Summary of Contents for Woosung Automa W2V40
- Page 1 USER INSTRUCTION For High Vacuum Rotary Vane Pump W2V40 WOOSUNG AUTOMA CO., LTD.
-
Page 2: Table Of Contents
CONTENTS 1. Utility of Basic Parts and Specification 2. Inspection 3. Installation 4. Operation 5. Maintenance 6. Trouble Shooting 7. Dimension of W2V40 8. Development figure 9. Bill of Material 10. Service Kit 11. Technical Support and Contact Information... -
Page 3: Utility Of Basic Parts And Specification
1. Utility of Basic Parts and Specification Specification Pumping Speed 400 ℓ/min Gas Ballast Closed 5X10-4 torr ( 6.7 X 10-2 Pa ) Ultimate Pressure Gas Ballast Open 5X10-2 torr ( 6.7 Pa ) Standard 220VAC 1Ф 50/60Hz Power Input Option 220VAC/380VAC 3Ф... -
Page 4: Inspection
① Open the Cover of Terminal box. You can see there is 6 cords connected. ② W2V40’s motor is 3 phase one. You need to connect 3 external cords to the pump. ③ By referencing the Terminal box cover, you can connect the pump to power. -
Page 5: Maintenance
WSA supports 2 kinds of repair kits for maintain W2V40. ‘Minor Repair Kit for W2V40’ is for normal overhaul. Pump consists of various metal and rubber component and some component need to change periodically. Please check the list of Repair kit. -
Page 6: Trouble Shooting
5. TROUBLE SHOOTING SYMPTOM CHECK STEM TO TAKE Power line voltage and connections. Correct voltage or connections. Any foreign materials inside the pump. Remove the foreign materials, If problem Noisy motor would not turn with oil, change it. Motor ( Open internal circuit). Replace open windings. -
Page 7: Dimension Of W2V40
7. Dimension of W2V40... -
Page 8: Development Figure
8. Development Figure... -
Page 9: Bill Of Material
9. Bill of Material BOM of W2V40 2007/02/09 (Standard Type : W2V40) SPEC NO DESCRIPTION STANDARD W4V0001 MOTOR 3ΦX 200/380V X750X50/60 W4V0002 5X5X15R W4V0003 MOTOR PLATE DIECAST W4V0004 MOTOR MOUNTING BOLT M6X15 W4V0006 COUPLING FAN FIXING BOLT M5X10(SET SCREW) W4V0007... - Page 10 W4V0039 STAGE BLADE 40*30.5*6 W4V0040 STAGE STATOR FC-25 W4V0041 SPRING WASHER Ø6 W4V0042 STAGE STATOR FIXING BOLT M6X30 W4V0043 O-RING G-70 W4V0044 O-RING W4V0045 END PLATE FC-25 W4V0046 COCKING PIN M6X6 W4V0047 END PLATE FIXING BOLT M6X30 W4V0048 O-RING AN-170 W4V0049 OIL BOX DIECAST...
- Page 11 W4V0084 STAGE STATOR FC-25 W4V0085 VALVE GUIDE PIN (ROLL PIN) Ø3X20 W4V0086 VALVE 50X53X3T W4V0087 VALVE BACK PLATE 49X54X1.8T W4V0088 VALVE SPACER Ø8X Ø15X9 W4V0091 VALVE FIXING BOLT M5X20 W4V0092 VALVE OIL BAFFLE 147X127X1.2T W4V0093 VALVE OIL BAFFLE FIXING BOLT M5X8 W4V0094 O-RING...
- Page 12 W4V0123 DIECAST W4V0124 MOTOR PLATE GUIDE PIN Ø6X13 W4V0125 HANDLE DIECAST W4V0126 HANDLE FIXING BOLT M6X20 W4V0127 MOTOR BODY FIXING BOLT M6X35 W4V0128 O-RING AN-048 W4V0129 TERMINAL BOX FIXING BOLT M5X20(+) W4V0132 3P TERMINAL 3P/20A W4V0133 COVER FIXING BOLT M4*8(+) W4V0134 NAME PLATE STICKER...
-
Page 13: Service Kit
10. Service Kits W2V40 Service KIT Code # Description Q’ty Standard Remarks W4V0016 OIL SUCTION FELT FELT Minor and Major W4V0020 O-RING P-22 Minor and Major W4V0021 OIL SEAL(Viton) 22X32X7 Minor and Major W4V0022 O-RING G-45 Minor and Major W4V0027... -
Page 14: Technical Support And Contact Information
11. Technical Support and Contact Information PLEASE RETURN TO POINT OF SALE...
