Summary of Contents for SoundCraft Spirit Live 3-2
- Page 5 Clipped Signal Noise If the signal level is too high, clipping distortion may occur. Signal Noise If the signal level is too low it may be masked by the noise.
- Page 8 Balanced Mic 2. Hot(+ve) 3. Cold(-ve) 1. Screen Unbalanced Mic 2. Hot(+ve) Link 3 to 1 1. Screen Balanced Unbalanced 3 pole Jack 3 pole Jack Hot (+ve) Signal Cold (-ve) Gnd/Screen Gnd/Screen Gnd/Screen Ring Sleeve Inserts Signal Send Signal Return Gnd/Screen Ring Sleeve...
- Page 9 Mix Outputs Mono Output 1. Screen 3. Signal - 2. Signal + Mix & Mono Inserts Signal Send Signal Return Gnd/Screen Ring Sleeve Aux Outputs Signal + Signal - Screen From LIVE 3 Impedance Balanced Output From LIVE 3 Headphones Impedance Balanced Output Left Signal...
- Page 10 Mix Outputs Mono Output 1. Screen 3. Signal - 2. Signal + Mix & Mono Inserts Signal Send Signal Return Gnd/Screen Ring Sleeve Aux Outputs Signal + Signal - Screen Headphones Left Signal Right Signal Ground...
- Page 26 86.1 mm (3.39") 590.5 mm (23.25") dim. ’x’ dim. ’y’ Width without end trim (for flight case mounting) Console dim ’x’ dim ’y’ 8 channel 456 mm 381 mm (18.0") (15.0") 12 channel 572 mm 497 mm (22.6") (19.6") 688 mm 613 mm 16 channel (27.1")
- Page 27 BASE BASE BASE...
- Page 28 Earthing Screw Location BASE Ground lead from power connector Ground lead from expander (RV2280) M3 Nut Power Connector washer...
- Page 32 A Harman International Company...
