- Page 1 MAXK Installation and Operating Instructions Document in original language | ·...
- Page 2 © Copyright Systemair AB All rights reserved E&OE Systemair AB reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it does not affect the previously agreed specifications.
-
Page 3: Table Of Contents
Contents Declaration of Incorporation.......1 7.7.1 Interception safety ....13 Silencer..........13 General information .........2 Internal lightening ........ 13 Notice symbols ........2 7.9.1 Roof units....... 14 2.1.1 Instruction symbols.....2 Syphon ............14 Notes on the documentation ....2 Syphon for cooler ......... 15 Warnings............2 8.1.1 General information .... -
Page 5: Declaration Of Incorporation
Declaration of Incorporation | Declaration of Incorporation... -
Page 6: General Information
| General information General information Notice symbols Danger Direct hazard Failure to comply with this warning leads directly to death or to serious bodily harm. Warning Potential hazard Failure to comply with this warning possibly leads to death or serious bodily harm and damage to objects. Caution Hazard with a low risk Failure to comply with this warning may potentially lead to moderate injuries or/and damage to objects. -
Page 7: Product Information
Product information | Warning • Keep the doors locked during operation to ensure required level of safety for the unit. • The unit must be duct connected or in some other way provided with protection so that it is not possible to come in contact with the fans through the duct connections •... -
Page 8: Dimensions
| Product information Dimensions MAXK-I3 DC 2000 DC 3326 1664 3000 DC 3486 1120 1664 4000 DC 3586 1600 1664 5000 DC 3686 1900 1664 6000 DC 3686 2280 1664 7000 DC 2786 2600 1664 * incl. 100 mm base frame. (dimensions in mm) Technical data MAXK-I3... -
Page 9: Acoustics
Transport and storage | 1000 1200 1390 1620 1840 Total weight without heating battery Total weight with 1093 1330 1521 1792 2031 heating battery * with built in filters (outdoor air F7 and extract air M6). Additional installed units such as, for example, heating battery reduce the available external pressure Acoustics MAXK-I3 DC Sound level*... -
Page 10: Crane Transport
| Transport and storage Crane transport Small units are equipped with 2 eyebolts (diagonally staggered), big parts with 4 eyebolts. Note: • load suspension device acc. to UVV188.4§4 • slope angle: 60° • it must be guaranteed that the crane doesn’t jerk •... -
Page 11: Installation
Installation | Installation Installation site Floors, foundations, ceilings or steel construction must be checked as to the planeness. Unplaneness causes a more dif- ficult mounting and the canting of the doors. The consequences among other things are doors which can heavily be opened and which are untight. -
Page 12: Mounting Steps
| Installation Note: The necessary screws and sealings for the mounting are attached loose to each delivery and deposited in the ventilator part. screws type term M8 x 20 mm Galvanized sheet, thickness: 2–3 mm U-70 M8 x 20 mm U-structural steel, rounded U-structural steel, rounded U-100 und U-120... -
Page 13: Mounting Indications For The Kind Of Delivery: „Dismantled Assembly Group
Installation | Important Through jolting during the transportation bore chips can loosen from the bolting connections and fall on the ground. Please vacuum these chippings immediately from the housing parts since rust spots can ensue. Mounting indications for the kind of delivery: „dismantled assembly group“ •... -
Page 14: Mounting Indications For Wet Parts
| Internal components Mounting indications for wet parts Cooler parts have to be mounted and filled very Detail A: tub protruding at the bottom thoroughly Detail B: tub flush at the bottom Internal components V-cell-filter Due to its large filter surface has a high air throughput. The pollution must be controlled with a differential pressure device (U-tube, inclined tube). -
Page 15: Air Heater, Air Cooler And Glycol-Compound System
Internal components | Air heater, air cooler and glycol-compound system After the mounting of the heat exchanger units the ribbed surfaces must be covered to avoid mechanical damages. The connection of the heat exchanger, air heaters as well as the coolers must be made de-energized. When exchanging the filter, pollutions must be removed. -
Page 16: Electrical Heater
| Internal components Electrical heater The casing is made of Aluzinc-coated sheet steel, AZ 185, that conforms to the requirements for corrosivity class C4. The heater elements are made of stainless steel to EN 1.4301. The junction box includes the terminal blocks necessary for the electrical connections. -
Page 17: Jalousie Damper
Internal components | Jalousie damper Jalousie flaps are equipped with polyamid-bearing- sleeves. These need not be maintained (do not put oil or grease on them). Please pay attention that the jalousie flaps must be opened before switching on the ventilator and that the ventilator must be switched off before the closing of the jalousie flaps. -
Page 18: Roof Units
| Syphon 7.9.1 Roof units Lights are wired on internal terminal boxes. Internal wiring of the terminal boxes between each other resp. from component to component must be made on site. Syphon 1a Rubber sleeve 40–30 1b Rubber sleeve 40–30 2 Jaining piece 40–40 3 Sleeve nut 1 1/2“... -
Page 19: Syphon For Cooler
Syphon | Ground clearance of the central units The function and mounting of a syphon requires a sufficient ground clearance of the respective device. The minimum ground distance R to picture 2 is: Important In case of disregarding the base height the overflowing of the tub is preprogrammed Syphon for cooler Pressure operation: Note:... -
Page 20: Outdoor Installation
| Outdoor installation Negative pressure Overpressure Outdoor installation Important ♦ If the weather protection roof cannot be bought immediately, the top of the unit must be covered watertight. ♦ The outside joints of outdoor units have to be permanently elastic sealed. While assembly work the joints must be proved. -
Page 21: Roof Frame Made Of Galvanized Sheet
Outdoor installation | kind of delivery. box sheets pre-punched drilling screws 4,8 x 19 loose Roof frame made of galvanized sheet detail: drip ledge Cut: roof frame insulated (extra charge) Mounting of the drip ledge ♦ install, set up, bolt the device ♦... -
Page 22: Condensation And Heat Insulation
| Condensation and heat insulation Top view Important It should be ensured that the base frame is insulated. Without insulation it can occur condensat. Condensation and heat insulation Outdoor air duct and exhaust ducts must always be well insulated against condensation. Correct insulation installation on ducts connected to the unit is especially important. -
Page 23: 11.2 General
Maintenance | 11.2 General The maintenance manual is only for Systemair air handling units of the MAXK-I3 series. Keep attention to the listed warnings above during maintenance work. Follow the valid general safety requirements and the valid operating rules. Use suitable and safe ads (ladder, working platform etc.) Mainly the maintenance work consists of a visual inspection of the air handling unit, periodic filter change and cleaning of the heat exchanger. - Page 24 | Maintenance Check the function of the water drain and odour seal Drop separator examine for dirt, incrustration, damage and corrosion Function sustenance cleaning Check the function of the water drain and odour seal Counterflow heat exchanger Examine for dirt, damage and corrosion Function sustenance cleaning (air side) Check the function of the water drain and odour seal...
-
Page 25: Disturbances And Troubleshooting
Disturbances and troubleshooting | 11.3 Examine interior air pipe surface for contamination and corrosion on two or more representative place Air passages 12.1 Examine installed perforated metal plate, wire mesh of filter for contamination Wall grid 13.1 Examine for dirt and mounting Silencer 14.1 Examine for dirt, damage and corrosion... - Page 26 | Disturbances and troubleshooting Venting Air handling unit does not heat or Air in the water heating battery heats insufficiently To low temperature of the hot water Control the temperature of the heating in the water heating battery medium To low power of the heating battery Contact the manufacturer Heat recovery defect Contact the manufacturer...
- Page 28 Systemair GmbH Seehöfer Str. 45 97944 Boxberg Germany Tel.: +49 (0)7930/9272-0 Fax: +49 (0)7930/9273-92 info@systemair.de www.systemair.de...
