Daily Operating Components

Air Compressor Exterior
SRL-7.5M6LL/ML/LH/MH
SRL-11M6LL/ML/LH/MH
Air Exhaust
Compressed Air
Discharge Pipe
Power Cable Inlet
Air Intake
● Intake air and cooling
air is supplied to the air
compressor.
SRL-16.5M6LL/ML/LH/MH
Air Exhaust
Power Cable Inlet
Compressed Air
Discharge Pipe
Air Intake
● Intake air and cooling
air is supplied to the air
compressor.
● Do not leave the front door open during operation.
Failure to adhere to this precaution may cause dust to be ingested, excessive vibration and/or noise to be
generated and/or reduction in air compressor life due to excessive temperature rise.
CAUTION
2
Control Panel
Emergency Stop
Switch
Locks for door
enclosure with Keys
Front Door
● Make sure that front
door is closed during
the operation of the air
compressor.
Control Panel
Emergency Stop
Switch
Locks for door
enclosure with Keys
Front Door
● Make sure that front
door is closed during
the operation of the air
compressor.
