Bull Outlaw 26038 Assembly & Operating Instructions
30 inch grill heads
Hide thumbs
Also See for Outlaw 26038:
- Assembly & operating instructions (20 pages) ,
- Assembly & operating instructions (35 pages) ,
- Assembly & operating instructions (34 pages)
Related Manuals for Bull Outlaw 26038
Summary of Contents for Bull Outlaw 26038
- Page 1 30 INCH GRILL HEADS ASSEMBLY & OPERATING INSTRUCTIONS OUTLAW LONESTAR SELECT ANGUS MODEL #26038 (L.P.) MODEL #87408 (L.P.) MODEL #47628 (L.P.) MODEL #26039 (N.G.) MODEL #87409 (N.G.) MODEL #47629 (N.G.) USA EDITION...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE # SAFETY INSTRUCTIONS…………………………...…………………………………………………….………………………..…………………………..2 THE LOCATION FOR YOUR GRILL ..................................2 CHECKING FOR GAS LEAKS ....................................2 NATURAL GAS SAFETY ......................................3 PROPANE GAS SAFETY ......................................4 INSTALLATION INSTRUCTIONS…………………………………………………………………………………………..………………….……....5 GRILL LOCATION ........................................5 GRILL VENTILATION ........................................ 6 CONNECTING TO GAS SOURCE ................................... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS BEWARE OF SPIDERS CAUTION: BURNERS MUST BE INSPECTED AND CLEANED BEFORE FIRST USE. Spiders and small insects occasionally spin webs or make nests in the burners during warehousing, transit and/or after long periods of non- use. These webs can lead to a gas flow obstruction, which could result in a fire in and around the burner tubes. - Page 4 WARNING: Gas valves are pre-set at the Bull factory to operate on LP Gas or Natural Gas. If you wish to convert to a different gas type, other than LP or NG, be sure to contact your grill dealer, licensed plumber or authorized service center for further details.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING YOUR GAS GRILL In the United States your gas grill must be installed in accordance with local codes or, per the latest NFPA 54/ANSI (Z223.1) edition of the National Fire Prevention Association In Canada, your gas grill must be installed in accordance with local codes or, per the latest edition of the Canadian Standards Association Code CGA B149.2 for Natural Gas and Propane Installation of Gas Burning Appliances and Equipment... -
Page 6: Grill Ventilation
GRILL VENTILATION INSTRUCTIONS Upper and lower level vents must be provided for combustion air on both sides of built-in cabinet. Vents on Grill insert must remain unobstructed to allow for combustion air and ventilation. Upper vents must be located within 5 inches from the top of the island enclosure to the bottom of the vent. Lower vents must be located within 1 inch from the bottom of the island enclosure to the bottom of the first vent openings and no more than 5 inches from the bottom of the island enclosure to the top of the vent. -
Page 7: Connecting To Gas Source
Bull purchase last longer. NATURAL GAS CONNECTIONS IMPORTANT: Bull Outdoor Products does not recommend the use of any quick connect fittings or lines to the unit. Use of these types of fittings or lines could cause low gas flow and greatly reduce the performance of the unit. - Page 8 OUTDOOR INSTALLATION SPECIFICATIONS FOR MODELS #26039, #87409 & #47629 USING NATURAL GAS (NG) NOTE: 1) Vents must be provided for combustion air and ventilation on both sides of built-in cabinet. 2) When choosing a location for your gas grill, keep in mind that it should never be located under any overhead combustible construction.
- Page 9 OUTDOOR INSTALLATION SPECIFICATIONS FOR MODELS #26038, #87408 AND #47628 USING LIQUID PROPANE (LP) GAS NOTE: Vents must be provided for combustion air and ventilation on both sides of built-in cabinet. When choosing a location for your gas grill keep in mind that it should never be located under any overhead combustible construction.
-
Page 10: Lp Gas Tank Retention
LP GAS TANK RETENTION LP tank must be properly secured within the structure to prevent being knocked over. The tank retention system must be securely fastened to the bottom of the island with the use of bolts, washers. There must be a minimum clearance of 2 inches between the floor and the cylinder enclosure. Once secured, place the LP tank in the tank retention system and tighten the tank retention bolt until the tank is held securely. -
Page 11: Transformer
TRANSFORMER NOTE In order to ensure transformer and interior light system longevity, the transformer must be installed at least 6 inches above the ground. The transformer may be attached to your island material using metal screws. To install your transformer, secure two screws (not provided) through the designed mounting tabs (see illustration below). -
Page 12: Inspecting / Cleaning Burners And Gas Valve Orifices
INSPECTING AND CLEANING BURNERS AND GAS VALVE ORIFICES Following the instructions below at least once a month, or if Grill has not been used for an extended period. To reduce the chance of FLASHBACK, the procedures below should be followed. SAFETY INSTRUCTIONS PRIOR TO CLEANING YOUR GRILL ... -
Page 13: Burner Replacement Into Insert
INSPECTING AND CLEANING BURNERS AND GAS VALVE ORIFICES, (CONTINUED) BURNER REPLACEMENT INTO INSERT CAUTION – Always turn off the gas supply prior to cleaning your grill Replace burner back into the grill insert. There is no need to replace the cotter pin back into the cast peg, it is for shipping purposes only. 1) Check the burner for proper location after replacing. -
Page 14: Burner Operation Check
INSPECTING AND CLEANING BURNERS AND GAS VALVE ORIFICES (CONTINUED) BURNER OPERATION CHECK NOTE: Upon first assembly, the gas lines and burners will be full of air. For the burners to light properly, the lines must fill with gas. It may require several attempts at lighting the burners before you are successful. 1) With BBQ Grill control knobs in “OFF”... -
Page 15: First Use Or New Season Guidelines
FIRST USE OR NEW SEASON GUIDELINES IMPORTANT Before first use and at the beginning of each barbecue season: 1) Wash flame tamers, cooking grids, and warming rack with warm, soapy water. 2) Rinse and dry thoroughly. 3) Season metal surfaces with cooking oil and occasionally throughout the season. 4) After cooking is completed, turn grill to high setting for NO MORE THAN five minutes to burn off excess grease or food residue. - Page 16 GRILL LIGHTING PROCEDURE LIGHTING MAIN BURNER(S): 1) Become familiar with the safety guidelines at the front of the manual. DO NOT SMOKE WHILE LIGHTING GRILL OR CHECKING GAS SUPPLY CONNECTIONS! 2) If your grill fuel source is LP, check the gas cylinder to see if it’s full. 3) Check that the end of each burner tube is properly located over each valve orifice.
-
Page 17: Operating Procedure
OPERATING PROCEDURE BURN OFF: Before cooking on your gas grill for the first time, burn the grill to get rid it of any odors or foreign matter by igniting the burners, closing the lid, and operating at “HIGH” setting for about five minutes. You may then either set the controls to “OFF” or cook on your grill immediately by turning the control knobs to a lower setting NOTE: Initially, the Ceramic Panel will have a blue flame. -
Page 18: Rotisserie Cooking
ANGUS MODELS # 47628 OR #47629 ROTISSERIE COOKING Rotisserie is mostly used to cook large pieces of meat and poultry to assure slow, even cooking. The constant turning provides a self-basting action, making food cooked on a rotisserie exceptionally moist and juicy. Rotisserie cooking generally requires 1 ½ to 4½... -
Page 19: Rotisserie Cooking With Indrect Heat
ANGUS MODELS # 47628 OR #47629 ROTISSERIE COOKING WITH INDIRECT HEAT Since indirect heat is often used in cooking on a rotisserie, a foil or aluminium drip pan is advisable to prevent excessive flare-ups. Generally, the cooking grates are removed to allow for the swing of the rotisserie. A basting pan can be placed under the rotisserie area on top of the flame tamer(s) to catch the drippings. -
Page 21: Light Bulb Replacement
LIGHT BULB REPLACEMENT LONESTAR SELECT MODELS #87408 AND #87409 ANGUS MODELS #47628 AND #47629 WARNING: If light bulb(s) need to be replaced, make sure power is disconnected and grill and light bulbs are completely cool to the touch. Your Grill uses G4 base 12 volt 5 watt bulbs. -
Page 22: Light System Wiring Diagram
LIGHT SYSTEM WIRING DIAGRAM LONESTAR SELECT MODELS #87408 AND #87409 ANGUS MODELS #47628 AND #47629 Wiring diagram: 1A - Black wire; 1B - Red wire; 1C - Blue wire; 1D - Yellow wire... -
Page 23: Cleaning & Maintenance
Chlorine, bromine, some fertilizers and other elements are extremely caustic chemicals for stainless steel. These chemicals combined with heat and humidity greatly increase the corrosiveness of these chemicals. Regular cleaning is the best way to prevent corrosion and add years of enjoyment to your Bull Stainless Steel products... -
Page 24: Troubleshooting
TROUBLESHOOTING NEVER SMOKE WHILE TROUBLESHOOTING! IF GRILL FAILS TO OPERATE PROPERLY 1) Turn off gas at source, turn control knobs to “OFF”, and wait five minutes before trying again. 2) Check gas supply/connections. 3) Repeat lighting procedure. If Grill still fails to operate properly, TURN “OFF” GAS AT SOURCE, TURN CONTROL KNOBS TO “OFF”, wait for grill to cool, and check for the following potential causes below and how to address: MISALIGNMENT OF BURNER TUBE(S) OVER ORIFICE(S) / CORRECTION: Reposition burner tube to properly seat over orifice. - Page 25 TROUBLESHOOTING (CONT.) MISALIGNMENT OF IGNITER ON BURNER / CORRECTION: • Check for proper position of electrode tip. The tip of the electrode should be pointing forward toward the front and free from grease for spark discharging. The ignition wire should be firmly connected to the valve ignition and electrode. •...
- Page 26 REGISTERING YOUR GRILL In order to validate your Bull Limited Warranty, you must complete the Warranty Registration Card within 90 days from the Proof of Purchase. You may register your unit either online at www.bullbbq.com...
- Page 27 OUTLAW GRILL PARTS LIST AND REF DRAWING MODEL #26038 (L.P.) /MODEL #26039 (N.G.) Any item with an * next to it requires a serial number...
- Page 28 LONESTAR SELECT GRILL PARTS LIST AND REF DRAWING MODEL #87048 (L.P.) / MODEL #87049 (N.G.) ITEM PART DESCRIPTION WARRANTY PERIOD 47023 INSERT ASSEMBLY Lifetime 47019 LID - FRONT 1 year 47021 LID - REAR 1 year 47022 COVER - REAR LID 1 year 47008 BACK PANEL...
- Page 29 ANGUS GRILL PARTS LIST MODEL #47628 ANGUS, ROTISSERIE, BUILT-IN, L.P. (PROPANE) MODEL #47629 ANGUS, ROTISSERIE, BUILT-IN, N.G. (NATURAL GAS) REF # PARTS # DESCRIPTION WARRANTY PERIOD 47019 LID - FRONT 1 year 47002 LID - REAR (2016 & OLDER MODELS) 1 year 47012 COVER - REAR LID (2016 &...
- Page 30 ANGUS GRILL EXPLODED ILLUSTRATION...
-
Page 31: Rotisserie Parts List And Exploded Illustration
ROTISSERIE PARTS LIST AND EXPLODED ILLUSTRATION WARRANTY IS 1 YEAR FOR ALL PARTS REF # PARTS # DESCRIPTION 16552 110 VAC MOTOR W/SWITCH 16554 MOTOR MOUNT BRACKET 16551 30" GRILL SPIT ROD 16553 LARGE 4-PRONG SPIT FORK 16591 SHAFT COLLAR 16587 1/4-20 X 1/2 THUMBSCREW 16675... - Page 32 Bull Outdoor Products, Inc. warrants to the original purchaser at the original site of delivery with proof of purchase of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
Need help?
Do you have a question about the Outlaw 26038 and is the answer not in the manual?
Questions and answers
I have a Bull model 26038 and have a new insert assembly. However, I cannot figure out how to remove the rear lid from the old one. I removed four bolts from each side, but there are apparently screws or bolts in the back of the unit I cannot see or reach. Any ideas on what has to be removed to reach them?
After removing the side bolts, slide the rear lid out and away from the grill housing.
This answer is automatically generated
