Speco VL-611C Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
1/3" Color CCD Camera
VL-611C
• General purpose color 1/3" format camera
• 0.5 lux low light sensitivity
• 420 TV lines of horizontal resolution

Specifications

Pick Up Device . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . .
Effective Pixels . . . . . . . . . . . . . . .
Sync Type . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . .
Min. Illumination . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . .
Gamma Correction . . . . . . . . . . . .
Horizontal Frequency . . . . . . . . . .
Vertical Frequency . . . . . . . . . . . .
Backlight Compensation
Power Supply . . . . . . . . . . . . . . . .
Consumption Current . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . .
Operating Temperature
For more information contact us at:
Features
• Auto electronic shutter and auto iris support
• Accepts C & Cs mount lenses
• Compact and lightweight
1/3" interline transfer CCD
420 TV lines
Video Auto Iris / DC Auto Iris / Manual Iris / Fixed Iris
510 (H) x 492 (V)
Internal
NTSC 525 lines / 60 fields / 30 frames
Composite 1.0 Vp-p / 75 ohm
0.5 lux
More than 50dB
Auto 1/60 to 1/100,000 sec.
0.45 / 1 (set to 0.45 before shipment)
NTSC: 15.734 KHz
NTSC: 60 Hz
. . . . . . . . . On
12V DC Regulated required
Max. 200mA
N.W./G.W.: 12 oz. / 17 oz.
4.3" L x 2.2" W x 2" H
. . . . . . . . . -14˚F to 122˚F
(lens not included)
