  • Page 1 MCa300 THREE HUNDRED WAll MULTIPLE-CHANNEL AMPLIFIER Owner’s Manual...

  • Page 2: Table Of Contents

    MC 0300 Amplifier Owner’s Manual ThankyouforpurchasingaSoundstreamamplifier. Younow own one of the finest power amplifiers available, a precision component capable of audiophile~quality performance. the most out of your MC-300. we suggest you care- To get fullyacquarntyourseltwithitscapabilitresanddesign. Please retain this manual for future reference.

  • Page 3: Wiring Diagram

    TUNEVDECX Figure 1 Z-Channel Operation Figure 2 3 Channel Operation Figure 3 4-Channel Operation...

  • Page 4: Design Features

    The case is equipped with generous heat sinks. Input sensitivity is adjustable to match any tuner! deck, the MC-300 can even be interfaced with OEM speaker level signals. INSTALLATION Proper installation and adjustment will reward you with reliable operation and optimum performance.

  • Page 5: Selecting Operating Mode

    SELECTING OPERATING MODE The three hundred watts available from the MC-300 can be -divided into two channels (stereo) [Figure I]. threechannels (stereo plus a single mono channels) [Figure 21, or four channels (front and rear stereo; or stereo bi-amp) [Figure 31.

  • Page 6: Power Connections

    POWER CONNECTIONS Note: your amplifier can on/y NegativeGroundefecfricatsysfem. Ifyourcarwasproduced before 1970. orifyouhaveanydoubts. Of electrical system you have before making any connectfons. The MC.300 will draw up to 45 amperes if used to its fullest capacity~ Determine the alternator rating of your car and the other accessories.

  • Page 7: Protection Circuits

    PROTECTION CIRCUITS Your amplifier is protected against both overheating and short circuits. Because of the “soft’ thermal protection (see the Design Features section on page 3) it is highly unlikely that the amplifier will shut off because of thermal overload. If your amplifier shuts down, turn off the system, wait for a few moments, and turn the system on again.
