Speco VL-265PIR Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
VL-265PIR & VL-272PIR
B/W Camera in Non-Operating
and Operating PIR Housing
Our 1/3" B/W CCD camera is encased in a white PIR housing. It has a .5 lux
sensitivity with 420 line resolution. It features a 3.6mm wide angle pinhole lens
and built-in electronic shutter. A 12V DC power supply is included. A color
version of this camera can be found under model number VL-565PIR
and VL-572PIR (with working PIR). A fully adjustable wall/ceiling mount is
included with this unit.

Specifications

V L - 2 6 5 P I R
Re s o l u t i o n 420 lines
M i n i mum Illumination .5 lux
I m a ge Dev i c e 1/3" CCD image sensor
E l e c t ronic Shu t t e r Auto 1/60 - 1/100,000 seconds
L e n s 3.6mm Hor. 7 4 ˚ , Ve rt . 5 7 ˚
O p e rating Te m p e ra t u re 14º F to 122º F
O u t p u t Video - BNC, p owe r- DC jack
Power Co n s u m p t i o n 120 ma
Scanning Fre q u e n cy H o ri zontal 15.75 kHz ve rtical 60 Hz
Video Output Leve l 1.0 V p - p, 75 ohm
Video S/N Ratio G reater than 46 dB
H o u s i n g White ABS plastic
with mount
Power Supply Regulated 12V DC power supply
included (UL and CSA listed)
D i m e n s i o n s 2"L x 2.75"W x 4.75"H
* N o t e : The PIR electronics in the VL-572PIR and VL-272PIR (wo rking PIRs) are for local indication and activation of
re c o rding devices only. Do not connect these devices to alarm systems that will re p o rt to local police or a central station.
For more information contact us at:
VL-272PIR (with working PIR)
420 lines
.5 lux
1 / 3 " CCD image sensor
Auto 1/60-1/100,000 seconds
3.6mm Hor. 7 4 ˚ , Ve rt . 5 7 ˚
14˚F to 122˚F
Video - BNC, p owe r- DC jack
130 ma
H o ri zontal 15.75 kHz ve rtical 60 Hz
1.0 V p - p, 75 ohm
G reater than 46 dB
White ABS plastic with working
PIR and mount
Regulated 12V DC power supply
included (UL and CSA listed)
2"L x 2.75"W x 4.75"H
