Speco CVC-57PH/HR Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Black & White Pinhole Board Camera
with Housing and Mounting Bracket
CVC-57PH/HR
Our high performance 1/3" black & white pinhole camera has a 0.5 lux sensitivity with a
420 line resolution. It features a 3.6mm conical pinhole lens with built-in electronic iris
and uses a BNC video output with DC power jack. A color version is available under model
number CVC-770PH.

Specifications

Resolution . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . .
Number of Pixels . . . . . . . . . . . . .
Operating Temperature
Humidity . . . . . . . . . . . . . . . . . .
Output Connections . . . . . . . . . . .
Scanning System . . . . . . . . . . . . .
Video Output Level . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . .
Synchronization System
Power Requirements . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . .
Suggested Power Supply
For more information contact us at:
Features
420 lines
1/3" CCD sensor
0.5 lux
3.6mm conical pinhole
Auto 1/60 second to 1/100,000 second
512 H x 492 V picture elements
. . . . . . . . . 14°F to 122°F
Within 95% RH
Video-BNC, Power DC jack
EIA standard 525 TV lines 60 fields/sec.
1.0 Vp-p, 75 ohms composite, BNC connector
Greater than 48dB
. . . . . . . . . Internal
12 Volts DC @ 130mA
1 3/8" x 1 3/8"
1.1 oz.
. . . . . . . . . Speco Technologies PSW-2 or PSW-5
