Spin Master Air Hogs Blue Sky Instructions

ADULT SUPERVISION IS REQUIRED

INSTRUCTIONS
Contents:
1 Plane
1 Pump, 1 Main Wing
1 Rear Wing Assembly

PUMP UP YOUR BLUE SKY

1. Gently push the PUMP NOZZLE
all the way onto the AIR INTAKE
on the nose of the plane.
2. Push pump 40 times (or until the
AIR TANK is full).
TIP: You will know the AIR TANK is
full when the release valve whistles.
3. Hold the plane by the engine
housing and gently
remove the plane from
the pump.
Use only the AIR PUMP that comes with your
BLUE SKY TM airplane. For safety, this pump has a
unique built-in pressure relief valve to ensure that
the AIR TANK is not over filled.

WING RE-ASSEMBLY

To increase the Blue Sky TM 's durability, it has
been equipped with pop-off wings. Pop-off wings
significantly help the plane to avoid breakage on
impact with harsh surfaces (ie. ground, trees etc.)
IMPORTANT: While pop-off wings do help to protect
the product against damage, they are not foolproof.
To help preserve the life of your Blue Sky
fly in a wide-open area with lots of grass.
1
Insert the MAIN WING
ALIGNMENT TAB into
the MAIN WING
ALIGNMENT SLOT.
2
Strap the FRONT
WING HARNESS over the
front of the MAIN WING and
wrap the elastic around the
AIR TANK.
Tail Flap
Rear Wing
Harness
Thank you for purchasing the Air Hogs
The Blue Sky TM is a real-flying plane and is powered by a miniature air pressure engine, called
the Rehco Rocket TM . The Blue Sky
Blue Sky TM requires no gas and no batteries... Just Pump It Up!
TM
Air
Nozzle
TM , always
3
Strap the REAR
WING HARNESS
around the back of the
AIR TANK.
Vertical Horizontal
Tail Wing Tail Wing
Main Wing
Alignment
Tab
Air
Tank
Air
Intake
Main
Wing
® Blue Sky TM and welcome to the exciting world of flight!
TM reaches exciting heights of up to 50 feet. Powered by air, the

FLIGHT INSTRUCTIONS

1
Starting the motor
Hold the plane in your launching hand
and flick the propeller downward with
your other hand.
3
To achieve a level flight you may
have to adjust the right and left
wing flaps up or down.
• Gently bend the Left flap
up to make the plane bank
to the Left.
• Gently bend the Right flap
up to make the plane bank
to the Right.
4
Make sure VERTICAL TAIL
WING is straight. Also ensure
HORIZONTAL TAIL WING is
level with MAIN WING.
Tail Wing
Horizontal
Tail Wing
Main Wing
Pump
Alignment
Handle
Slot
Pump
Shaft
Pump
Nozzle
Pump Base
2
Launch Blue Sky
the wind for best take off and
flight results.
Right Wing Flap
5
Bend both TAIL
FLAPS up to
make plane
climb higher/
faster.
Vertical
TM against
Left Wing
Flap
6
Bend both TAIL
FLAPS down if
plane is climbing
sharply, then
crashing.
