Preparing AC Input Cables and Connecting Waterproof Connectors
Flat-head
Scale line
screwdriver
(Unit: mm)
Installing Power Cables and Signal Cables
10.4
NOTICE
Ensure that caps and waterproof connectors are installed at all idle ports on the modules.
Installing an RJ45 Communications Cable for a Lithium Battery
Connecting Cables Between the Function Module and Lithium Batteries
PV input
AC input
Function module
Lithium battery
Lithium battery
11
