DO NOT REMOVE PRIOR TO SALE!
Model 1189
I. APPROVAL CONDITIONS and CARRIAGE REQUIREMENTS
Inflatable PFD Model No. 1189 is approved by the U.S. Coast Guard
for use as Type III Personal Flotation Device (PFD) and Model No.
1193 is approved as Type V Personal Flotation Device (PFD) with Type
III performance because the harness with it can cause injury if not
properly used.
Inflatable PFD's are not approved for water skiing or other high impact,
high-speed activities. This inflatable was designed to be more
comfortable and less restrictive to wear than inherently buoyant PFDs.
When worn, used and serviced according to this owner's manual, this
PFD can greatly increase your chances of survival in the water. Not
recommended for non-swimmers or weak swimmers. Users of
inflatable PFDs must be at least 16 years old.
PLEASE SEE IMPORTANT SIZING, FIT AND USE INFORMATION FOR
SAILING HARNESS ON PAGES 3 AND 4. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN INJURY OR DEATH.
OWNER'S MANUAL
Model 1193 w/harness
Advertisement
Table of Contents
Related Manuals for Stearns 1189
Summary of Contents for Stearns 1189
- Page 1 Model 1189 I. APPROVAL CONDITIONS and CARRIAGE REQUIREMENTS Inflatable PFD Model No. 1189 is approved by the U.S. Coast Guard for use as Type III Personal Flotation Device (PFD) and Model No. 1193 is approved as Type V Personal Flotation Device (PFD) with Type III performance because the harness with it can cause injury if not properly used.
-
Page 2: Specifications
MECHANISM PARTS LIST SPECIFICATIONS Chest Size: 30 - 52 inches (76 - 132 cm) Weight Range: More than 90 pounds (41 kg) Minimum Height: For harness model 1193 only - 5 feet 5 inches (165cm) Age Range: 16 years of age and older Buoyancy (minimum): 33.7 Pounds (150 Newtons) when fully inflated Inflation System: Manual Inflation Mechanism (located on your right side) - Page 3 HARNESS USE INSTRUCTIONS FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN INJURY OR DEATH. • ALERT! Under no circumstances should the sailing harness be used in any climbing task or related activity. Failure to comply with this restriction in use may result in death or injury. •...
-
Page 4: Mandatory Carriage Requirements
ADDITIONAL HARNESS INFORMATION • This harness was designed and tested to meet the requirements for OFFSHORE RACING COUNCIL (ORC) requirements for Sailing Harnesses. • USCG approval does not apply to the sailing harness. • It is strongly recommended that first time users of Sailing Harnesses receive instruction from a reputable dealer, sailing school, or otherwise experienced harness sailor. - Page 5 READ BELOW FOR MORE DETAILED INFORMATION! 1. Inspecting Your PFD For Damage Make sure that the PFD is free from rips, tears or punctures. This type of damage on the outside covering indicates that the Inflatable Chamber may have been exposed to potentially damaging elements. If these defects expose the yellow inflatable chamber material, discontinue use of the PFD until you have the PFD inspected by an authorized repair facility.
-
Page 6: Donning Instructions
DONNING INSTRUCTIONS After donning, locate the Jerk To Inflate tab for the mechanism. It should protrude from the PFD as shown on the pictogram. Make sure that you are comfortable locating the Jerk To Inflate tab with either hand. Should an emergency develop, be prepared to use it! Always wear your PFD over, not under clothing. - Page 7 INFLATION INSTRUCTIONS See Pages 12 -14 for additional information on testing and inflating your PFD. 1. Manual Inflation - To inflate, grasp the Jerk to Inflate tab and pull sharply downward. 2. Oral Inflation - The Oral Tube is located on the wearer's left side. Grasp the Oral Tube and bring to mouth.
- Page 8 DEFLATION INSTRUCTIONS Depress Oral Valve (located inside end of Oral Tube) using either the protective cap or tab provided by inserting into the end of Oral Tube, see drawing. Gently compress air out of the inflatable chamber while depressing the Oral Valve. DO NOT TWIST OR WRING INFLATABLE CHAMBER TO DEFLATE.
-
Page 9: Freezing Temperatures
FREEZING TEMPERATURES Never use in below freezing temperatures, unless worn partially inflated. At or below 40° F (4° C) inflation time with CO2 gas will be longer. Wearing a partially inflated PFD in these conditions will provide some initial buoyancy while the PFD fully inflates. Caution: Do not fully inflate orally and then inflate with the CO2 cylinder. -
Page 10: User's Inspection
V. CARE AND MAINTENANCE INSTRUCTIONS GENERAL PRODUCT LIFE EXPECTANCY The reliability and service life of this PFD depends greatly upon how it is used and cared for. Avoid storing PFD in direct sunlight. Sunlight contains ultraviolet radiation that weakens synthetic materials. Prolonged exposures to high temperatures and high humidity may shorten service life of this PFD. -
Page 11: Care And Cleaning Instructions
REARMING KIT(S) Use Rearming Kit No. 0932. See Rearming Instructions on back cover. CARE AND CLEANING INSTRUCTIONS Drying - If the device is wet, place on a coat hanger to allow thorough drying. Do not place in direct sunlight to dry. Do not use any heat source or place on radiator. -
Page 12: Why Are Pfds Required Safety Equipment
VI. WHY ARE PFDS REQUIRED SAFETY EQUIPMENT? Drownings are the leading cause of fatalities involving recreational boating. A PFD provides flotation to help keep your head above water, help you to stay face up in the water, and increase your chances for survival and rescue. -
Page 13: How Do You Test Your Pfd Using The Manual Inflator
HOW DO YOU TEST YOUR PFD USING THE 1. To test your inflatable PFD, you will need: • Your fully armed PFD, and • Rearming kit approved for your PFD. 2. Put on the PFD. 3. Actuate the inflation system by jerking firmly downward on the pull tab. -
Page 14: How Do You Test Your Pfd Using The Oral Inflator
HOW DO YOU TEST YOUR PFD USING THE ORAL INFLATOR? 1. To test your inflatable PFD, you will not need any spare parts or rearming kits. 2. Remove the CO2 cylinder to prevent inadvertent activation of the inflation system, which could potentially damage the PFD. 3. -
Page 15: Wear Your Pfd
VIII. WEAR YOUR PFD In approximately 80 percent of all boating fatalities, the victims were not wearing a PFD. Most fatal accidents happen on calm sunny days. This inflatable PFD is much more comfortable to wear than other PFD types. Get into the habit of wearing this PFD. - Page 16 Some Points to Remember About Hypothermia Protection: 1. Always wear your PFD. Even if you become incapacitated due to hypothermia, the PFD will keep you afloat and greatly improve your chances of rescue. 2. Do not attempt to swim unless it is to reach a nearby craft, fellow survivor, or a floating object on which you can lean or climb.
-
Page 17: Additional Information
X. EACH OF THESE DEVICES IS INTENDED TO HELP YOU SAVE YOUR OWN LIFE For your PFD to function properly follow these suggestions to verify that it fits, floats, and remains in good condition. 1. Check the status of the inflator and make sure that the status indicator is green. -
Page 18: Do Not Attach Pfd's To Your Boat
DO NOT ATTACH PFD'S TO YOUR BOAT Each PFD has straps, hooks, buckles, or other means for securing the device in place on the wearer. Some PFDs also incorporate decorative dee rings or tabs. Such items are not to be used to attach the device to the boat. -
Page 19: Repacking Instructions
REPACKING INSTRUCTIONS Always deflate the PFD and rearm the Inflation Mechanism - follow REARMING Instructions prior to REPACKING! 1. Lay device out flat with the yellow inflatable chamber up. Fold right inside edge over as shown, exposing Velcro® strip. 2. Fold right outside edge over, securing Velcro®... - Page 20 (printer id)
