Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Day/Night Waterproof Marine Camera
Great for Marine Applications
CVC-627M
Supplied with Stainless Steel Mount
Features
Day/Night Operation. . . . . . . . . . . . . . . . . . . . . . . . . 12 built-in IR LEDs controlled by a CDS sensor
Weatherproof/Waterproof . . . . . . . . . . . . . . . . . . . . Can withstand full immersion in water and
Attractive Housing . . . . . . . . . . . . . . . . . . . . . . . . . . White to blend in with your surroundings
Stainless Steel White Mount & Screws . . . . . . . . . Will not rust
Specifications
Horizontal Resolution
. . . . . . . . . . .
Min Illumination
. . . . . . . . . . . . . .
Camera Type
. . . . . . . . . . . . . . . . .
Image Sensor
. . . . . . . . . . . . . . . . .
Lens
. . . . . . . . . . . . . . . . . . . . . .
Iris
. . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter Speed
Effective Pixels
. . . . . . . . . . . . . . . .
TV Standard
. . . . . . . . . . . . . . . . .
Sync Type
. . . . . . . . . . . . . . . . . . .
Scanning System
. . . . . . . . . . . . . .
Video Output
. . . . . . . . . . . . . . . .
Gamma Characteristics
. . . . . . . . . .
S/N Ratio
. . . . . . . . . . . . . . . . . . .
Gain Control
. . . . . . . . . . . . . . . . .
Back Lighting
. . . . . . . . . . . . . . . . .
Operating Temperature
. . . . . . . . . .
IR LED
. . . . . . . . . . . . . . . . . . . . .
Construction
. . . . . . . . . . . . . . . . .
Current Consumption
. . . . . . . . . . .
Power Requirements
. . . . . . . . . . . .
Mount
. . . . . . . . . . . . . . . . . . . . .
Dimensions
. . . . . . . . . . . . . . . . . .
Weight
. . . . . . . . . . . . . . . . . . . .
Cable
. . . . . . . . . . . . . . . . . . . . .
*Depending on scene reflection
Also available: CVC-627MR
For more information contact us at:
Benefits
allow this color camera to see a perfect b/w
picture in the dark at distances up to 45'*
stand up to any type of weather
420 Lines
1 lux (LED off), 0 lux (LED on)
Waterproof color day/night
1/4" Color CCD
2.9mm
Electronic shutter
. . . . . . . . .
1/60 to 1/100,000 second
510 (H) x 492 (V) pixels
NTSC
Internal
2:1 Interlace
1 Volt P-P into 75 ohms
0.45 typ.
48 dB
Automatic
Automatic
-14˚F to 120˚F
12 IR LEDs controlled by CDS sensor, 45' range*
Waterproof, brass - painted white, removable/adjustable
sunshield, stainless steel screws and mount
150 mA (LED off), 330 mA (LED on)
12V DC regulated power supply @ 500mA
Universal wall/ceiling mount included (stainless steel)
2.75" Dia. x 3.65" L
12.5 oz.
10' of power/video cable
(Reverse image camera for help in backing up)
Compatible
with all plotters
that accept
composite
video inputs.
plotter not included
