- Page 1 OPERATION AND PARTS MANUAL HAND HELD POKER VIBRATOR P14-E LIEVERS HOLLAND Groot Mijdrechtstraat 68 – 3641 RW Postbus 103 - 3640 AC Mijdrecht (NL) Phone.: 0031 – (0)297-231900 / Fax: 0031 – (0)297-231909 E-mail: info@lieversholland.nl / Internet: www.lieversholland.com...
-
Page 2: Table Of Contents
Lievers Holland. Lievers Holland may not be held responsible for any guarantees or liabilities for the contents of this publication and points to, in this case, all implied securities for suitability of merchantability or any other purposes. -
Page 3: Preface
Alternations of the machine carried out by other than manufacturer. This also includes assembling of non-original parts. Guarantee certificate P14 nr: _______________________________ Date of purchase: ___________________________________ Fig. 1: example label P14-E The label can be found under the handle on the motor housing. 3/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 4: Introduction
1. hose coupling 2. vibrating hose 3. handle 4. switch 5. ventilation slot 6. electric cable 7. motor housing + electrical motor 8. flexible spindle 9. pendulum 3. Technische specificaties 10. vibrator housing 4/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 5: Technical Specifications
230 V/1-fase/50 Hz Current consumption 3 Ampère Mass (without poker) 3 kg Figure 4: Measurements in mm of the P14E drive unit Isolation class IP54, splash proof insulation Double insulated, S.E.V.-TÜV-/GS-tested. Design Portable. 5/20 Operation manual P14-E, revision 3: 08-06-2012... - Page 6 3 hours (comfort value) to a max. of 11.7 hours per day safely. Table 1: View of the assortment of flexible poker vibrators The flexible poker vibrator with a pokerhead of 38 and 45 millimetres are available with rubber caps. 6/20 Operation manual P14-E, revision 3: 08-06-2012...
-
Page 7: Safety
Be careful when lifting and carrying the poker vibrator. Do not bend forwards when picking up the apparatus, but bend your knees. Ensure that the working area is within your reach, so that you do not have to bend forward. 7/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 8: Remaining Risk
When operating frequently, it is obligated to wear vibration reducing gloves. The manufacturer describes this as a rest risk. Nevertheless, well instructed operators with a correct working attitude concerning safe operating are well capable of working safely with the P14E. 8/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 9: Use
1) Pull the handle of the quick release upwards (4). 2) Pull the hose coupling (3) from the motor coupling (1) and pull the flexible drive shaft out of the drive pin (2). 9/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 10: Operation & Application
-Vibration time 3 to 4 seconds. -Pull the flexible poker vibrator slowly out of the concrete and move it. -The next vibration places at a distance of ± 50 cm. from one another. 10/20 Operation manual P14-E, revision 3: 08-06-2012... - Page 11 -Pull the flexible poker vibrators out of the concrete slowly and move it. -The next vibration places at a distance of ± 50 cm from one another. -Now ready for the following pour of ± 100 cm of concrete. 11/20 Operation manual P14-E, revision 3: 08-06-2012...
-
Page 12: Maintenance
9) Attach the ventilation cap to the motor housing with three screws. 10) Carry out the same operation in this section for the other ventilation cap. 12/20 Operation manual P14-E, revision 3: 08-06-2012... - Page 13 Figure 10: DO NOT LUBRICRATE . O NOT LUBRICATE THE PENDULUM AND THE POKER HEAD HE FLEXIBLE DRIVE SHAFT OF THE POKER VIBRATOR HAS BEEN LUBRICATED DURABLY BY THE MANUFACTURER Figure 11: Cleaning of the poker housing . 13/20 Operation manual P14-E, revision 3: 08-06-2012...
-
Page 14: Troubleshooting, Repairs
7.Trouble shooting, repairs The table below shows the most occurring problems, causes and solutions: PROBLEM CAUSE SOLUTION The connected and activated The electrical motor has Prevent the flexible poker vibrator of getting electrical drive-unit keeps been overloaded, jammed between the reinforcement. Stop tripping out. -
Page 15: Dismantling, Disposal
National and local regulations concerning dismantling and disposal of materials need to be obeyed. According to our knowledge, handheld poker vibrator P14E does not contain material which is a danger to the environment. 15/20 Operation manual P14-E, revision 3: 08-06-2012... -
Page 16: Part Lists
9. Part lists Figure 12: Exploded view P14E drive unit 16/20 Operation manual P14-E, revision 3: 08-06-2012... - Page 17 0293M Screw 1101220480N Switch 1101220500 Strap 1101220510 Drive motor 230V complete 1101220520 Thermical relay (option) 1101220530 Plastic screw cap (option) 1101220540N Plastic motor housing ( excl. handle) 1101220510 Drive motor complete 115 V 17/20 Operation manual P14-E, revision 3: 08-06-2012...
- Page 18 Figure 13: Exploded view poker vibrator / hose 18/20 Operation manual P14-E, revision 3: 08-06-2012...
- Page 19 Steel point 38 mm 1100380011 Rubber tip 38 mm 1100450001 Vibrator housing 45 mm 90/1 1100450003 Vibrator housing interchangeable 45 mm 1100450002 Pendulum 45 mm Table 4: Partlist P14E for the flexible poker vibrator 19/20 Operation manual P14-E, revision 3: 08-06-2012...
-
Page 20: Declaration Of Conformity
2) complies with the following harmonised standards: NEN-EN-60204-1 (2006), NEN-EN 12649, EN 60034-5 (2001), NEN-EN-IEC 60745-2-12, EN 60034-1 , EN61000-3-2, EN 61000-3-3 Mijdrecht, July 1st, 2010 Supplier: Bouwmachinefabriek Lievers B.V. Address: Groot Mijdrechtstraat 68, 3641 RW Mijdrecht Name: C.M. de Wit Position: Managing director 20/20 Operation manual P14-E, revision 3: 08-06-2012...
