  • Page 1 ® Operator’s Manual...
  • Page 3 CE Marking: This product (model number 2800) is a CE-marked product. For conformity information, contact LI-COR Support at http://www.licor.com/biotechsupport. Outside of the U.S., contact your local sales office or distributor.
  • Page 4 Notes on Safety LI-COR® products have been designed to be safe when operated in the manner described in this manual. The safety of this product can not be guaranteed if the product is used in any other way ® than is specified in this manual. The Odyssey Fc Imager is intended to be used by qualified personnel.
  • Page 5 LI-COR, Odyssey, MPX, and IRDye trademarks contained in the Software Product are trademarks or registered trademarks of LI-COR, Inc in the United States and other countries. Third party trademarks, trade names, and product names may be trademarks or registered trademarks of their respective owners. You may not remove or alter any trademark, trade names, product names, logo, copyright or other proprietary notices, legends, symbols, or labels in the Software Product.
  • Page 6 States and other countries. The Odyssey Fc Imaging System, FieldBrite XT technology, and IRDye reagents are covered by U.S. patents, foreign equivalents, and patents pending.

  • Page 7: Table Of Contents

    ® Odyssey Table of Contents Imager Page Chapter 1: Installation and Safety Information Safety Considerations Laser Safety Safety Interlocks Placement in the Laboratory Ambient Laboratory Conditions Instrument Ventilation Space Requirements Moving the Instrument Chemical Safety Electrical Considerations Power Cords Fuse Replacement Chassis Ground Access Hole Chapter 2: System Overview External Panels and Controls...
  • Page 8 Cleaning the Fan Filter Front Panel Warning Light Indicates an Error Resetting the Instrument Desiccant Replacement Replacement Procedure Obtaining Technical Support Chapter 4: Appendix Specifications Embedded Firmware Source Code...

  • Page 9: Chapter 1: Installation And Safety Information

    Safety Act of 1968 are required to furnish various reports to the CDRH. The Odyssey Fc Imager is certified as a Class I laser product. This means that hazardous laser radiation is not emitted outside the instrument. Radiation emitted inside the Odyssey Fc Imager is confined within protective housings and external covers.

  • Page 10: Safety Interlocks

    Where there is a potential for class 4 laser radiation behind a given panel, the label in Figure 1-4 is affixed to the panel. The label shown in Figure 1-4 is affixed to the Odyssey Fc Imager in two locations; one on top of the camera hood and one on the inner front access panel (Figure 1-3).

  • Page 11: Placement In The Laboratory

    Instrument Ventilation The air intake fan on the back of the Odyssey Fc Imager (Figure 2-4) is used to cool the internal electronics and maintain fresh air circulation throughout the internal volume of the instrument. The air intake is filtered and the filter should be periodically cleaned (see Maintenance on page 15).
  • Page 12 Chapter 1: Installation and Safety Information 8) Level the instrument to prevent liquid from pooling in the imaging tray and to keep the instru- ment from tilting. The instrument can be leveled by turning the threaded metal inserts located in each of the 4 plastic feet (Figure 1-5).

  • Page 13: Chemical Safety

    This is a necessary safety feature. If you are unable to insert the plug into the outlet, you will need to replace the outlet. Do not defeat the purpose of the grounding-type plug. Do not locate the Odyssey Fc Imager where the power cord will be walked on or exposed to water or chemical spills.
  • Page 14 Page 6...

  • Page 15: Chapter 2: System Overview

    Image drawer (closed) storage shelf Figure 2-1. Front panel features and controls of the Odyssey Fc Imager. Power On/Off Button: Pressing this button momentarily turns the instrument on and off. Pressing the button for 5 seconds or more cuts power to the instrument (see Maintenance on page 15).
  • Page 16 Chapter 2: System Overview ™ maintained. The indicator light is off only if communication is lost or Image Studio Software is closed or the instrument is powered off. Figure 2-2. Location of the green image acquisition light and red error light. Red Error Indicator: The error indicator light illuminates when a particular process could not be completed.

  • Page 17: Right-Side And Rear Panels

    ® Odyssey Fc Imager Right-side and Rear Panels Figure 2-3. Close up of the Odyssey Fc Imager control Figure 2-4. Rear panel showing air intake fan. module showing the power receptacle and Ethernet Keep the intake unblocked during operation and connectors (use only the supplied Ethernet cable).

  • Page 18: Imaging Drawer

    During an unexpected power loss, the drawer button will not function. This may leave a sample inside the Odyssey Fc Imager, or it may result in the imaging drawer being left partially open or closed. If the power remains off, the drawer can be opened or closed by pulling or pushing on the drawer front.

  • Page 19: Sample Placement

    Fc Imager Sample Placement The Odyssey Fc Imager Imaging Tray has four corner markers that delineate the edges of the Odyssey Fc imaging area. Membranes or gels up to 10 x 12 cm placed within these markers will be fully imaged.

  • Page 20: Using Membranes

    Before image acquisition starts, the imaging tray containing a membrane or gel is placed in the Odyssey Fc imaging drawer and the drawer is closed. A safety interlock prevents operation of the laser illumination module while the imaging drawer is open.

  • Page 21: Computer Connections And Networking

    (such as SYBR Safe) can be imaged in the 600 nm channel. The quality of images from the Odyssey Fc Imager is enhanced by a patented filtering system that dramatically reduces noise before detection by the CCD detector. Infrared signal detection has also ®...
  • Page 22 Page 14...

  • Page 23: Chapter 3: Maintenance

    The air intake fan on the back of the Odyssey Fc Imager is used to cool the internal electronics. Periodically inspect the air intake filter (Figure 3-1). Clean or replace the filter when it looks like dust is starting to block air flow.

  • Page 24: Front Panel Warning Light Indicates An Error

    Fc Imager is unable to complete a task requested by Image Studio Software, or some hardware failure is encountered, the red error indicator on the Odyssey Fc front panel (Figure 2-1 and Figure 2-2) flashes and an audible alarm sounds. This error condition is automatically cleared after a few seconds and a message dialog is displayed in the Image Studio software to explain the error.

  • Page 25: Replacement Procedure

    CAUTION: Remove the tray and its contents from the instrument prior to any maintenance that requires moving or tilting the instrument. 1) If necessary, turn off the Odyssey Fc Imager by first disconnecting the instrument from Image Studio Software and then briefly pressing the power button on the Odyssey Fc Imager front panel.

  • Page 26: Obtaining Technical Support

    Note: If an error message to replace the desiccant is displayed after replacing the desiccant, power off the Odyssey Fc Imager and wait an hour or two. After waiting for the air inside the camera to dry, power on the Odyssey Fc Imager, start the application software, and see if the Status changes to “Ready”...
  • Page 27 ® Odyssey Fc Imager 1) Click the Image Studio Application Button, point to Logs, and then click Export. The Zip Application Log Files dialog will open. 2) In the Zip Application Log Files dialog, keep All log files selected (unless you need to save a smaller file due to email restrictions), and choose where to save the file.
  • Page 28 Page 20...

  • Page 29: Chapter 4: Appendix

    Chemiluminescence none Visible ® ® ® Dyes: Optimized for LI-COR IRDye 680RD and IRDye 800CW reagents, and chemiluminescent substrates. Image Display Options: Pseudocolor, positive and negative grayscale, single color (red, green or blue), or two colors with overlapping fluorescence displayed in a third color.

  • Page 30: Embedded Firmware Source Code

    Fc Imager is certified as a Class 1 laser product. Hazardous laser radiation is not emitted outside the instrument. Radiation emitted inside the Odyssey Fc Imager is confined within protective housings and external covers. A series of safety interlocks ensures that laser beams cannot escape during any phase of user operation.
