Speco CVC-880EX Specification Sheet

* ExView is a trademark of Sony Corporation
Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
H.E.A.T Color Camera w/ ExView Technology*
& Dual Voltage Operation
CVC-880EX
This color camera offers a 470 line resolution with a 0.075 lux, and ExView
Technology*. Additional features include back light compensation, auto electronic
shutter, automatic gain control, automatic light compensation and internal line
lock/phase adjustable in 24V AC mode. The camera accepts video and DC drive
auto iris lenses. It requires either a 12V DC or 24V AC power supply.
The lens is sold separately.

Specifications

Resolution
Image Device
Scanning Frequency
Video Output
Video S/N Ratio
Adjustable Phase
Electronic Shutter
Humidity
Internal Line
Lock/Adjustable Phase
Lens
Minimum Illumination
Operating Temperature
Output
Power Consumption
Power Supply
Dimensions
Weight
For more information contact us at:
Features
Ultra high 470 line
1/3 inch color ExView* CCD
15.75 kHz horizontal 60 Hz vertical
1.0 Vp-p 75 ohms
Greater than 50 dB
In 24V AC mode
Auto 1/60 - 1/100,000 seconds
Within 95 % RH
24V AC mode
Accepts C/CS mount lenses
- auto iris & manual iris (sold separately)
0.075
14 degrees F to 122 degrees F
Video - BNC
130 mA
Re q u i res 12V DC or 24V AC power supply
(not included)
5.75"L x 2.5"W x 2.1"H
1.0 lb.
