Wine storage cellar
INSTRUCTION FOR USE –
AVV80 AVV168B AVV206

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVV80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avintage AVV80

Summary of Contents for Avintage AVV80

  • Page 1 Wine storage cellar INSTRUCTION FOR USE – AVV80 AVV168B AVV206...

  • Page 2: General Safety Instructions

    Before use, please read and follow the safety rules and operating instructions in this manual. Firstly, we would like to thank you for purchasing an AVINTAGE product and hope that this appliance fully lives up to your expectations. This appliance enables you to bring your bottles at room temperature or bring them to service temperature (depending on the bottles) thanks to its wide adjustment range.
  • Page 3 Make sure that your electrical installation's voltage corresponds to that on the appliance’s nameplate; the appliance must be connected to an approved, earthed system. Incorrect repairs or connections can cause safety hazards. Have your electrical installation checked by a professional, if you are in any doubt. This unit must be correctly connected to an earthed socket for your protection.
  • Page 4 mains cable, plug or the appliance itself in water or any other liquid. Do not handle the appliance with wet hands. Keep the appliance away from any source of heat and out of direct sunlight. Do not allow the mains cable to hang from a table or be in contact with sharp edges or hot surfaces.
  • Page 5 If you are discarding the appliance, pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent children playing from suffering an electric shock or from closing themselves inside it. If this appliance, featuring a magnetic door seals, is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make the spring lock unusable before you discard the old...
  • Page 6 WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. WARNING — Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction and ensure that air can circulate, especially if the appliance is recessed into a wall.
  • Page 7 Caution: risk of fire If the refrigerant circuit should be damaged:  Avoid opening flames and sources of ignition.  Thoroughly ventilate the room in which the appliance is situated. It is dangerous to alter the specifications or modify this product in any way.
  • Page 8 children. In case of doubt, contact your installation technician. Daily use This appliance is intended to be used exclusively for the storage of wine. Do not store flammable gas or liquids in the appliance. There is a risk of an explosion. Do not operate any electrical appliances in the appliance (electric ice cream makers, mixers etc.).
  • Page 9 disconnect the appliance. When cleaning the appliance, do not use metal objects, steam systems, volatile fluids, organic solvents or abrasive substances. Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or explosion. Do not use sharp or pointed objects to remove ice. Use a plastic scraper.
  • Page 10 In order to avoid fire risk, wherever possible, ensure that the appliance is not in contact with walls or with any hot element (compressor, condenser). Observe installation recommendations. The appliance should not be placed close to radiators or cooking hot plates or gas rings. Check that electrical sockets remain accessible when the appliance is installed.
  • Page 11 The appliance is designed for home use only. The manufacturer declines any liability whatsoever in the case of other use. R600a Safety instructions Caution — Do not obstruct the ventilation grills on the appliance. Keep ventilation openings in the appliance enclosure or in the structure for building-in clear of obstruction.

  • Page 12: Description Of The Appliance

    2. DESCRIPTION OF THE APPLIANCE Temperature digital display Carbon filter (depending on models) Air circulation hole Adjustable foot 3. TECHNICAL CHARACTERISTICS Below is an example of the nameplate: The name plate attached to the inside or rear of the appliance (depending on the model) includes all the information specific to your wine cellar.

  • Page 13: Installation Instructions

    We recommend that you make a note of its serial number in this booklet prior to installation, so that you can refer to it later (technical work, request for assistance, etc.) Once it is installed and loaded, access to it is not so easy. CAUTION: No assistance can be provided without this information.
  • Page 14 Pure air continually changed and filtered. Your Avintage wine cellar is equipped with a continuous fresh air system, filtered by a charcoal filter. This is a 5- cm diameter black plastic washer in the top left of the cellar at the back. It should be replaced annually and can be bought from our partner website www.vinokado.com...
  • Page 15 CAUTION! The filter is inserted in a plastic part. Do not try to remove all the parts, ONLY the filter. Pulling or pushing the plastic receptacle may be not reparable as foamed in the body. The anti-vibration system Wine does not like to be disturbed. It especially dislikes vibration. This is why your wine cellar’s slow-cycle compressor is mounted on special shock absorbers called "silent blocks".
  • Page 16 evaporation tray which is located in the back of the appliance near the compressor. The heat produced by the compressor then evaporates the condensates collected in the tray. Lock (depending on model) For cellars fitted with a lock, the keys can be found in the bag along with the manual. To open the cellar, turn the key anti clockwise.
  • Page 17 6. LOADING The maximum recommended bottle loading quantities are guidelines and are not contractually binding; they provide a quick estimate of the size of the appliance (similar to the litre capacities of refrigerators). They relate to tests conducted with a standard bottle: the “75 cl traditional Bordeaux” bottle. How to fill and maintain your wine cellar: Your wine cellar is delivered with one or more wine bottle trays made of metal or wood.

  • Page 18: Care And Maintenance

    7. CARE AND MAINTENANCE Before cleaning your appliance (something that should be done regularly), disconnect it by removing the plug or by pulling the fuse on the circuit. Before using your appliance for the first time and regularly after that, we recommend that you clean the inside and outside (front, side and top) with warm mixed with a gentle cleaning product.

  • Page 19: Problems And Solutions

    ’ F THESE CHECKS REVEAL NOTHING THEN CONTACT YOUR RETAILER FTER ALES EPARTMENT CAUTION! Unplug the appliance before carrying out any maintenance or repair work. 9. PROBLEMS AND SOLUTIONS You can solve many simple problems with your wine cellar yourself, thus avoiding having to contact your after- sales department.
  • Page 20 Taking an average of these two values, we obtain an average humidity of 55%. It is essential to calculate an average value over several cycles and not from a single reading. To increase the humidity in the cellar, there are two alternatives: Place a jar of water in the upper part of the cellar Raise the temperature slightly inside the cellar...

  • Page 21: Some Useful Information

    This is not detrimental to your wine and is a normal phenomenon during the first few days of use. There is water in the bottom of the cellar Ensure that the two front feet are slightly raised. Ensure that the condensation water evacuation pipe is not blocked.
  • Page 22 As we continuously improve our products for the benefit of our customers, we reserve the right to modify technical characteristics without notice. Warranties for AVINTAGE brand products are offered exclusively by selected retailers. No part of these instructions may be considered as a supplementary guarantee.
  • Page 23 EUROPEAN DATA SHEET according to the regulations (UE) N°1060/2010 CONSERVATION WINE CABINET BRAND AVINTAGE COMMERCIAL REFERENCE AVV80 POWER SUPPLY 220-240 V / 50 Hz PRODUCT DIMENSIONS (W x D x H) 620 x 730 x 825 mm NET WEIGHT 42,5 kg...
  • Page 24 EUROPEAN DATA SHEET according to the regulations (UE) N°1060/2010 CONSERVATION WINE CABINET BRAND AVINTAGE COMMERCIAL REFERENCE AVV168B POWER SUPPLY 220-240 V / 50 Hz PRODUCT DIMENSIONS (W x D x H) 620 x 710 x 1450 mm NET WEIGHT 65 kg...
  • Page 25 EUROPEAN DATA SHEET according to the regulations (UE) N°1060/2010 CONSERVATION WINE CABINET BRAND AVINTAGE COMMERCIAL REFERENCE AVV206 POWER SUPPLY 220-240 V / 50 Hz PRODUCT DIMENSIONS (W x D x H) 700 x 710 x 1330 mm NET WEIGHT 72 kg...
