" (106.7 cm)
1501D-48** 48" (121.9 cm) / 42" (106.7 cm)
* Note: Consult the diagram on the next page for the location of the measurements.
** Note: Add appropriate frame color/finish code to the end of the unit model # when ordering.
Page 1 of 2
G
1022520-4-
DESIGNER PIVOT SHOWER DOORS
Colors/Finishes
•
Refer to the Price Book for current frame finish and glass
options
Height (B)* Walk Through (C)*
(Min/Max)
65-1/2" (166.4 cm) 24-13/16" (63 cm) / 19-1/2" (49.5 cm)
65-1/2" (166.4 cm) 24-13/16" (63 cm) / 19-1/2" (49.5 cm)
65-1/2" (166.4 cm) 24-13/16" (63 cm) / 19-1/2" (49.5 cm)
VISTA PIVOT
TM
1500D
ALSO 1501D
For more information
visit SterlingPlumbing.com
or call 1-800-STERLING
