2004 TURBO
®
PRO
CYCLOCOMPUTER
Congratulations on your purchase! You are now the
owner of the world's most advanced cyclocomputer.
Your Specialized Turbo® Pro features a wireless speed
transmitter and a wired cadence sensor. Additionally, it
incorporates a revolutionary new backlit three-line LCD
screen. The large, easy to read, digits allow you to view
two functions simultaneously and the alphanumeric dot
matrix display provides a quick reference to the currently
displayed function. The Turbo® Pro has been designed
to provide the best combination of performance,
features, durability and ease of use.
3
7
4
5
6
8
2
1
FIGURE 1
This illustration describes the screen display and buttons
1- MODE rocker switch
2- SET rocker switch
3- TOP Button (Backlight & Start/stop)
4- Digital Display Area
5- Secondary Function Display Area
6- Dot-matrix Display Area
7- MPH or KM/H indicator
8- Wheel Option Indicator
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Turbo Pro 23A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Specialized Turbo Pro 23A

  • Page 1 CYCLOCOMPUTER Congratulations on your purchase! You are now the owner of the world’s most advanced cyclocomputer. Your Specialized Turbo® Pro features a wireless speed transmitter and a wired cadence sensor. Additionally, it incorporates a revolutionary new backlit three-line LCD screen. The large, easy to read, digits allow you to view...
  • Page 2: Battery Installation And Replacement

    Install make a note of your the battery (model odometer reading and CR2032, Specialized wheel circumference set- P/N 481-3004) with the tings before removing it. positive pole (+) facing You can then re-enter the upward.
  • Page 3: Installation

    from the transmitter hous- the transmitter is 24 inches ing. Install the battery (610mm). The distance (model 23A) with the posi- may need to be less than tive pole (+) facing 24 inches (610mm) if upward. Carefully thread ambient temperatures are the battery cap back onto below 40 °F (4 °C).
  • Page 4: Operation And Programming

    inside of your crank arm FIGURES 7, 8 & 9 directly across from the sensor. Use a tie-wrap to fasten the magnet to the crank arm. (See figure 8). Do not tighten the tie-wrap until final placement of the magnet is correct. The clearance between the magnet and the sensor should be approximately...
  • Page 5 Your Turbo® Pro has been Press the “SET” button to preprogrammed with the select the next digit to the following 14 Specialized right. Repeat this process tire sizes: until all five digits are 26 X 1.0 entered as your existing 26 X 2.2...
  • Page 6 FIGURE 12 You may also use the following quick-reference chart: Generic Tire Size Chart This chart is for non- Specialized tires 26 X 1.75 2140 26 X 2.0 2074 FIGURE 13 26 X 2.1 2090...
  • Page 7 5. Setting the Clock accept the hour selection. Your Turbo® Pro features a The minutes will flash and digital clock. To access the can be adjusted by press- “clock mode” press and ing the “MODE” button. the “MODE” button repeat- (Hold the “MODE”...
  • Page 8: Computer Functions

    programmed, press the until “ALTI” appears. Note: “TOP” button to start/stop if your display says the countdown. (See fig- “ALTIÒ” or “%GRD”, press ure 15). Note: The shortest the “SET” button to change interval that can be set is 5 to “ALTI”.
  • Page 9 The resolution of the aver- age speed data on the Digital Display Area is shown in 0.1M/h or Km/h increments. (See figure 16) FIGURE 17 Auto Start/Stop Timer (ATM)- In ATM mode the timer function records the actual time spent riding. It oper- ates only when there is FIGURE 16 speed input and is dis-...
  • Page 10: Troubleshooting

    AC button on the (An accessory handlebar bottom of the case mount is available from Display shows your Specialized dealer. partial digits: 4814-5045) Press the AC button on the bottom of the case. Backlight-...
  • Page 11: Specifications

    0 to 99,999 miles or Km your spokes and cause an accident. Stopwatch (TM) • See your authorized 0 to 9hrs, 59min, 59sec. Specialized dealer if you recycling type have any trouble installing or maintaining your computer. Automatic Timer (ATM) 0 to 9hrs, 59min, 59sec.
  • Page 12 This warranty does not pertain to batteries. No person or representative is authorized to assume any liability on behalf of Specialized Bicycle Components, Inc. in connection with the sale of this product. Some states do not allow the exclusion or limita-...
