HT Simple Touch Programming Instruction

15-Channel Remote Programing Instruction
Step 1. 15-Channel Remote Frequency Connection
Setp 2. Setup Top Limit
Press Up button to move shade to top limited location.
Press Up and My Favorite buttons at the same time for 5 seconds.
You will hear 3 short "B".
Top limit setup completed.
Setp 3. Setup Bottom Limit
Press Down button to move shade to bottom limited location.
Press Down and My Favorite buttons at the same time for 5 seconds.
You will hear 3 short "B".
Bottom limit setup completed.
Step 4. Setup My Favorite Position
Operate the shade to your favorite position.
Press My Favorite button for 5 seconds. Wait for a short "B".
Then press My Favorite button again for 3 seconds. Wait for 3 short "B".
My Favorite position setup completed.
*
Hide unused channels on remote
*
Unhide channels on remote
*
Reset/ Re-programing
Press Up, My Favorite, and Down buttons at the same time. Don't release until you hear a long "B".
Start programing from Step 1 to Step 4 above.
February 2019
Back side of remote
Press and hold Left and Right buttons at the same time, and then "C" will show on the screen. Wait
until "15" shown on the screen, then release buttons.
Press Left or Right button to select how many channels you want to show on the screen. For
example, if you only have 10 motorized shades connected to this remote, please select "10".
Press and hold My Favorite button (a small "0" will appear first) until channel number shown on
the screen again.
Setting completed.
Press and hold Left and Right buttons at the same time, and then "C" will show on the screen.
Wait until "15"shown on the screen, then release buttons.
Press My Favorite button (a small "0" will appear on screen).
Setting completed.
Simple Touch 15-Channel Remote
Use Left or Right button to select channel from
1 to 15.
Press motor receiver with pin or paper clip for
2 seconds. Wait for motor to "jog".
Click P2 button (on back of remote) with pin
or paper clip, and then wait for motor to "jog".
Click P2 again and wait for another "jog".
Click Up button.
RF connection completed.
