User Guide
PLEASE READ & SAVE THESE ORIGINAL INSTRUCTIONS
Image Spot
This guide applies to the following Rosco Image Spot Mini models:
296201030651
Image Spot Mini 3000K – IP65 - w/o Lens – Black
296201030652
Image Spot Mini 3000K – IP65 - w/o Lens – White
296201055651
Image Spot Mini 5500K – IP65 - w/o Lens – Black
296201055652
Image Spot Mini 5500K – IP65 - w/o Lens – White
2962010T3001
Image Spot Mini 3000K – Track 0-10V/Triac – Black – No Lens
2962010T3002
Image Spot Mini 3000K – Track 0-10V/Triac – White – No Lens
2962010T3003
Image Spot Mini 3000K – Track DMX – Black – No Lens
2962010T3004
Image Spot Mini 3000K – Track DMX – White – No Lens
2962010T5501
Image Spot Mini 5500K – Track 0-10V/Triac – Black – No Lens
2962010T5502
Image Spot Mini 5500K – Track 0-10V/Triac – White – No Lens
2962010T5503
Image Spot Mini 5500K – Track DMX – Black – No Lens
2962010T5504
Image Spot Mini 5500K – Track DMX – White – No Lens
2962010UV651
Image Spot Mini UV - IP65 – w/o Lens – Black
296210000010
Image Spot Mini 0-10V/Triac Driver 15W
296210000DMX
Image Spot Mini DMX Driver 36W
Mini
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rosco Image Spot Mini Series
Summary of Contents for Rosco Image Spot Mini Series
- Page 1 PLEASE READ & SAVE THESE ORIGINAL INSTRUCTIONS Image Spot Mini ® This guide applies to the following Rosco Image Spot Mini models: 296201030651 Image Spot Mini 3000K – IP65 - w/o Lens – Black 296201030652 Image Spot Mini 3000K – IP65 - w/o Lens – White 296201055651 Image Spot Mini 5500K –...
-
Page 3: Table Of Contents
Warranty ............................20 Information and specifications in this document are subject to change without notice. Rosco assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Image Spot Mini User Guide Copyright ©2019 by Rosco... -
Page 4: Introduction
INTRODUCTION Congratulations on your purchase of a Rosco Image Spot Mini projector. Designed to provide crystal-clear imaging and spot illumination, the Image Spot Mini is quick and easy to set up with convenient on-board dimming or remote controls. To ensure efficient and safe operation, please take a few moments to read this manual completely. - Page 5 PREVENTING ELECTRIC SHOCK • This system uses mains drivers that connect to electrical power at 100-277VAC. When directly contacted, such voltages are hazardous to human life. Follow all local electrical codes and take precautions when using this product. • Use only extension cords that are of appropriate length and are rated for Image Spot Mini’s specified voltage and current.
- Page 6 • Rosco Image Spot Mini is not certified for use in hazardous locations. • Rosco Image Spot Mini is designed for operation within the range of -4° to 122°F (-25° to +50°C). • Ensure Rosco Image Spot Mini is stored within the range of -13° to 140°F (-25° to +60°C).
-
Page 7: Unpacking
UNPACKING Carefully remove the unit from the box. Do not attempt to operate Rosco Image Spot Mini projector if there are any signs of physical damage. In case of damage, contact your local Rosco dealer. Your Rosco Image Spot Mini projector requires that an Image Spot Mini focusing lens tube (purchased separately) be inserted into the opening on the front of the unit prior to operation. -
Page 8: Installing Lens Tube
INSTALLING LENS TUBE Gently insert the end of the lens tube into the opening on the front of the projector. Rotate several turns to engage the threads. Once the projector has received power, the lens tube can be further rotated to adjust the focus of the projected image. MOUNTING The Image Spot Mini projector can be installed in the desired location via the center hole in the yoke. -
Page 9: Wiring
Your Rosco Image Spot Mini projector will arrive with an unterminated power cord attached to the unit. Wiring to a Rosco-supplied driver and the driver to line voltage should be performed by a qualified electrician and is the responsibility of the installer or end user. - Page 10 DN Wiring Dia 2 V3 Image Spot Mini Wiring For On-Board Dimmer LED + : Red L : Black LED - : Black N: White IMAGE SPOT MINI Black 0-10V/TRIAC White Black White Grey DRIVER Black Green Purple DN Wiring Dia 3 V4 Image Spot Mini Wiring For DMX Controller IMAGE SPOT MINI LED -...
- Page 11 The current will be preset on the LTech DMX driver to 1050mA: Note: the suggested current is 1050mA, any variation may result in under performance or a shortened LED life cycle, and may void warranty. Ensure the correct power connections have been made to the Image Spot Mini projector. The fixture will immediately illuminate upon receiving power and a valid control signal.
-
Page 12: Dimming Control
Due to the ultra-clear optics of the Image Spot Mini projector, it is advised to keep the optic path clean of dust and debris. Use a non-abrasive micro-fiber cloth with Rosco Lens Cleaner to clean the Image Spot Mini lenses and any glass gobos or Permacolor dichroic glass filters you may have installed. -
Page 13: Gobo Projection
A flat tipped screw driver can be used for additional torque to tighten the thumb screws. For optimum image quality, use Rosco Image Spot Mini gobos, which feature custom bezels that fit securely inside the Image Spot Mini gobo cassette. -
Page 14: Dichroic Color Filters
DICHROIC COLOR FILTERS Rosco Permacolor dichroic filters are available to provide fully customizable, long-term color options for your Image Spot Mini. For optimal performance and installation, specify Image Spot Mini Permacolor Filters that feature custom bezels to fit securely inside the Image Spot Mini gobo cassette. -
Page 15: Accessories
Image Spot Mini Medium Angle Lens Optic / 17º - Silver 296220000252 Image Spot Mini Wide Angle Lens Optic / 25º - Silver 855072020008 Rosco Lens Cleaner 8oz 855072040406 Lens Tissue - 4” X 6” Pad (100 Sheets) 296220000022 Image Spot Mini Cable Cover - Black... -
Page 16: Ordering Gobos & Permacolor Filters
ORDERING GOBOS & PERMACOLOR FILTERS Gobos and Permacolor Dichroic Filters for the Image Spot Mini projector can be easily ordered through any Rosco dealer. Visit www.rosco.com to locate the dealer nearest you and provide them with the information below. Standard Gobos... - Page 17 For assistance ordering or specifying gobos or Permacolor filters for the Image Spot Mini, please contact our Gobo Customer Service Centers: Americas Toll Free in the US: 866-228-2256 customgobo@rosco.com Outside of the US: 512-388-5299 EMEA +44 (0)20 8659 2300 salesadmin@rosco.com...
-
Page 18: Technical Specifications
TECHNICAL SPECIFICATIONS Luminaire Input Voltage: 14Vdc, 1050mA Maximum Power Consumption: 14 Watts at maximum output Output: 650 lm (3000k) 1050 lm (5500k) 2,250 mW (UV) Drivers Protocol: Mains Dim / 0-10V / Non-dim / DMX RDM Input Voltage: 100-277VAC (Triac control is 120 VAC compatible) Output: 8-14Vdc Power Consumption:... - Page 19 Power/Data Connection: 2m (6-ft) Insulated Cable/Gland (IP65), unterminated Operating Temp.: -13° F to 122° F (-25° C to 50° C) Dimensions: 4.7 in x 3.4 in x 1.9 in (119 mm x 84.2 mm x 48 mm) excluding yoke 5.17 in x 3.5 in x 9.57 in (131.2 mm x 89 mm x 243 mm) including pendant Weight: 2.2 lbs (1.0 kg) –...
-
Page 20: Warranty
This warranty does not cover damage to the Rosco Product caused by parts not manufactured, distributed or certified by Rosco. Rosco is not obligated to provide warranty service should the Product fail to be properly maintained or fail to function properly as a result of misuse, abuse, improper installation, neglect, improper shipping, damage caused by disasters such as flood, fire and lightning, improper electrical current or unauthorized service repairs other than those by a Rosco Authorized Servicer. - Page 21 OF MERCHANTABILITY, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED IN THIS WRITTEN WARRANTY AND UNLESS EXCLUSIONS ARE SPECIFICALLY FORBIDDEN BY STATE LAW, NEITHER ROSCO NOR ITS AFFILIATES WILL BE LIABLE FOR ANY LOSS, INCONVENIENCE, OR DAMAGE, INCLUDING DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURY TO PERSONS OR PROPERTY, RESULTING FROM THE USE OR INABILITY TO USE THE ROSCO PRODUCT, WHETHER RESULTING FROM BREACH OF WARRANTY OR ANY OTHER LEGAL THEORY.
- Page 22 5007481...
