Toto YH87S Installation Manual

YP03067R
Robe Hook・Paper Holder・Towel Bar
In order to make full use of the capabilities of the product, mount it properly according to this installation manual. After mounting the product, fully explain the
method of use to the customer.
The product comes with an owner's manual for the customer. After the completion of product mounting, be sure to give the owner's manual to the customer.
Be sure to write the name of the dealer and the date of installation on the warranty attached to the owner's manual.
Safety precautions
Carefully read the Safety precautions before mounting the product and bear
them in mind when mount the product.
・In order to mount the product safely and properly and to
prevent physical harm to the customer or other persons
and damage to property, various signs are shown in this
manual. The signs and their meanings are shown below.
Sign Meaning
Indicates that disregarding the
precaution shown in this box could
WARNING
result in death or serious injury.
Warning about mounting
Use plywood of a thickness of 12mm or more
as the mounting surface.
Not doing so could cause the mounted product to become
unstable and fall resulting in injury.
If the mounting surface is a thin wall, reinforce
it with a wooden board of a thickness of 30mm
or more beforehand and then mount the product.
Not doing so could cause the mounted product to become
unstable and fall resulting in injury.
WARNING If the mounting surface is a tile or concrete
Be sure to do
wall, use the provided resin plug, etc.
Not doing so could cause the mounted product to become
unstable and fall resulting in injury.
Use the provided wall mounting screw for
mounting the product.
Not doing so could cause the mounted product to become
unstable and fall resulting in injury.
Installation Manual
(Be sure to observe these safety precautions .)
・The following symbol is used to
indicate and explain the type of
precaution.
indicates matters
that should be
performed without fail.
This symbol means
Be sure to do .
Warning about mounting
After mounting the product, check that it
does not rattle.
If the product rattles, it could come off or the wall could be
WARNING
Be sure to do
damaged, causing the user to fall down and get injured.
If there is an uneven area on the wall, secure a
■
Request
flat surface using a washer or spacer.
concerning
Leave 130mm or more of space to the left of the
■
mounting
paper holder so that a paper roll can be set.
Checking of attached parts
■ Check that the following parts are provided.
Attached parts
Wall mounting screw
(Pan head tapping screw φ4.5×40)
Wall mounting screw
(Flat head tapping screw φ5×40)
Resin plug
Mount
Main body assembling screw
(Cross recessed head countersunk screw M4×8)
Cover
Cover assembling screw
(Hexagon socket head countersunk screw M3×20)
Hexagonal wrench (nominal dimension of spanner: 2)
YA87S ・YH87S
YT87S5S ・YT87S7R
YA87S YH87S YT87S5S YT87S7R
2 ー ー ー
ー 4 3 4
2 4 3 4
1 ー ー ー
2 ー ー ー
ー 1 1 1
ー 2 2 3
ー 1 1 1
