Owner's Manual
CAUTION:
Weight on this product should not exceed 300 lbs.
2007, 10
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 (800) 375-7520
www.staminaproducts.com
WARNING
Exercise can present a health
risk. Consult a physician
before beginning any exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Follow all safety instructions in
this manual.
When calling for parts or
service, please specify the
following number.
50-3000
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2007 Stamina Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Viper VG1500 and is the answer not in the manual?

Questions and answers

bacon
April 15, 2025

What size is the cable for replacement

0
1 comments:
Mr. Anderson
April 15, 2025

The Stamina Viper VG1500 uses a Cable (part 45) and a Short Cable (part 46), but the specific size of the cables is not provided in the available information.

This answer is automatically generated

0

Related Manuals for Stamina Viper VG1500

Summary of Contents for Stamina Viper VG1500

  • Page 1 Follow all safety instructions in this manual. When calling for parts or service, please specify the following number. 50-3000 STAMINA PRODUCTS MADE IN CHINA Product May Vary Slightly From Pictured. 2007 Stamina Products, Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Instructions Before You Begin Hardware Identification Chart Assembly Instructions Setting up The Accessories Storage Maintenance SAFETY INSTRUCTIONS WARNING: To reduce the risk of serious injury, read the following Safety Instructions before using the VIPER Read all warnings posted on the VG1500 Read this Owner's Manual and follow it carefully before using the VG1500 Make sure that it is properly assembled and tightened before use.
  • Page 3 THANK YOU FOR PURCHASING THE VIPER VG1500 Leverage System Your VIPER VG1500 Leverage System does require assembly. Please follow the assembly steps set forth in this manual. Within a short time you will be getting your body into shape and on your way to a achieving a healthier lifestyle.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the VG1500 System. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to its fullest. Yes, it's a proven fact that a regular exercise program can improve your physical and mental health.

  • Page 5: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers, the end of the bolts, or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.

  • Page 7: Locking Knobs

    ASSEMBLY INSTRUCTIONS FRONT REAR STEP 3 Attach the LOWER UPRIGHT(6) to the BASE FRAME(1) with the SUPPORT BRACKET(5), HEX BOLTS (M12x1.75x70mm)(72), WASHERS(M12)(80), and NYLOCK NUTS(M12x1.75)(82). Do not tighten the bolts. Attach the LOW UPRIGHT(6) to the REAR STABILIZER(2) with HEX BOLTS(M12x1.75x70mm)(72), WASHERS(M12)(80), and NYLOCK NUTS(M12x1.75)(82).
  • Page 8 ASSEMBLY INSTRUCTIONS FRONT Large Ball End Small Ball End REAR STEP 6: Run the SMALL BALL END of the CABLE(45) through the slot at the top end of the UPRIGHT(7). Attach the CABLE(45) to the UPRIGHT(7) at "A" with the LARGE PULLEY(44), a HEX BOLT (M10x1.5x95mm)(70), two WASHERS(M10)(81), and a NYLOCK NUT(M10x1.5)(83).

  • Page 9: Back View

    ASSEMBLY INSTRUCTIONS BACK VIEW STEP 9 Refer to the inset drawing. Attach the SLIDER SUPPORT(14) to the LOWER UPRIGHT(6) with HEX BOLT (M12x1.75x160mm)(77), WASHERS(M12)(80), and NYLOCK NUT(M12x1.75)(82). Do not over tighten the bolt, as the SLIDER SUPPORT(14) must be able to pivot smoothly. STEP 10 Pull the SPRING PIN(34) on the SLIDER SUPPORT(14).
  • Page 10 ASSEMBLY INSTRUCTIONS FRONT REAR STEP 12 Attach the SEAT FRAME(9) to the LOWER UPRIGHT(6) with HEX BOLTS(M12x1.75x100mm)(75), WASHERS(M12)(80), and NYLOCK NUTS(M12x1.75)(82). STEP 13 Attach the LEG LIFT(10) to the SEAT FRAME(9) with HEX BOLT(M12x1.75x90mm)(74), WASHERS (M12)(80), and NYLOCK NUT(M12x1.75)(82). STEP 14 Run the CABLE(45) through the slot in the LEG LIFT(10).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 16 Attach the FOAM SUPPORTS(15) to both sides of the LOWER UPRIGHT(6) with HEX BOLTS (M12x1.75x100mm)(75), WASHERS(M12)(80), and NYLOCK NUTS(M12x1.75)(82). STEP 17 Attach the HEAD REST(35) and BACK CUSHION(36) to the BACK SUPPORT(12) with HEX BOLTS (M10x1.5x25mm)(67) and WASHERS(M10)(81). STEP 18 Attach the SEAT CUSHION(37) to the SEAT POST(11) with HEX BOLTS(M10x1.5x25mm)(67) and WASHERS(M10)(81).
  • Page 12 ASSEMBLY INSTRUCTIONS Screw hole Slot STEP 19: There is an "L" decal on the LEFT LEVERAGE ARM(17), and an "R" decal on the RIGHT LEVERAGE ARM(18). Slide the RIGHT LEVERAGE ARM(18) onto the shaft at right side of the ARM BRACE(16) and secure with LARGE WASHER(M12xø31mm)(79) and NYLOCK NUT(M12x1.75)(82).
  • Page 13 ASSEMBLY INSTRUCTIONS Ring STEP 22 Slide a FOAM ROLLER(39) onto a SUPPORT TUBE(38) and screw a SECURING CAP(41) onto the end of the SUPPORT TUBE(38). Insert the other end of the SUPPORT TUBE(38) through the hole in the LEG LIFT(10). Slide another FOAM ROLLER(39) over the protruding end of the SUPPORT TUBE(38) and screw a SECURING CAP(41) onto the end of the SUPPORT TUBE(38).

  • Page 14: Setting Up The Accessories

    SETTING UP THE ACCESSORIES LAT BAR(49) Attach the LAT BAR(49) to the CABLE(45) with a QUICK LINK(47). For some exercises, the SHORT CHAIN(56) or LONG CHAIN(55) should be attached between the LAT BAR(49) and the CABLE(45) with two QUICK LINKS(47). STRAIGHT BAR HANDLE(51), ANKLE CUFF(53) The STRAIGHT BAR HANDLE(51) and ANKLE CUFF(53) can be attached to the ball end of the CABLE(45) at the bottom of the LEG LIFT(10) with two QUICK LINKS(47) and one of the CHAINS(55, 56).

  • Page 15: Storage

    Leverage System is regularly examined for damage and wear. Special attention should be given to the following: Verify that the warning and notice labels are in place and easy to read. Call Stamina Products immediately (1-800-375-7520) for a replacement label if labels are missing or damaged.

  • Page 16: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength-training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength...

  • Page 17: Limited Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071 or call us at 1 (800) 375-7520. If the defect is covered under this limited warranty, you will be requested to return the product or part to us for free repair or replacement at our option.

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING BACK FRONT...

  • Page 19: Parts List

    PARTS LIST DIAGRAM# PART NAME Base Frame Rear Stabilizer Rear Support Foot Plate Support Bracket Lower Upright Upright Lever Arm Seat Frame Leg Lift Seat Post Back Support Adjustment bar Slider Support Foam Support Arm Brace Left Leverage Arm Right Leverage Arm Left Weight Bar Right Weight Bar Left Handlebar...
  • Page 20 PARTS LIST DIAGRAM# PART NAME Hook Sleeve Lat Bar Foam Grip Straight Bar Handle Hand Grip Ankle Cuff Ab Curl Strap Long Chain (10 Links) Short Chain (6 Links) Stand Bumper Rectangular Plug (30mm x 60mm) Rectangular Plug (50mm x 75mm) Square Plug (50mm x 50mm) Round Plug (25.4mm) Round Plug (42mm)

  • Page 21: Notes

    NOTES...

  • Page 22: Fax/Mail Ordering Form

    ONLINE CUSTOMER SERVICE CUSTOMER SERVICE Fax: (417) 889-8064 parts@staminaproducts.com cust-srvc@staminaproducts.com www.staminaproducts.com Detach and Mail or Fax the Form Below Stamina Products, Inc. P.O. Box 1071 Springfield, MO 65801-1071 State: Work Phone #: ( DESCRIPTION Rear Unit Assembly MAIL STAMINA PRODUCTS, INC.
