Dr. Mach Mach 120 Mounting Instructions, Directions For Use

Wall attachment
Hide thumbs Also See for Mach 120:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Use Manual
Wall attachment Mach 120/130
Mach LED 120/130
Mounting instructions Directions for use
Wall lamps:
Dr. Mach
59860002
WALL ATTACHMENT
MACH LED 120/130
MACH 120/130
Mach 120...............................
Mach 120F.............................
Mach 130...............................
Mach 130F.............................
Mach LED 120.......................
Mach LED 120F.....................
Mach LED 130.......................
Mach LED 130F.....................
GmbH u. Co., Flossmannstrasse 28, D-85560 Ebersberg
Tel.: +49 (0)8092 2093 0, Fax +49 (0)8092 2093 50
Internet: www.dr-mach.com, E-mail:
Order No. 120 110 2202
Order No. 120 220 2202
Order No. 130 120 2202
Order No. 130 230 2202
Order No. 120 310 2202
Order No. 120 420 2202
Order No. 130 330 2202
Order No. 130 430 2202
info@dr-mach.de
Edition 11
Dr. Mach
Lamps and Engineering
25.25.2011 / Bak Page 1/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mach 120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dr. Mach Mach 120

Summary of Contents for Dr. Mach Mach 120

  • Page 1 Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering Mounting instructions Directions for use WALL ATTACHMENT MACH LED 120/130 MACH 120/130 Wall lamps: Mach 120....... Order No. 120 110 2202 Mach 120F......Order No. 120 220 2202 Mach 130.......

  • Page 2: Table Of Contents

    4. Electrical connection......................Page 10 4.1 Preparing the electrical connection ................Page 10 4.2 Position of transformer – Dr. Mach lamps..............Page 10 4.3 Wiring diagrams ......................Page 10 5. Mounting the articulated arms and the lamp head ............Page 11 5.1 Mounting the articulated arms to the wall bearing .............

  • Page 3: Wall Attachment Mach

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering Static inspection Note: The static (structural) inspection must be carried out before the installation of the ceiling or wall anchorage! The strength of the construction must be designed, checked and certified by a structural engineer.

  • Page 4: Safety Instructions

    The manufacturer is not responsible for damage to persons or property caused by incorrect or improper use, or when used for incorrect purposes. In view of the slight weight of the Dr. Mach lamps, it is not fundamentally necessary to drill through the wall and use a counter-plate.

  • Page 5: Mounting Layout Wall Lamps

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 2. Mounting layout wall lamps Type 1: Mach 120; Mach 120F Wall bearing Wall Lamp Bracket Spring arm Type 2: Mach 130; Mach 130F Wall bearing Wall Lamp...
  • Page 6 Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering Wall bearing Light Wall Spring arm Bracket 59860002 Edition 11 25.25.2011 / Bak Page 6/19...

  • Page 7: Wall Attachment

    20mm. Electrical connection is carried out later using a 2m long cable provided by Dr. Mach with shock-proof plug on the wall arm. It is important to check whether there is an appropriate plug socket in the vicinity.

  • Page 8: Mounting The Wall Bearing

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 4.2 Mounting the wall bearing For mounting the wall bearing proceed as follows: Fastening with dowels • wall bearing with dowels recommended by the structural engineer. • Place cover 1, cover 2 and cap 3 in position in such a way that they engage in the locks.

  • Page 9: Wall Attchments, Room Heights

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 4.2.1 Wall attachment, room heights Wall attachment R700 Room heights H wall attachments Lower borehole for Lamps wall bearing (min) Mach 120 2274 Mach 120F 2274 Mach 130...

  • Page 10: Electrical Connection

    The socket used must be installed according to IEC or VDE 0100-710 requirements. In case of the lights Mach LED 120, Mach LED 120F, Mach 120 and Mach 120F the transformer is positioned in the wall bearing.

  • Page 11: Mounting The Articulated Arms And The Lamp Head

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 5. Mounting the articulated arms and the l head 5.1 Mounting the articulated arms to the wall bearing To mount the articulated arms proceed as follows: • Loosen the screw 1.

  • Page 12: Mounting The Lamp To The Spring Arm

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 5.2 Mounting the lamp to the spring arm ATTENTION! Notice the rated voltage information! Coupling journal Lamp bow Sticker with voltage information Each lamp has a red sticker applied near the coupling journal at the lamp bow. The sticker shows the rated voltage of the lamp.
  • Page 13 Mounting the lamp Mach 120/120F to the spring arm • Loosen brake screw 1, so the plastic bushing 2 can be slipped easy onto the spring arm.

  • Page 14: Cleaning

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 6. Cleaning Note: Before doing any cleaning work turn off the lamp, disconnect from mains and make sure that the lamp cannot be switched on again. Please ensure that no disinfection liquid flows into the joints or lamp head.

  • Page 15: Adjusting The Spring Force

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 7.2 Adjusting the spring force Springs are wearing parts, thus the spring force can decrease in time and must be readjusted. Note: Set the spring force in such a way, that the spring arm with the lamp head holds its position at every set height.

  • Page 16: Data

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 8. Data 8.1 Technical data Wall attachment Rated voltage 120V / 230V Rated frequency 50 / 60Hz Power consumption Rated current at 24V 2,5A Protection class The device is not suitable for use in combustible blends of anaesthesia agents with air or for use in combustible blends of anaesthesia agents with oxygen or nitrous oxide.

  • Page 17: Dimensions And Range Of Movement

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 10. Dimensions and range of movement Rmax=1900 R700 59860002 Edition 11 25.25.2011 / Bak Page 17/19...

  • Page 18: Spare Parts

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 12. Spare parts 17,26 01,02,03 23,24 11,26 23,24 11,26 Mach 120 Mach 130 18,19,20 16,27(25) 16,27(25) 21,22 59860002 Edition 11 25.25.2011 / Bak Page 18/19...

  • Page 19: Spare Parts List

    Dr. Mach Wall attachment Mach 120/130 Mach LED 120/130 Lamps and Engineering 13. Spare parts list Item Qty. Name Part no. Remark Wall bearing 230V / 24V with power supply 60W 74844004 For Mach 120/120F Halogen Wall bearing 230V / 24V with power supply 60W...
