Speed Queen 202147R2 User Manual

Speed Queen 202147R2 User Manual

Topload washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Inside . . .
Operation . . . . . . . . . . . . 6
Clothing Care . . . . . . . .15
Maintenance. . . . . . . . .16
Troubleshooting . . . . .19
Para bajar una copia de estas instrucciones
en español, visite www.speedqueen.com.
www.speedqueen.com
for your
topload
washer
Part No. 202147R3
November 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 202147R2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Speed Queen 202147R2

Summary of Contents for Speed Queen 202147R2

  • Page 1: Table Of Contents

    Inside . . . Safety Information . . . 3 Operation ... . 6 Clothing Care ..15 Maintenance..16 Troubleshooting .
  • Page 2 W A R N I N G For your safety and to reduce the risk of fire or an explosion, do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 3: Safety Information

    Safety Information Explanation of Safety Messages Throughout this manual and on machine decals, you will find precautionary statements (“DANGER,” “WARNING,” and “CAUTION”) followed by specific instructions. These precautions are intended for the personal safety of the operator, user, servicer, and those maintaining the machine. D A N G E R Indicates an imminently hazardous situation that, if not avoided, will...
  • Page 4 5. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using a washing machine or combination washer-dryer, turn on all hot water faucets and let the water flow from...
  • Page 5 23. If the washer’ s volume or type of sound changes from what is normally heard, call an authorized service agent immediately to prevent possible damage to other components. 24. Never start a cycle and leave the property without first checking to make sure the wash cycle is complete.

  • Page 6: Operation

    Operation Before Washing Prepare Wash Load Empty Pockets and Cuffs Make sure all pockets are empty and turn them inside out. One bobby pin, metal or plastic toy, nail or sharp object in a load can catch laundry and cause tears. Facial tissue left in a pocket will produce extreme “lint”.

  • Page 7: Loading The Washer

    W A R N I N G Do not wash or dry items soiled with vegetable or cooking oils. Some oils may remain after washing and may cause the fabric to catch on fire by itself. Loading the Washer NOTE: Always add detergent first. Load Articles ...

  • Page 8: Wash Temperature

    Wash Temperature Hot Water Hot water will give the best results of cleaning and sanitizing, but it is not suitable for all items. It is best for sturdy whites and colorfast items, heavily soiled items and diapers. Warm Water By using warm water, there is less chance of color loss in items.

  • Page 9: Determine Proper Cycle

    Operating Your Washer W A R N I N G To reduce the risk of fire, electric shock, serious injury or death to persons, read the Safety Information section before operating your washer. Determine Proper Cycle (Some cycles may not be included on your model) Regular Cycle Use for sturdy items, like play or work clothes, towels, T-shirts, etc.

  • Page 10: To Wash Clothes

    Fabric Selector Setting (on select models only) The fabric selector setting allows users to control the agitate and spin speeds. However, if certain cycles are selected, their speeds will override these settings. In the Permanent Press cycle the first spin will always be slow. In the Delicate and Hand Wash cycles, all speeds will be slow.
  • Page 11 3. Add clothes loosely into the washtub. TLW1996N 4. Close the lid. The washer will not agitate or spin with the lid open. TLW1997N W A R N I N G To reduce the risk of serious injury, do not by-pass the lid switch by permitting the washer to agitate or spin with the lid open.

  • Page 12: Manual Soaking

    7. Set Fabric Selector (on select models only). 8. Select Extra Rinse (on select models only) if desired. 9. Select the cycle according to the type of fabric being washed. Push the timer knob in and turn clockwise to the desired cycle and wash time.

  • Page 13: Fabric Softener Dispenser

    Optional Features Bleach Dispenser The bleach dispenser is located in the left front corner, under the lid. Use liquid bleach in the dispenser. Powdered bleach must not be used in the dispenser. Add powdered bleach to the wash water. Use no more than one cup chlorine bleach for large loads, three-quarters cup for medium and one-half cup for small loads.
  • Page 14 To Clean the Dispenser Remove the dispenser housing from agitator by squeezing the lower part of the dispenser, pulling directly upward and at the same time tilting slightly. This will expose the dispenser cup, which is also removable, for cleaning (refer to illustration). Both housing and cup can be soaked in hot soapy water and rinsed clean.

  • Page 15: Clothing Care

    Clothing Care Clothing Concerns To keep clothes looking white or bright, use good washing practices at all times to prevent a gradual Problem Gray or Dingy Insufficient Detergent Clothes Improper Sorting Nonphosphate Detergent and Hard Water Water Not Hot Enough Overcrowding Washer Yellowed Clothes Unremoved Soil...

  • Page 16: Maintenance

    Maintenance Cold Weather Care  If the washer is delivered on a cold day (below freezing), or is stored in an unheated room or area during the cold months, do not attempt to operate it until the washer has had a chance to warm up.

  • Page 17: Motor Overload Protector

    Reinstallation of Shipping Materials You must install the shipping brace and shipping plug any time the washer is moved. Shipping Brace  The shipping brace in the lid opening should be saved and reinstalled whenever the washer is moved. To reinstall the brace, open the washer lid and place the brace over the washer agitator, placing the back of the brace into the washtub first.

  • Page 18: Preventative Maintenance

    Preventative Maintenance Follow these guidelines to ensure the washer operates properly. Call for service if you observe any of the following: water of any amount on the floor, an increase in operating noise or water remaining in the washtub after a cycle. Frequency 1.

  • Page 19: Troubleshooting

    Troubleshooting Try these troubleshooting tips before making a service call. You may save time and money! Washer Symptom  Won’t Fill          Won’t Start       Won’t Agitate ...
  • Page 20 Washer Symptom  Water Leaks Check that fill hoses are properly installed on the faucets and the washer’ s water mixing valve.  Replace the fill hoses every five years.  Make sure drain receptacle is not clogged.  Check house plumbing. ...

  • Page 21: Contact Information

    If you are unable to locate an authorized service center or are unsatisfied with the service performed on your unit, contact: Speed Queen Shepard Street P.O. Box 990 Ripon, Wisconsin 54971-0990 www.speedqueen.com Phone: (920)748-3121...
