Vertical
Tail Wing
Propeller
Gyro Havoc
Experience radio-controlled flight with the Air Hogs
flying fun & easy! Just choose the direction you want to fly and press the controller toggle. The ultra-light Gyro Havoc™ is powered
by a lithium battery for long flights, features precision speed control and damage-resistant foam. The Gyro Havoc™ also includes an
integrated Charger/Controller unit for convenient portability and easy handling on the field.
1. Use a Phillips screwdriver to loosen the battery door.
2. Remove the battery door.
3. Install 6 AA 1.5-V alkaline batteries (not included).
Be careful to align the positive (+) and negative (-)
polarities with the corresponding markings inside the
battery compartment.
4. Reinstall the battery door and tighten the screw.
IMPORTANT TIP: TURN YOUR CHARGER/
CONTROLLER ON TO ENSURE THAT THE
BATTERIES ARE INSTALLED PROPERLY. THE
RED LIGHT ON THE FRONT OF THE
CHARGER/CONTROLLER SHOULD TURN RED.
After use, store the Gyro Havoc™ in its package to
prevent damage.
Your Gyro Havoc
rechargeable battery in the aircraft's fuselage
Because the Controller's AA batteries
are used for 2 functions – charging and
controlling, they will need to be replaced after
every 20 – 25 flights.
WARNING:
THIS PRODUCT IS A GYROCOPTER!
A gyrocopter is different from
an airplane or conventional helicopter.
Read these instructions to ensure
successful flights.
®
INSTRUCTIONS
Rotors
Propeller
Wing
Fuselage
TM
®
RC Gyro Havoc™! The Gyro Havoc™ is half airplane and half helicopter making
CHARGER/CONTROLLER BATTERY INSTALLATION
TM
has a preinstalled
TM
ON/OFF/CHARGE
Switch
Throttle
Charge Door
(to access Charge Nozzle)
Charger/Controller
1
Battery
Door
3
Six AA
1.5-V
Alkaline Batteries
Antenna
.
Controller/Charger
Repair
Check to make sure contents are complete:
• 1 Air Hogs
®
Gyro Havoc™ • 1 Wind Ribbon
• 1 Charger/Controller • 1 Instruction Sheet
Antenna
2
REPAIRS
If the wings or fuselage
on your gyrocopter get
damaged they can be
easily repaired with clear
tape as shown.
Charge
LED
Power
LED
Left/Right
Toggle
Steering
Trim Knob
Battery
Compartment
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spin Master Air Hogs RC Gyro Havoc
Summary of Contents for Spin Master Air Hogs RC Gyro Havoc
- Page 1 ® Rotors Vertical Tail Wing Propeller Gyro Havoc Experience radio-controlled flight with the Air Hogs flying fun & easy! Just choose the direction you want to fly and press the controller toggle. The ultra-light Gyro Havoc™ is powered by a lithium battery for long flights, features precision speed control and damage-resistant foam. The Gyro Havoc™ also includes an integrated Charger/Controller unit for convenient portability and easy handling on the field.
- Page 2 • Before taking your initial flight, charge the Gyro Havoc™ for a complete charge cycle on your charger. • Depending upon the length of future play, you will not need to complete a full charge before each flight. NOTE: A shortened charge results in a shorter play time (may take up to 1/2 hour to fully charge). 1.
- Page 3 Charger/Controller NOTE: The Gyrocopter’s rotors are not powered Throttle (Helicopters have powered rotors) – the rotors spin due to interaction with the air as the Gyrocopter moves. LEFT TURN Tap or pulse the steering stick (right stick) to the left, this will result in a gentle turn, for a steep turn, hold the stick to the left.
- Page 4 CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Spin Master Ltd., 450 Front Street West, Toronto, ON M5V 1B6 Canada Spin Master, Inc., PMB #10053, 300 International Drive, Suite 100,...
