Sterling SSIL Series Reference Manual

Quickstart Installation Checklist
(Refer to main manual for complete installation instructions)
1. Mount hopper mounting flange to machine bin or feed throat, using rivets if possible.
2. Ensure that unit is level for proper operation.
3. Attach flex hose to unit and pickup wand. Secure it with hose clamps.
4. Attach clean, dry 80-120psi air.
5. Plug unit into grounded three-prong receptacle.
Unit Operation
(Refer to main manual for complete operating instructions)
1. Insert pickup wand into desired material.
2. Press the
Note: The hopper loader loads itself until full, then dumps and repeats.
It pauses only when the machine bin below is full.
3. To stop the unit from loading, press the
For Proportioning Models
1. Insert pickup wands into desired materials.
2. Press SCROLL key repeatedly until screen displays "3".
3. Press the
4. Use the UP and
5. Press the
6. Press the
Sterling
th
2900 S. 160 Street • New Berlin, WI 53151 USA
Tel. 262.641.8610 • Fax 262.641.8653
SSL and SSIL Series Hopper Loaders – Series One Plus Control
Reference Manual (PN: 882.00149.00) for
Complete Operation and Installation Instructions
(Available online at www.acscustomerservice.com)
START/STOP key.
START/STOP/SELECT key to select the "% of MAT'L B" menu.
DOWN keys to set the desired % of Material B.
START/STOP/SELECT key to set this value.
START/STOP/SELECT key again to start the hopper loader.
START/STOP key.
Part No: 882.00349.00
Bulletin No: CV1-335.01
