Speco CVC-812PC Installation & Operation Instructions

CVC-812PC COLOR DOOR MOUNT CAMERA
Installation & Operation Instructions
Please review these instructions carefully before installation and operation.
FEATURES :
* Weatherproof Operation
* High Resolution
* Electronic iris allows for application with varying lighting conditions
* Good low light sensitivity
* Maintenenance Free
Installation :
Bezel(A)
Fixing Ring (C)
1. Place bezel(A) on the camera and then put the camera through the door.
2. Place bezel(B) on the camera.
3. Tighten the camera to the door using the two fixing rings (C).
Specifications
Image Device
Horizontal Resolution
Scanning System
Built-In Lens
Synchronization
Output Signal
Minimum Illumination
Shutter Control
Power Supply
Weight
Housing
Cable Length
Always use discretion when installing video and/or audio surveillance equipment especially
when there is perceived privacy, or and expectation of privacy. Inquire regarding federal,
state and/or local regulations applicable to the lawful installation of video and/or audio
recording or surveillance equipment. Party consent may be required.
Bezel(B)
CVC - 812PC
1/3" Interline CCD
350 TV Lines
2 : 1 Interlace
Standard 2.5mm Wide Angle
Internal
1Vp-p Composite Video, 75 ohms
1.0 Lux
Auto, 1/60 ~100,000
12V DC, 500mA (Regulated)
3.6oz(126g)
Metal / Black Color
40 Inches
VIDEO OUTPUT
POWER INPUT
+
DIMENSIONS:
7
1
"
8
5
1
"
8
3
"
2
4
200 NEW HIGHWAY
AMITYVILLE, N.Y. 11701-0726
631-957-8700 1-800-645-5516
1
"
1
8
(28mm)
