Speco VL-648IR Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Indoor Dome Camera w/Built-In IR
LEDs and Anti-Reflection Technology
VL-648IR
3.6mm lens
(optional lenses available)
The VL-648IR is a color day/night camera with special shielding to eliminate IR reflections.
It is used for indoor ceiling applications to cover the full spectrum of bright light to no
light surveillance. This dome camera can be wall or ceiling mounted by using the matching
bracket that is included in the box.

Specifications

Resolution . . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . .
Synchronization . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . . .
Back Light Compensation
AGC . . . . . . . . . . . . . . . . . . . . . . .
Gamma Characteristic . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . .
LED IR Wave Length . . . . . . . . . . . . .
Number of LED . . . . . . . . . . . . . . . .
Effective IR range . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . .
Dimension . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . .
Case . . . . . . . . . . . . . . . . . . . . . .
*Super HAD is a trademark of the Sony Corporation
VL-648IR or VL-648IRVF Camera
Warranty card
For more information contact us at:

Features

420 lines
1/3" Sony Super HAD* color CCD
0 lux with IR on, 1.0 lux with IR off
Auto 1/60-1/100,000 sec.
3.6mm lens (optional lenses available)
Varifocal version only - 4-9mm auto iris
Internal 2:1
EIA standard 525 line 60 fields/second
Greater than 48 db
. . . . . . . . . Auto
Auto
0.45 typ.
1.0 Vp-p, 75 ohm
14˚F to 120˚F
850 NM
22 IR LEDs
60' (depending on scene reflection)
12V DC regulated - included UL approved
5" Diameter x 3"H
8 oz.
High impact ABS

Package Includes:

VL-648IRVF
Comes with 4-9mm
auto iris varifocal lens
Instructions
Power Supply
