Speco VL-6WMTDV Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Vandal-Resistant Wall/Ceiling Mount Color Dome
Camera with Auto Iris Varifocal Lens

Features

Wall or ceiling mounting through the use
of a unique internal 3-way camera bracket . . . . . . . . . . . .Look straight down a wall with no loss of coverage
Safe Mount System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Keeps tools and hardware away from
Auto Iris Varifocal Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Camera operates in a wide range of
Supplied with a clear "lined" dome . . . . . . . . . . . . . . . . . . .Conceals camera position without a loss of light
Conduit compatible . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Side and rear cable entry
Vandal Resistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Withstands blows from a 10lb. sledge hammer
Tamper Resistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .The cover is secured by 6 tamper resistant screws

Specifications

Horizontal Resolution . . . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . . . . . . . . . .
Min. Object Illumination . . . . . . . . . . . . . . . . . .
Effective Picture Element . . . . . . . . . . . . . . . . . .
Backlight Compensation . . . . . . . . . . . . . . . . . .
White Balance . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . . . . . . . .
AGC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Built In Lens . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Auto Iris Lenses . . . . . . . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . . . . . . . . . . .
Weatherproof Standard . . . . . . . . . . . . . . . . . . .
Mechanical construction . . . . . . . . . . . . . . . . . .
Operating Environment . . . . . . . . . . . . . . . . . . .
Video Signal Output . . . . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VL-6WMTDV camera
Mounting hardware
Power supply
For more information contact us at:
VL-6WMTDV

Benefits

camera electronics
lighting conditions
420 TV lines
1/3" Interline transfer type CCD
1.0 lux
270K 512(H) x 492(V)
Active
Auto
1/60-1/100,000 seconds
Active-Auto
Auto iris varifocal lens 4-9mm, F1.6
4-12mm, 2.6-6mm varifocal
Greater than 48db
IP66
Aluminum composite/polycarbonate
-20˚F to 120˚F
1.0Vp-p/75 ohms (BNC) NTSC
150mA
12V DC 500 mA regulated power supply
(UL & CSA listing) included
24 ounces

Package Includes:

Instructions
Warranty
