Web en www.SonyEricsson.com o, si se encuentra en Estados Unidos, también puede llamar al 1-800-374-2776. Register your new phone, purchase Sony Ericsson original accessories, and see the latest in products by visiting us at www.SonyEricsson.com. This manual is published by Sony Ericsson Mobile Communications (USA) Inc., without any warranty.
Table of Contents Features of Your Mobile Phone ...4 Guidelines for Safe and Efficient Use...5 Battery Information...11 Limited Warranty...13 Getting Started ...15 Getting To Know Your Phone...18 Changing Front Covers ...19 Calling...21 Personalizing Your Phone ...31 Voice Control...39 Voicemail ...44 Sending and Receiving Items ...54 Setting Up Mobile Internet ...55 Messaging...60...
You can personalize your phone by changing the cover, downloading ring tones, animations, and images, and customizing your background picture. To personalize your phone, visit www.SonyEricsson.com. Accessories Sony Ericsson offers a number of innovative and unique accessories including the FM Radio, the MP3 Player, the ™ ™ Chatboard...
Do not remove the antenna yourself. Only use an antenna that has been specifically designed by Sony Ericsson for your mobile phone. Use of unauthorized or modified antennas could damage your mobile phone and may violate the appropriate regulations, causing loss of performance and SAR levels above the recommended limits (see below).
For optimum performance with minimum power consumption please: • If your mobile phone is equipped with a retractable antenna, Sony Ericsson recommends that the antenna should be kept fully retracted (closed) while the phone is worn on the body to avoid the antenna touching, or coming in close proximity to, the body.
Page 8
Federal Communication Commission in the U.S. requires that some manufacturers’ accessories shall be tested, and Sony Ericsson has done so with respect to its products. Sony Ericsson has not tested non-original accessories in conjunction with Sony Ericsson mobile phones.
Law in many countries/states requires drivers to use a Hands Free solution. Sony Ericsson recommends that you use only Sony Ericsson or Ericsson branded Hands Free solutions intended for use with this product. Sony Ericsson is concerned about your safety. Always give...
In the event of such interference, you may want to consult your service provider or call your local Sony Ericsson Contact Center to discuss alternatives. Other Medical Devices If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fuelling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Do not transport or store flammable gas, liquid, or explosives in the same compartment of your vehicle that contains your mobile phone and accessories.
Emergency Calls IMPORTANT! This mobile phone, like any mobile phone, operates using radio signals, cellular and landline networks as well as user- programmed functions, which cannot guarantee connection under all conditions. Therefore you should never rely solely upon any mobile phone for essential communications (e.g. medical emergencies).
Use only Sony Ericsson or Ericsson branded original batteries and chargers intended for use with this product. Using other batteries and chargers could be dangerous, and the warranty does not cover product failures which have been caused by use of other batteries and chargers.
To get maximum use of your new Product, we recommend that you follow a few simple steps: Read the Guidelines for Safe and Efficient Use. Read all the terms and conditions of this Sony Ericsson Warranty. Save your original receipt. You will need it for warranty repair claims.
Page 15
4 Since the cellular system on which the product is to operate is provided by a carrier independent from Sony Ericsson, Sony Ericsson will not be responsible for the operation, availability, coverage, services or range of that system.
Getting Started About this user’s guide For ease of reference, see “Getting To Know Your Phone” on page 18 for a quick overview of the main functions of the phone, shortcuts and general information. Available services Some services and functions described in this user’s guide are network- or subscription-dependent.
Charging Your Battery To charge your battery for the first time, attach the phone’s battery to the back of your phone under the back cover. Then, replace the back cover. Once you install your battery, you should not need to remove it.
Replacing the Back Cover 1 Locate the notches along each side of the back of the phone. 2 Using the notches as a guide, slide the back cover upward. Press the back cover latch to allow the back cover to fully insert. 3 Click the back cover into place.
Getting To Know Your Phone Phone Views The following diagrams illustrate the front, back, and bottom views of your phone. 1 Earpiece 2 Side volume keys 3 Display 4 Left softkey 5 Joystick (4-way navigation with center push key) 6 Options key 7 Keypad 8 Power On/Off key 9 Clear key...
Changing Front Covers Removing Your Phone’s Covers Your phone is equipped with replaceable covers. For more information on ordering additional covers, see “Ordering Accessories” on page 87. Never use your phone with the front or back cover removed. 1 Remove the back cover. Use one hand to press down on the back cover latch and the other hand to slide the cover off the phone.
Replacing Your Phone’s Covers 1 Place the keypad in the new cover, pressing firmly until the keys are properly in place. 2 Locate the tab on the top of the cover. 3 Holding the front cover at an angle, as shown in the illustration, insert the tab into the notch on the phone.
3 Enter the area code (if necessary) and phone number and press Call to make the call. 4 Press End to end the call. 5 When the phone rings, press Answer to answer the call. Note! Your mobile phone is equipped with an internal antenna located inside the back of your phone, above the back cover.
To mute the microphone during a call Press and hold until the display shows hold again to resume the conversation. Automatic redialing If the connection of the call failed and the display shows , press Yes. The phone redials the number (up to Retry? 10 times): •...
Receiving calls When you receive a call, the phone rings and the display shows the number that is calling you. If your subscription includes Caller ID service and the caller’s number is identified, the number is displayed. If you have saved the number in your phonebook, the name associated with that number is displayed.
5 Select the next field and so on. 6 When you have entered the information, scroll to and press Proceed. and exit? Note! The total number of contacts varies according to the amount of stored information for each contact. You can check the number of available contacts under Phonebook, Memory Status.
Page 26
To check the phonebook memory, scroll to Memory Status Note! The total number of contacts varies according to the amount of stored information for each contact. Adding voice commands to contacts You can add a voice command to a contact. •...
Deleting all contacts Scroll to Phonebook Options Delete All Note! Contacts that are saved on the SIM card are not deleted. Copying the contacts stored on your SIM card 1 Scroll to Phonebook Options 2 Press Select. Copy from SIM may take a few minutes. Copy now? appears on your display.
Page 28
Switching between input methods Press and hold during text entry to toggle between Multitap and T9. Input languages Before you start entering letters, you need to select the input languages that you want to use when writing. Selecting input languages 1 Scroll to Settings Language...
Page 29
Options during multitap text input When you press during multitap text input, you can choose from the following list of things to do: • – Symbols and punctuation marks such as ? Symbols and , are shown. Move between the symbols by tilting the joystick to the left or to the right.
Page 30
Entering Text Quick Keys To... Do this when entering letters using multitap text input: Reach the second Press and hold the upper side letter or character of volume key followed by a digit key a key (for example, press the upper side volume key then press B.
Page 31
each key only once, even if the letter you want is not the first letter on the key. Note! T9™ Text Input does not work for phonebook entries or WAP addresses. Entering letters using T9 Text Input 1 Scroll to Messages Send New 2 For example, if you want to write the word “phone”,...
• – A list of alternative words is shown. Candidates • – A help screen is displayed. Help Turning off T9 Text Input Method You can turn off T9 Text Input. This setting is valid for all input of texts – not only for the text you are currently writing.
Page 33
Pictures Your phone contains several pictures which you can send in a text message via SMS. Editing and saving a picture 1 Scroll to Extras Pictures 2 Select a picture group. 3 Tilt the joystick up or down to scroll through the pictures.
Page 34
You, and not Sony Ericsson, are entirely responsible for additional melodies that you download to or forward from your mobile phone. Prior to...
Page 35
• Press once to raise the note one semitone. • Press twice to lower the note one semitone. • Press to remove notes. 2 To listen to your melody, press Play. 3 You will be prompted with Accept? it, or press No to continue composing. Note! To send a ring sound or melody in a text message, see “Inserting an item in a text message”...
Vibrating alert To set the vibrating alert 1 Scroll to Settings Sounds & Alerts 2 Select the setting you want. Minute Minder From the Settings Sounds & Alerts select Message Alert Key Sound Minder If you turn on the minute minder, you hear a beep once every minute during a call.
Page 37
Automatic keylock Automatic keylock means the keypad is locked 25 seconds after you last press a key. • To turn automatic keylock Locks Auto Keylock • To lock the keypad manually, press and hold or press and select Lock Keypad The keypad remains locked until you answer an incoming call or until you unlock the keypad manually.
2 Change your phone to TTY Accessory scrolling to Settings Profiles Accessory 3 Follow the operating instructions provided with your TTY device. Note! TTY Accessory profile is intended for use by those with a TTY Accessory for the speech and hearing impaired.
User greeting When you turn your phone on or off, the Sony Ericsson greeting appears in the display. Your service provider’s own greeting may be shown instead. To interrupt the greeting, press No. To interrupt the greeting, press Selecting a greeting...
Go to Settings Display Background You can only store one customized background picture in your phone at a time, but you can store additional pictures in your personalized area at www.SonyEricsson.com. Phone number display You can check your own phone number(s). To check your phone number, scroll to .
Page 41
2 Select . Now you are going to record a voice command for each number type you use with your phonebook contacts like “home”, “mobile”, “work”, “other”. 3 Instructions appear on your display. 4 Select a number type. 5 Lift the phone to your ear, wait for the tone and say the number type that you have selected.
Page 42
From standby, you can also initiate voice dialing, voice profiles and voice memos by: • Pressing and holding the upper or lower side volume key. • Pressing the handsfree button (when using a portable handsfree device). • Saying the Magic Word. See “The Magic Word” on page 43.
Page 43
Changing a profile using voice commands 1 From standby, press and hold the upper or lower side volume key until you hear a tone. 2 Release the key, lift the phone to your ear and say the profile command for the desired profile. The profile command is played back to you and the current profile is changed.
Page 44
The Magic Word You can record a Magic Word and use it as a voice command. Say the Magic Word and then one of your recorded voice commands. The Magic Word is especially suitable when using a car handsfree kit. Note! Choose a long, unusual word which can easily be distinguished from ordinary background speech.
• You held the phone too far away – hold it as you do during a call. • The voice command was too short – it should be around one second long and more than one syllable. • You spoke too late or too soon – speak immediately after the tone.
Checking the call time of the last call Scroll to Call Info Call Timers Last Call Checking the call time of your outgoing calls Scroll to Call Info Call Timers Outgoing Time Checking the total call time Scroll to Call Info Call Timers Total Calls Resetting the total call time...
Page 47
Turning on call forward 1 Scroll to Settings Call Manager 2 Select a call category and then a forward alternative. 3 Select Activate 4 Enter the phone number to which you want your calls to be forwarded or retrieve it from the phonebook by pressing Note! When the...
Receiving a second call • To answer the second call and put the ongoing call on hold, press Hold. • To reject the second call and continue the ongoing call, select Ignore • Select to answer the second call and Release &...
2 Select the participant. You may now have a private conversation with the participant. Rejoining the participant to the conference group Scroll to Ongoing Call Join Calls Releasing Participants You can release participants from the conference group one by one or all at once. Releasing a participant •...
Changing the Name When you buy your phone, the names of the lines are normally line 1 and line 2, but you can change their names. Changing the name of a line 1 Scroll to Settings Display Edit Line Tags 2 Select a line.
Page 51
Calling Card Service To be able to make calling card calls, you need to turn on the service. Turning on the calling card service 1 Scroll to Phonebook Options 2 Enter your phonelock code (0000 unless you reset it). 3 Select The Calling card service is now on and the sub-menu is available in the Calling Cards...
Selecting a card 1 Scroll to Phonebook Calling Cards 2 Enter your phonelock code. 3 Select the card that you want to use. 4 Select Activate Making a Calling Card Call 1 Enter the phone number you wish to call or retrieve it from the phonebook.
Fixed dialing The Fixed dialing function allows calls to be made only to certain numbers saved on the SIM card. If an attempt is made to call other numbers, the message appears in the display. Fixed dialing Number not permitted requires a SIM card that allows fixed numbers to be saved.
Accept calls With the accept calls service, you can choose to receive calls only from certain numbers. Other calls are automatically rejected by a busy tone. The phone numbers of calls you have rejected are saved in the Call List. Adding numbers to the accepted callers list 1 Scroll to Settings...
Notepad If you want to make a note of a phone number during a call, you can use your phone display as a notepad. Use the number keys to enter the number. When you end the call, the number remains in the display. You can call the number by pressing Call.
Your GSM or Internet service provider may be able to send the required data account, WAP, and email settings directly to your phone in a text message (SMS). Requesting settings from Sony Ericsson Mobile Internet 1 Use a PC to go www.SonyEricsson.com/mobileinternet.
Page 57
(connection method). You can choose from Account Type account types. GPRS Data GSM Data Note! Contact your service provider for details on any data usage charges. GPRS (General Packet Radio Service) allows fast and efficient access where you can always be online.
Page 58
Creating a data account manually 1 Scroll to Settings Data Comm. Account? 2 Select an account type. 3 Enter a name for the data account. 4 Enter the settings that you have received from your service provider. You will be asked to confirm each setting. 5 Scroll to Select Proceed to save your changes.
Page 59
2 Scroll to Browser WAP Settings 3 Select or a to add a new profile or Common Profile select an existing profile that you want to edit. Note! Some WAP Profiles may be set by your service provider and you may not be able modify them. Contact your service provider for specific WAP Profiles information.
Page 60
Transaction contracts You can check on transactions you have made with your phone when browsing. A contract, which contains details about the transaction, can be saved in your phone. To check your contracts, scroll to Common Security Contracts Email account settings An email account specifies, for example, the server that is used for your email messages.
Messaging Your phone supports various messaging services - text messages, enhanced text messages with pictures and/or melodies (EMS), and email messages. Please contact your service provider for details on which services you can use. Text messages Text messages can be sent to one person, or to a group of recipients that you have saved in the phonebook (see “Groups”...
Page 62
Inserting an item in a text message 1 Scroll to Messages Send New text message, you may need to turn on (see below). 2 While writing your message press and hold 3 Select Insert Object 4 Select Picture Sound Melody 5 Select an item and confirm your selection.
• To resume a Chat session, scroll to Resume • To end a Chat session, press Cancel. • To reject a Chat message, press No. The rejected Chat message is saved in the in the Messages menu. Inbox • If you receive a new Chat message while another Chat session in ongoing, you can end the ongoing session and start the new one.
are saved on the SIM card. Messages that you have saved on the SIM card remain there until you delete them. Saving from a text message When the email address, phone number, WAP address, picture, animation, or melody is highlighted, press Select to save the item.
• Validity Period – If your message cannot be delivered, for example, if the recipient has turned off the phone, your service center can save the message to send it later. • Reply Request – Include a reply request if you want the recipient of your message to reply.
Page 66
Forwarding a message 1 Select in the list of options. Forward 2 You can now edit the message. 3 Enter the recipient’s phone number or tilt the joystick to the left to retrieve the number from the phonebook or the call list. Press OK to send. Saving a received message Select in the list of options.
Message Alert You can choose the signal you want to hear when you receive a message. You can choose between clicks, tones, or silent. Setting the message alert 1 Scroll to Messages Options 2 Select an alert. Area Information The ordinary Short Message Service (SMS) is a personal service that carries your private messages.
Page 68
Email You can use the email function in your phone to send and receive e-mail messages. Before using the email program, make sure you have created a data account, an email account and specified which email account to use. You must also have a subscription that supports data transmission.
Page 69
3 Select the email message you want to read. Note! The phone can save up to six complete email messages. All your email messages are saved on your email server. You may not be able to see all your new email messages at once, since the memory capacity of the Inbox is limited.
WAP (Wireless Application Protocol) is a global standard for advanced mobile services, for example, mobile Internet communication, mobile e-commerce, and telephony services. WAP allows you to access certain services on the Internet such as banking services, news, and reservation services from your mobile phone.
which email account you want to use when sending and receiving email messages. Note! The settings may already be entered when you buy the phone, or you can receive the settings from your network operator or your Internet service provider. You can also receive settings from www.SonyEricsson.com.
Page 72
– your password to log on to the external data Password network. (Password request) – if this setting is on, Passwd. request you are asked for a password each time you log on to the external data network. – if you want to allow incoming calls Accept calls during a GPRS session, select .
Data Counters To check how much data you have sent and received, using GPRS, scroll to Call Info Data Counters Total Data Using the WAP browser Starting to browse 1 First select the WAP profile you want to use. 2 Scroll to Browser 3 Select one of the following (dependent upon your service provider):...
• – go back to the WAP services menu in Go To Menu order to access other phone menus. The connection to the Internet is not interrupted. When you want to start browsing again, scroll to Browser • – Go to standby or disconnect. Exit •...
Page 75
Setting push message acceptance 1 Scroll to Browser WAP Setting Access 2 Select one of the following settings: • – You allow push messages to be automatically loaded. • – You do not allow push messages. Responding to a push message When you receive a push message, it comes to the Inbox •...
Transferring and Exchanging Information Fax and data calls Sending fax and data calls To send fax and data calls you need to connect your phone to a computer, and then start the appropriate software program. Receiving fax and data calls The procedure of receiving fax and data calls depends on your network and subscription.
More Features Alarm clock The alarm can be set to ring at a specific time within 24 hours, or recurrently at a specific time on several days. You can have both these alarms set at the same time. Even if you have set your phone to silent, the alarm and timer signals ring.
• To reset the stopwatch, press Note! The stopwatch is turned off when you answer an incoming call or when you exit the stopwatch menu. Timer The phone has a built-in 24-hour countdown timer which replaces the clock when it is set. •...
Page 79
• All codes are encrypted in the mobile phone. • When you access your codes, they are shown for a limited time only. Opening code memo for the first time 1 Scroll to Extras Code Memo A message with instructions appears. 2 Enter a four-digit password to open Code Memo.
You can synchronize the calendar and contacts in your phone with the calendar and contacts in your PC. To do this, you first need to install on your PC the synchronization program found on the Sony Ericsson mobileinternet website (www.SonyEricsson.com/mobileinternet). If you have an Internet calendar or phonebook, you can also synchronize that with your phone calendar and contacts, using WAP.
Page 81
Appointments and tasks You can save up to 200 appointments and tasks in your calendars, depending on the size of each item. You can choose to add a new appointment or task, or to use an old appointment or task as a template by copying and editing it. •...
• – Move within and among the weeks by View Month moving the joystick. Press Select to view a certain day. Days on which you have appointments are marked in bold. Note! In the monthly and weekly views, you can go to next week by pressing 3, to next month by pressing 6 and to next year by pressing 9.
Page 83
Making the WAP synchronization settings 1 Scroll to Extras Synchronization 2 Select WAP Profile In the list of WAP profiles, select the one you want to use for synchronization. 3 Select Server User ID Enter your user id for the Internet calendar and phonebook.
Security SIM card lock The SIM card lock protects your subscription, but not your phone itself, from unauthorized use. If you change SIM cards, the phone still works with the new SIM card. Most SIM cards are locked at the time of purchase. If the SIM card lock is on, you have to enter a “PIN”...
Phonelock on If the phonelock is on, the message each time you turn on the phone. You have to enter your code to use your phone. Automatic If the phonelock is set to automatic, you do not need to enter your phonelock code until a different SIM card is inserted in the phone.
• You may have set Accept calls Select instead. See “Data Account Settings” on page 70. If you still cannot receive incoming calls, it could be due to network limitations. Cannot Speed Dial Your contacts are not saved on the SIM card. See “Voice Control”...
Page 87
See “Turning Fixed dialing on or off ” on page 52. Charging, alien battery The battery you are using is not a Sony Ericsson-approved battery and is charging slowly for safety reasons.
• Visiting www.SonyEricsson.com/us (US only) • Calling 1-800-374-2776 (US only) • Calling 1-800-755-6789 (Puerto Rico) • Visiting your local Sony Ericsson or Ericsson retailer. Accessible Solutions/Special Needs For information on Accessible Solutions for individuals with special needs call the Sony Ericsson Special Needs...
Icons The table below shows icons which may appear in standby or in the menus. Icon Description Your personal phonebook. Handling of text and voice messages. Handling of call time, call cost information, and ongoing calls. Personal settings, profiles, forward calls, networks, and voice control.
Page 90
Icon Description You have received a WAP push message. Line 1 is in use for outgoing calls. Line 2 is in use for outgoing calls. A Chat session is active Encoding is currently not being provided by the network. The card lock or phonelock is on. A secure WAP connection is established.
Page 91
Icon Description An email message has not been read. An email message has been read. Only part of an email message is saved in the phone. An email message, not read, has been deleted. The appointment is a meeting. The appointment is a date. The appointment is to travel.
Index Accessibility Accessories Air Bags Aircraft Alarm clock Answering mode Antenna Care Area information Assistance Battery attaching charging disposal Blasting Areas Business cards exchanging Calculator Calendar add a task add an appointment settings status view Call costs calling card minute minder Call time Calling automatic redialing...
Page 93
reset Conference calls extracting a participant putting conference on hold releasing a participant reviewing participants Contacts call copy edit Data account Data calls Data counter Display animation greeting Index help texts icons light Disposal Driving Electronic Devices Emergency Calls Emergency calls Emergency numbers Enhanced Messaging Entering letters...
Page 94
Keypad lock automatic manual Language in display Light Locks keypad phone SIM card Magic word 20, 21 Making calls Medical Devices Melodies saving from a message Melodies, see Ring sounds Menu language Menu overview Message options Messaging Missed calls 69, 87 Mobile Internet bookmarks browsing...
Page 95
Product Care Profiles automatic activation selecting Radio Frequency (RF) Reset Ring sounds increasing increasing ring key sound personal Settings profiles Shortcuts SIM card copy contacts Index unblocking SIM card lock activating/canceling deleting messages forwarding messages Special Needs Speed dialing Stopwatch SyncML T9 Text Input Technical Assistance...
Page 96
editing voice commands magic word recording voice memos reject 41, 43 tips Voice dialing Voicemail WAP, see Mobile Internet Index...
Menu Overview Phonebook Messages Call Contact Call Voicemail Add Contact Edit Contact Chat Business Cards Email Call from SIM Options Groups Calling Cards Options Memory Status Special Numbers * Only available during a call Additional menus are network- and subscription-dependent. Call Info Settings Missed Calls...
Page 98
Redial Last Dialed Number Press CALL LIST then CALL . Scroll Through Menus Tilt the joystick to the left or right. Move through lists Tilt the joystick up or down. Delete an item Press and hold C when in lists. T61 Quick Card...
Page 99
Select a menu or setting Press SELECT or press center push key. Go back to standby Press and hold BACK . Turn on Voice Dialing Press and hold the upper or lower side volume key. Call Voicemail Press and hold 1 . Call a contact Tilt and hold the joystick to the right.
