Speco D16RS User Manual

4, 8, 16 channel digital video recorder
Hide thumbs Also See for D16RS:
Table of Contents

Advertisement

Quick Links

See also: Quick User Manual
User Guide
(Ver. 2.4)
Model: D4RS, D8RS, D16RS, D4WRS, D8WRS, D16WRS

4, 8, 16 Channel Digital Video Recorder

About This User's Guide
Before operating the unit, please read this user‟s guide thoroughly and retain it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D16RS and is the answer not in the manual?

Questions and answers

Related Manuals for Speco D16RS

Summary of Contents for Speco D16RS

  • Page 1: Channel Digital Video Recorder

    User Guide (Ver. 2.4) Model: D4RS, D8RS, D16RS, D4WRS, D8WRS, D16WRS 4, 8, 16 Channel Digital Video Recorder About This User’s Guide Before operating the unit, please read this user‟s guide thoroughly and retain it for future reference.

  • Page 2: Explanation Of Graphical Symbols

    Cautions Explanation of Graphical Symbols This symbol indicates the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. This symbol indicates the presence of “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock, property damage, personal injury, or death.

  • Page 3: These Precautions Must Be Followed For Safety Reasons

    These Precautions must be Followed for Safety Reasons Warning  Do not use if the unit emits smoke.  Do not disassemble the unit.  Do not place any heavy or sharp objects on the unit.  Do not place on uneven surface. ...

  • Page 4: Product Components

    DVR Unit (D4WRS/D8WRS/D16WRS or D4RS/D8RS/D16RS) Remote Control Battery1.5V (AAA x 2EA) Quick Start Guide Mouse for D4RS/D8RS/D16RS Software & Manual CD Adaptor (DC12V 3A for D4RS/D4WRS, DC12V 5A for D8RS/D16RS/ D8WRS/D16WRS) & Power cable (110V or 220V) Audio Cable for D8RS/D16RS/D8WRS/D16WRS...

  • Page 5: Specifications

    10 seconds to 3 minutes after an event 1, 4, 8 ×2, 4, 8, 16, 32, 64 ×2, 4, 8, 16 Timeline, Event, Archive, Log Serial ATA D4RS/D4WRS: Max. 1 TB D8RS/D8WRS/D16RS/D16WRS: Max. 2 TB NaFS 16RS/D16WRS 1 BNC 1 BNC 120fps 240fps...
  • Page 6 USB Port Backup Menu Display User I/F Input Method RS-485 PTZ control Dynamic DNS Network Interface Network Dual Encoding for Network Streaming Web Viewer (1:1) Network Mobile View Software (1:1) Access Multi-sites Monitoring System DLS (Day Light Saving) EZRecord S.M.A.R.T Internal Beep Features Multi-Language...

  • Page 7: Table Of Contents

    Table of Contents Main Features ... 10 Initial Boot up Process ... 11 2-1. Initial Boot up and Basic Time Setup ... 11 2-2. Setting Daylight Saving Time ... 12 2-3. Setting NTP (Network Time Protocol) ... 13 Name, Function and Connection ... 16 3-1.
  • Page 8 5-3-7. Log List ... 50 5-4. Play Mode ... 51 6. Back Up ... 52 6-1. Still Image Backup onto USB Flash Drive ... 52 6-2. Video Backup onto USB Flash Drive ... 52 6-3. Transferring Still Images or Video from the ARCHIVE List ... 54 6-4.
  • Page 9 10-2. App Viewer for Android Phone ... 86 APPENDIX: Network Connection - LAN ... 88 APPENDIX: Network Connection – Internet and DDNS ... 90 APPENDIX: E-SATA CONNECTION ... 94...

  • Page 10: Main Features

    1. Main Features  H.264 Video Compression  Reliable File System  4 Channel Audio Recording NOTE: Under federal law, The Fourth Amendment to the U.S. Constitution, Title III of the Omnibus Crime Control and Safe Streets Act of 1968, as amended by the Electronic Communications Privacy Act of 1986 (18 ...

  • Page 11: Initial Boot Up Process

    2. Initial Boot up Process 2-1. Initial Boot up and Basic Time Setup 1. During the first boot up, the following logo and message will be displayed. 2. After the system initializing is completed, select the language and set date and time as specified below.

  • Page 12: Setting Daylight Saving Time

    2-2. Setting Daylight Saving Time To enable Daylight Saving feature/NTP synchronization, take the following steps. 1. Enter the SETUP mode. The default Username is “ADMIN” and Password is “1111”. 2. Go to SETUP > SYSTEM > DATE & TIME SETUP...

  • Page 13: Setting Ntp (Network Time Protocol)

    3. Select ON from the DAYLIGHT SAVING dropdown menu. 2-3. Setting NTP (Network Time Protocol) 1. SETUP > SYSTEM > NTP SETUP > ON 2. Select the proper TIME ZONE time. Alaska (Aleutian Islands) Arizona (Navajo) Table2.3.1. GMT Time Zone State Standard Time Alabama...
  • Page 14 Arkansas California Colorado Connecticut District of Columbia Delaware Florida Florida (W) Georgia Hawaii Idaho (N) Idaho (S) Illinois Indiana Indiana (SW / NW) Iowa Kansas Kansas (W) Kentucky (E) Kentucky (W) Louisiana Maine Maryland Massachusetts Michigan Michigan (W) Minnesota Mississippi Missouri Montana Nebraska...
  • Page 15 Ohio Oklahoma Oregon Oregon (E) Pennsylvania Rhode Island South Carolina South Dakota (E) South Dakota (W) Tennessee (E) Tennessee (W) Texas Texas (W) Utah Vermont Virginia Washington West Virginia Wisconsin Wyoming NOTE: If you want the unit to automatically synchronize the local time, the Time Zone must be properly set according to your local time zone.

  • Page 16: Name, Function And Connection

    3. Name, Function and Connection 3-1. Front Panel Name POWER LED light is on when power is applied to the system. LED light is on when the system is recording video data. This USB port for archiving footage into a USB device. (USB 2.0 connector) USB Port 3-2.
  • Page 17 D8RS, D16RS: CVBS1 – Composite Video Output / CVBS2 – Spot Monitor ③ VGA: VGA (Video Graphics Array) output port. Connects to the PC VGA monitor. ④ RS-232C (for D8RS/D16RS/D8WRS/D16WRS only): For engineering use only, the function is used by a gender through the VGA output.

  • Page 18: Remote Control

    3-3. Remote Control ① ID: To set the remote control ID. ② REC: To start and stop manual recording ③ 0~9: To select channel (1,2,3,..) or to enter a DVR ID number or use as number key. ④ F/REW:  During playback – To move the playback position 60seconds back. ...

  • Page 19: Setting Up The Dvr

    4. Setting up the DVR The following sections detail the initial setup of the DVR. Menu screen will close if user input is not received in 5 minutes. 4-1. Setup – Main Live Screen To enter the setup menu, right click on the mouse and select setup from the submenu or press the setup button on the remote control.

  • Page 20: Setup - System Mode

    4-2. Setup – SYSTEM Mode In the SETUP menu, select the SYSTEM tab. Then, the SYSTEM menu is displayed as pictured below. Navigate through the menu items using the mouse or the remote control and change the value of the menu item.
  • Page 21 DATE DISPLAY Select the date display format using the mouse or the control button on the remote FORMAT control. Options are: MM/DD/YYYY, YYYY/MM/DD, DD/MM/YYYY, YYYY-MM-DD, MM- DD-YYYY, DD-MM-YYYY DATE&TIME Select the display date and time using the mouse or the control button on the remote SETUP control and press OK button to set the present date and time.

  • Page 22: Send Email

    MAIL BY MOTION: Enable/disable sending e-mail when the motion is detected. MAIL BY SENSOR: Enable/disable sending e-mail when sensor input is received (Only applies to D8RS, D16RS models) MAIL BY VIDEO LOSS: Enable/disable sending e-mail when the video loss is detected.

  • Page 23: Setup - Record Mode

    ID: Enter the appropriate mail server ID. PASSWORD: Enter the appropriate mail server PASSWORD. MAIL FROM: To set the email address sent to the destination host. UNIT NAME Name the DVR (e.g. Factory) This feature is to identify the name of the DVR under the same network. 4-3.

  • Page 24: Frame Rate

    Select D1, Half D1 or CIF using the mouse or the control button on the RESOLUTION remote control. FRAME RATE Set the frame rate for the specified channel. The sum of the frame rate values from each channel cannot exceed the maximum frame rates for a specific recording resolution.

  • Page 25: Recording Schedules

    4-3-1. Recording Schedules To setup a recording schedule, select SCHEDULE in the RECORD menu. Navigate through the items using the mouse or the control button. Select CHANNEL > select NONE, CONTINUOUS or MOTION > HIGHLIGHT AREA To copy a schedule to a different channel, select the channel from the COPY SCHEDULE menu. Figure 4.3.2.

  • Page 26: Setup - Device Mode

    (D4RS does not support CONTROLLER & PTZ.) D4RS/D4WRS: CVBS OUT is switchable as Composite Video Output or Spot-Out according to the resolution of VIDEO OUTPUT (VGA). D8RS/D16RS/D8WRS/D16WRS: CVBS1 – Composite Video Output / CVBS2 – Spot-Out. Select specified channel for motion zone setup.
  • Page 27 SENSITIVITY KEY TONE REMOTE CONTROL ID SENSOR 4-4-1. Alarm-Out Table 4.4.2. Item for ALARM-OUT Setup Screen Item ALARM OUT SENSOR IN MOTION ON VIDEO LOSS ON ALARM DURATION ERROR ALARM Control the motion sensitivity from 1 to 9. (9 – Highest sensitivity, 1 – Lowest sensitivity) Enable/disable key tone.

  • Page 28: Keyboard Controller & Ptz Setup

    4-4-2. Keyboard Controller & PTZ Setup To control the PTZ functions of the camera, connect the PTZ controller to the RS-485 port on the back of the chassis with CAT5 (or equivalent) cable. ① Connect the RS-485 cables of PTZ camera to the RS-485 port on the rear panel. [D4WRS] ②...

  • Page 29: Spot Out

    Note: Connect PTZ cameras that support RS-485 directly to the RS-485 port. If the camera is controlled through an RS-232C interface, use an RS-232C to RS-485 to RS-232C signal converter. Use the PTZ setup screen to select the following options for the camera PTZ controller: CHANNEL: Channel connected to a PTZ device CAMERA: Protocol Type SPEED: 19200, 14400, 9600, 4800, 2400 (Baud rate)

  • Page 30: Motion Zone Setup

    4-4-4. Motion Zone Setup Select MOTION ZONE using the mouse or the control button on the remote control and select either PARTIAL ZONE or FULL ZONE using the mouse control. The default value is FULL ZONE. If FULL ZONE is selected, the motion zone grid screen is not displayed. Only set the level of sensitivity for MOTION SENSITIVITY.

  • Page 31: Setup - Display Mode

    4-5. Setup – DISPLAY Mode In the SETUP menu, select the DISPLAY tab. Then, the DISPLAY menu is displayed as pictured below. Navigate through the menu items using the mouse or the control button on the remote control and change the value of the menu item.

  • Page 32: Video Output

    D4RS/D4WRS (VGA) When VGA REOSLUTION is set at 1024 x 768, When VGA RESOLUTION is set as 1280 x1024, D8RS/D16RS/D8WRS/D16WRS CVBS1: Composite Video Output CVBS2: Spot-Out port 4-6. Setup – NETWORK Mode Select the NETWORK tab. Then, the network menu is displayed as pictured below. Navigate through the menu items using the mouse or the control button on the remote control and change the value of the menu.

  • Page 33: Network Types

    Table 4.6.1. Menu Items in NETWORK Setup Screen Item NETWORK TYPE SUBNET MASK GATEWAY DNS (PRIMARY) DNS (SECONDARY) DDNS NETWORK PORT WEB PORT NETWORK STREAM 4-6-1. Network Types 4-6-1-1. DHCP An IP address is automatically assigned by the DHCP server, which automatically assigns the IP address and other parameters to new devices.

  • Page 34: Network Stream

    User can set the RESOLUTION, FRAME RATE, and the QUALITY for the network stream. D4RS: Up to 60 fps @CIF for 4 channels. D8RS, D16RS: Up to 120 fps @CIF for 8 channels & 16 channels. <Note> Individual Channels can be set with different RESOLUTION, FRAME RATE, and QUALITY.

  • Page 35: Setup - User Management Mode

    4-7. Setup – USER MANAGEMENT Mode In the SETUP menu, select the USER MANAGEMENT tab. Then, the USER MANAGEMENT menu is displayed as pictured below. Navigate through the menu items using the mouse or the control button on the remote control and change the value of the menu item. Figure 4.7.1.
  • Page 36 ADMIN, USER1, USER2, USER3: Selected Checkbox: The user can access the function. Blank Checkbox: The user can not access the function. PASSWORD Options are ADMIN, USER1, USER2 and USER3. Select USER PASSWORD using the mouse or the control button on the remote control SETUP and press SEL button.

  • Page 37: Setup - Storage Mode

    4-8. Setup – STORAGE Mode In the SETUP menu, select the STORAGE tab. Then, the STORAGE menu is displayed as pictured below. Navigate through the menu items using the mouse or the control button on the remote control and change the value of the menu item.
  • Page 38 DISK INFO Hard drive information. Displays the following information; RECORDING Enable/disable recording limit. LIMIT RECORDING Set the recording limit days. (1- 90 days) If the RECORDING LIMIT DAYS are set to 1, the data will be overwritten after 24 LIMIT DAYS hours.

  • Page 39: Setup - Config Mode

    4-9. Setup - CONFIG Mode In the SETUP menu, select the CONFIG tab. Then, the configuration menu is displayed as pictured below. Navigate through the menu items using the mouse or the control button on the remote control and change the value of the menu item.
  • Page 40 LOAD Press the button to reset the system to the default settings. DEFAULT The following settings such as Language, DVR ID, Security User Authentication, Security User P/W, Date format, DLS settings, Network settings, HDD overwrite, Limit recording, HDD serial number, and HDD ERROR time will not be included.

  • Page 41: Firmware Upgrade

    1. Create a new folder named “upgrade” in the USB flash drive root directory. 2. Create sub-folder for each model under “upgrade” folder and copy each firmware.  D4RS: “main_D4RS_speco_*.*.*_201****”  D8RS: “main_D8RS_speco_*.*.*_201****”  D16RS: “main_D16RS_speco_*.*.*_201****”  D4WRS: “main_D4WRS_speco_*.*.*_201****”  D8WRS: “main_D8WRS_speco_*.*.*_201****”  D16WRS: “main_D16WRS_speco_*.*.*_201****”...
  • Page 42 Figure 4.9.3 Figure 4.9.4 NOTICE If selecting REBOOT LATER, the upgraded software will not be applied until the system reboots. If selecting REBOOT NOW when the USB flash drive is plugged, the following message will pop up. Remove the USB flash drive and select OK.

  • Page 43: Live, Search And Playback

    5. Live, Search and Playback 5-1. Live View In the Live screen, video inputs from the cameras are displayed as they are configured in the Display Setup screen. Various On-Screen Display (OSD) symbols, which indicate the status of the DVR, are described in Table 5.1.1.
  • Page 44 Record button on the front panel. Motion alarm recording in progress. Sensor recording in progress. (Only for D8RS and D16RS model.) Right click the mouse, and the quick operation window will be displayed as below. Figure 5.1.2. Quick Operation Window...
  • Page 45 Table 5.1.2. Menu Items in Quick Operation Window Icon SETUP Setup button. Click this button to go to a setup menu. AUDIO Audio button. Click this button to set an audio reception type; (Channel 1 through 4, Audio Mute). SEARCH Search button.

  • Page 46: Ptz Control

    5-1-1. PTZ Control Table 5.1.3. Menu Items in PTZ Control Window Item Description INITIALIZE Initialize the PTZ settings of the selected camera Select PAN/TILT using the ▲▼◀ and ▶button, PAN/TILT then press SEL. Adjust the tilt (UP/DOWN)/pan (LEFT/RIGHT) position using the ▲▼◀and ▶ buttons.

  • Page 47: Digital Zoom In Live And Playback Screen

    5-2. Digital Zoom in Live and Playback Screen RS series supports Digital Zoom feature during live and playback mode. 1. Double click the target channel. 2. Click the left button of the mouse and drag to make rectangular shape. 5-3. SEARCH Screen To enter the search screen menu, select SEARCH menu on the screen using the mouse or press SEARCH icon on live screen.

  • Page 48: Time Line Search

    5-3-1. Time Line Search The CALENDAR Search window is used to find the stored video by using the time line bar. Figure 5.3.2. Calendar Screen Figure 5.3.3. Time-Line Search Screen When the Timeline menu is selected, the user can see a calendar, which displays recorded dates with highlights.

  • Page 49: Event Search

    5-3-2. Event Search The Event Search window is used to find stored video. When the Event menu is selected, the user can see a calendar, which has recorded data. Select a specific date and the event log will be displayed. Press the PLAY button to playback the data or the SAVE button to save the data after selecting the specific data.

  • Page 50: Archive List

    SPECIFIC TIME menu. Use the mouse or the control button on the remote control to change the date and time value and press the PLAY button after setting. If there is no video data in the set date and time, No Data Exist message displays.

  • Page 51: Play Mode

    Table 5.4.1. Button Functions in PLAY Mode Description 1x, 2x, 4x, 8x,16x, 32x speeds for D4RS/D4WRS 1x, 2x, 4x, 8x,16x for D8RS/D8WRS 1x, 2x, 4x, 8x for D16RS/D16WRS 2x, 4x, 8x,16x, 32x speeds for D4RS/D4WRS 2x, 4x, 8x,16x for D8RS/D8WRS 2x, 4x, 8x for D16RS/D16WRS...

  • Page 52: Back Up

    6. Back Up 6-1. Still Image Backup onto USB Flash Drive Still images can be captured and archived onto a USB flash drive or an external hard drive in live mode or while playing back recorded video. In the live mode, press the BACKUP button to launch the archive function or select BACK UP menu on the screen using the mouse.
  • Page 53 3. Select USB STICK (Flash Drive) to back up less than an hour. Select USB HDD (Huge Backup) to back up from 1 hour to 24 hours. 4. Once you select the channel and duration, the system will start to archive the data to the USB flash drive.

  • Page 54: Transferring Still Images Or Video From The Archive List

    7. The following shows the image to complete the backup. Select lose to return to the previous screen. 6-3. Transferring Still Images or Video from the ARCHIVE List The stored data in the hard drive can be found in the ARCHIVE list in the SEARCH window. User can back up still images or video into the storage device from the ARCHIVE list.

  • Page 55: Playback Of Backup Video

    6-4. Playback of Backup Video  AVI format: AVI format video can be played back by Window Media Player™ or other media player that is compatible with AVI format video.  NSF format: NSF format video can be played back using the player that the DVR copies on USB flash drive with video.

  • Page 56: Network Access Using The Multi-Sites Network Viewer

    7. Network Access Using the Multi-Sites Network Viewer 7-1. Overview The SpecoTech Multi Client is a multiple site monitoring client software with; video, audio, and alarm signals from the DVRs over networks. The SpecoTech Multi Client does not limit the number of DVR units to register.

  • Page 57: Installation Of The Program

    7-3. Installation of the Program 1. Insert the provided CD in the CD drive and double-click “SpecoTech Multi Client (XXXX).exe” 2. Select a destination folder and click “Next”. 3. Select the program folder and click “Next”. 4. The installation status screen is displayed. 5.

  • Page 58: Live Window

    7-4. Live Window When installation is completed, double click the “SpecoTech Multi Client” icon on your desktop to start the program. 7-4-1. Main User Interface 7-4-2. Control Buttons Button LOCAL PLAYBACK REMOTE PLAYBACK Description Click this icon to run a playback window to search and play videos that are recorded in the local PC.
  • Page 59 SITE MANAGEMENT CONNECT DISCONNECT SETUP CAPTURE EVENT LIST PAUSE ALARM ON RECORD ON AUDIO PRESET/TOUR/SCAN/MENU CHANNEL SPLIT DVR SITE SPLIT THUMBNAIL REFRESH: Click this icon to refresh and renew thumbnail image of the connected sites. SITE ADDITION: Click this icon to open „Site Addition‟ window. SITE DELETE: Click this icon to delete site from the index window, after disconnect a site.

  • Page 60: Search And Playback Window

    7-5. Search and Playback Window 7-5-1. Main User Interface You can access to search window by clicking the search icon (Local Playback / Remote Playback) on the upper right of the Live Window. 7-5-2. Main Control Panel Button LOCAL PLAYBACK REMOTE PLAYBACK Description Click this icon to run a playback window to search and play videos that...
  • Page 61 CONNECT DISCONNECT SETUP CAPTURE EVENT LIST MARK IN MARK OUT BACKUP AUDIO Click this icon to connect the selected site/sites. Click this icon to disconnect the selected site/sites. Click this icon to setup configuration of SpecoTech Multi Client. Click this icon to capture a still image. Opens list of events logged by the UMS Multi Client.

  • Page 62: Setup Of Specotech Multi Client

    7-6. Setup of SpecoTech Multi Client Click the setup icon window is displayed as below. 7-6-1. General Security Option: Set a password for security options. Select security options and set a password. Then when you access any of selected functions, you need to enter the password. You can also set the save path for capturing and backup Save Path: Specify the location to save captured still image for Capture and Backup data.

  • Page 63: Event

    7-6-2. Event Event log can be archived and searched. Event Log: Specify the location to save event logs and select event to archive. Event Search: Event log can be searched from the selected time.

  • Page 64: Record

    7-6-3. Record Record Setup: You can set the recording conditions as the following; Always, Event, or Auto record. And you can also select target DVR/DVRs and channel/channels. When you set the recording condition to event, you can set event for motion or alarm with duration. Record Local Storage Setup: You can select the local disk to record and the amount of disk space you want to allow the program to use for recording.

  • Page 65: Display

    7-6-4. Display You can select the OSD (On Screen Display) to be displayed. 7-6-5. About “About” provides network client version information.

  • Page 66: Remote Setup

    7-7. Remote Setup The menu settings for the DVR unit can be set over network. Put the cursor of the mouse on the channel, which is connected to the site and right click on the mouse to open the submenu. Then the following window is displayed as below. Select the REMOTE SETUP. Then the setup window is displayed.

  • Page 67: System

    7-7-1. System Select System to set system and time settings. 1. Date Display Format: YYYY/MM/DD, MM/DD/YYYY, DD/MM/YYYY, YYYY-MM-DD, MM-DD-YYYY, DD-MM-YYYY 2. Client Access: Enable/Disable remote access through network client software. 3. NTP: Sets whether to synchronize the time using NTP server or not. - Primary SNTP Server: Input the NTP primary server address.

  • Page 68: Record

    7-7-2. Record Select RECORD tab to set the recording conditions. These settings apply to the specified channel only. 1. Recording Setup - Resolution: Sets the resolution for the recordings. The set value applies to an individual channel. - Frame Rate: Sets the recording rate. - Quality: Sets the image quality in 5 levels.

  • Page 69: Device

    7-7-3. Device Select Device to set Spot Out, Enable/Disable CVBS Out, motion zone. 1. Motion: Setup the motion detection area and the sensitivity. - SITE: Select the channel - MOTION ZONE: FULL Zone or PARTIAL Zone - Motion Sensitivity: 1~9 (High sensitivity level) 2.

  • Page 70: Display

    7-7-4. Display Select the DISPLAY tab to set the DISPLAY conditions. These settings apply to all channels. 1. OSD: Sets whether to display or not date and time as well as channel number on the screen. 2. OSD Contrast: Adjust the character contrast on the screen. 3.

  • Page 71: Network

    7-7-5. Network 1. Network Type - STATIC: The address setting mode is manual. Input IP, Gateway, Subnet Mask, and DNS server IP. - DHCP: The address setting mode is automatic. Addresses and other information do not need to be set. 2.

  • Page 72: Storage

    7-7-6. Storage Select Storage to configure continued recording settings by overwriting the hard disk and the storage period for the recording data. 1. Overwrite: To continue recording by overwriting when the hard disk becomes full, check the checkbox. 2. Record Limit: Sets whether to limit or not the recording data storage period. - Record Limit Days: Sets a recording data storage period.

  • Page 73: Operation

    7-8. Operation 7-8-1. Addition, Delete, and Modify of DVR Sites 7-8-1-1. Addition of Sites 1. Click SITE ADDITION button. And then the following window will be displayed as below. o Site Name: Input a name that properly describes a site. o IP Address: Input IP address (Public IP address of a router that DVR is connected.) or Domain name o Port Number: Default Port Number is “5445”.
  • Page 74 7-8-1-3. Modify of Sites 1. Select the site/sites to modify from the directory window. 2. Click NET FINDER button. And then the following window will be displayed as below. 3. Click MODIFY button. And then the modified information is displayed as below.

  • Page 75: Connect And Disconnect

    7-8-2. Connect and Disconnect 7-8-2-1. Connect 1. Select site/sites to connect from the directory window. 2. Click CONNECT button, and then site/sites displays/display as connected. 7-8-2-2. Disconnect 1. Select site/sites to disconnect from the directory window. 2. Click DISCONNECT button, and then selected site/sites disconnected.

  • Page 76: Still-Image Capture During Live

    7-8-3. Still-image Capture During Live 1. Double-click a channel to capture from the display screen. (Otherwise all channels will be captured.). 2. Click CAPTURE button. And then a Capture window will be displayed as below. 3. Set Save Path, File Name, and File Format. And then click OK button. 4.

  • Page 77: Recording Video On Local Pc During Live

    7-8-4. Recording Video on Local PC During Live 1. Click SETUP button. And then a setup window will be displayed as below. 2. Select Record and set the values. 3. Select Disk and set the values. 4. Click RECORD ON button. And the color of button is changed. 5.

  • Page 78: Local Playback And Remote Playback

    7-8-5. Local Playback and Remote Playback 7-8-5-1. Playback of Recorded Video on a Local PC 1. Click LOCAL PLAYBACK. And then Playback Window will be displayed over the Live Window. 2. Select site/sites to connect from the directory window. 3. Click CONNECT button.
  • Page 79 7-8-5-2. Playback of Recorded Video on Remote DVR 1. Click REMOTE PLAYBACK. And then Playback Window will be displayed over the Live Window. 2. Select the site to connect from the directory window. 3. Click CONNECT. And then Green bar displays on Search calendar and timeline scale window.

  • Page 80: Avi Backup During Playback

    7-8-6. AVI Backup during Playback You can back up the recorded videos in AVI format during playback. 1. Double-click the target channel to backup. 2. Select the beginning time by using the search calendar and timeline scale bar. 3. Click MARK IN button on the timeline scale to select the beginning point of the backup.
  • Page 81 6. You can also set the beginning time and ending time on this window. After selecting a channel for backup, click the OK button. The backup will begin. 7. AVI video data is recorded as set in AVI Backup window. AVI format video can be played back by using Window Media Player™...

  • Page 82: Network Access Using The Web-Browser Viewer

    8. Network Access Using the Web-Browser Viewer The DVR provides a live remote monitoring feature by web-browser viewer. (NOTE: Web-Brower is only available for Internet Explorer) 1. Check the IP address of the DVR from SETUP>SYSTEM>DESCRIPTION>IP ADDRESS or 2. Input the IP address or Domain name address that you pre-registered. 3.
  • Page 83  Site Name: Input a name that properly describes a site.  IP Address: Input IP address (Public IP address of a router that DVR is connected.) or Domain name  Port Number: Default Port Number is “5445”.  ID: Input ID of DVR. Default ID is “admin”. ...

  • Page 84: Network Access Using The Smart Phone Viewer

    9. Network Access Using the Smart Phone Viewer 9-1. App Viewer for iPhone 1. Enter the Apple App Store. 2. Search “Speco Viewer” in the App Store. Notice SPECO VIEWER is for the RS, WRS and HD series DVRs. SPECO VIEWER is not compatible with the T Series DVR‟s (TH, TN or TL) or the PC Series DVR‟s.
  • Page 85 7. Select the saved site from “My Site List” 8. Select a channel (s) to view. 9. After selecting a channel, the app will display the channel (s). Notice Data Usage applied without Wi-Fi connection. Please check with your Phone Carrier.

  • Page 86: App Viewer For Android Phone

    10-2. App Viewer for Android Phone 1. Enter the Android Market. 2. Search “Speco Viewer” in the Android Market and install the “Speco Viewer” app. 3. Open the installed “Speco Viewer” App 4. Select the ADD in the top right corner for “Site Information”...
  • Page 87 5. Input the “Site Information” and select CONFIRM to save the “Site Information” 6. Select the saved site from “My Device” for network connection. 7. The app will display the live streaming video. Notice Data Usage applied without Wi-Fi connection. Please check with your Phone Carrier.

  • Page 88: Appendix: Network Connection - Lan

    APPENDIX: Network Connection - LAN 1. Install the network client software from the supplied CD. 2. Check the IP address from SETUP > SYSTEM > DESCRIPTION or SETUP>NETWORK of DVR. 3. Run the network client software.
  • Page 89 4. Input Site Name, Site Address (IP address), Port Number, and Password on the connect window.  Site Name: Input a name that properly describes a site.  IP Address: Input IP address  Port Number: Default Port Number is “5445”. ...

  • Page 90: Appendix: Network Connection - Internet And Ddns

    APPENDIX: Network Connection – Internet and DDNS Dynamic Domain Name System (DDNS) allows a domain name to be constantly synchronized with a dynamic IP address. A current dynamic IP address is being associated with a static domain name. 1. Go to SETUP>NETWORK>DDNS and set the DDNS SERVER to ON. If you set ezDDNS to ON, the host name is automatically generated and registered.
  • Page 91 3. When a manual host name is completed, Go to SETUP>NETWORK>DDNS>SUBMIT/UPDATE and select ON to submit the settings on the SPECO DDNS. Once the setting is completed, the DDNS address will be: http://hostname.ddns.specoddns.net For example, if you enter the host name as “D4RS”, then the address will be: http://d4rs.ddns.specoddns.net 4.
  • Page 92 8. Port forward the network PORT (Default: 5445) and WEB PORT (Default: 80) of the private IP Address of the DVR on the network router. Please refer to the user manual and guide for the detailed steps for port forwarding for specific router model.
  • Page 93 And select the OK button. Then, press button after checking the left check box.

  • Page 94: Appendix: E-Sata Connection

    APPENDIX: E-SATA CONNECTION Please read the following instructions before using the E-SATA port. Failure to do so may cause serious damage to the recorded video. SPECO is not responsible for data loss caused by improper usage.  Use ONLY a new HDD or a HDD that is pre-formatted on a PC. ...
