SERVICE MANUAL
MICROFILM
Mass
500 g (1 lb 1.6 oz)
Dimensions
185 134 51 mm (l/w/h) (7
USB terminals
Upstream : 1, Downstream : 4
Voltage per port
DC + 5V
Current per port
500 mA (max.)
Operating temperature
0 – 40 C (32 – 104 F)
Supplied accessories
AC power cord (1), USB cable (1), Rubber feet (4), Stand (1),
Instruction manual (1)
NOTICE
This notice is applicable for USA/
Canada only.
If shipped to USA/Canada, install only
a UL LISTED/CSA LABELLED power
supply cord meeting the following
specifications:
SPECIFICATIONS
Plug Type
Nema-Plug 5-15p
Cord
Type SVT or SJT,
minimum 3
Length
Maximum 15 feet
Rating
Minimum 7 A, 125 V
SPECIFICATIONS
3
3
/
5
8
18 AWG
UH-1000
US Model
Canadian Model
AEP Model
1
/
2
/
in.)
8
8
USB HUB UNIT

Advertisement

Table of Contents
loading

Related Manuals for Sony UH-1000

Summary of Contents for Sony UH-1000

  • Page 1 AC power cord (1), USB cable (1), Rubber feet (4), Stand (1), Instruction manual (1) Nema-Plug 5-15p Type SVT or SJT, minimum 3 18 AWG Maximum 15 feet Minimum 7 A, 125 V UH-1000 US Model Canadian Model AEP Model in.) USB HUB UNIT...

  • Page 2: Table Of Contents

    ON THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS AP- PEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- MENTS PUBLISHED BY SONY. CIRCUIT ADJUST- MENTS THAT ARE CRITICAL FOR SAFE OPERATION ARE IDENTIFIED IN THIS MANUAL.

  • Page 3: General

    • Windows ® is registered trademark of Microsoft Corporation in the United States and other countries. • All other product names mentioned herein may be the trademarks or registered trademarks of their respective companies. • Furthermore, “™” and “®" are not mentioned in each case in this manual. SECTION 1 GENERAL The operating instructions mentioned here are partial abstracts...

  • Page 4: Disassembly

    UH-1000 2-1. BOX REMOVAL Two screws (+PTP 3 x 10) SECTION 2 DISASSEMBLY Two claw Box upper USB shield (upper) Two screws (+PTP 3 x 10) US board Two screws (+PTP 3 x 10)

  • Page 5: Schematic Diagrams And Printed Wiring Boards

    3-1. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Note: C1120 R1101 All capacitors are in µF unless otherwise noted. (pF: µµF) 560k C1101 LF1101 F1101 1/2W 3.15A :SURGE 250V Capacitors without voltage indication are all 50 V. C1111 Indication of resistance, which does not have one for rating 220p 250V electrical power, is as follows.
  • Page 6 — US BOARD (Conductor Side) — (us) USB CONTROL — US BOARD (Component Side) — • US BOARD SEMICONDUCTOR LOCATION Conductor Component Side Side IC1101 A–2 A–2 IC1102 A–3 A–2 IC1103 A–2 A–2 IC1201 B–1 IC1202 A–1 IC1501 B–1 IC1502 B–1 TRANSISTOR Conductor...

  • Page 7: Semiconductors

    3-2. SEMICONDUCTORS MIC2526-2BM-T&R D5SC4M TPS7233QPWR 1 TOP VIEW 8 pin SOP TOP223Y-BB HZU5.6B2TLF HZU5.6B2TRF TUSB2040PT MA8039 ANODE TOP VIEW 48 pin QFP CATHODE UPC1093J-1-T PC123F2 PC123FY2 2SC1623-L5L6 2SC2412K-T-146-QR P6KE200AG23 CATHODE D1N20R ANODE CATHODE UDZ-TE-17-3.9B ANODE ANODE D4SB60L CATHODE ‘ ‘ UF4005PKG23 CATHODE ANODE...

  • Page 8: Exploded Views

    UH-1000 NOTE: • Items with no part number and no description are not stocked because they are seldom required for routine service. • The construction parts of an assembled part are indicated with a collation number in the remark column.

  • Page 9: Packing Materials

    1-790-081-11 CABLE, USB * 4-066-558-01 TRAY * 4-066-561-01 CUSHION, REAR * 4-066-560-01 CUSHION, FRONT * 4-066-557-01 INDIVIDUAL CARTON UH-1000 Les composants identifiés per un tramé ¡ et une marque sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié.

  • Page 10: Electrical Parts List

    UH-1000 (us) REF.NO. PART NO. DESCRIPTION NOTE: The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. Les composants identifiés per un tramé ¡ et une marque sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié.
  • Page 11 R1511 1-216-663-11 METAL CHIP R1512 1-216-295-91 SHORT R1513 1-216-685-11 METAL CHIP R1514 1-216-073-00 RES,CHIP R1515 1-216-073-00 RES,CHIP R1516 1-216-053-00 RES,CHIP R1517 1-216-009-00 RES,CHIP R1518 1-216-009-00 RES,CHIP R1520 1-216-295-91 SHORT UH-1000 (us) DESCRIPTION REMARK 560K 1/2W 10% 3W 1/4W 1/4W 1/4W F 0.50%1/10W...
  • Page 12 UH-1000 (us) REF.NO. PART NO. DESCRIPTION <SWITCH> ¡ S1101 1-771-242-11 SWITCH, POWER (AJ7231BK) <TRANSFORMER> T1101 1-433-440-11 TRANSFORMER, CONVERTER (SRT) <VARISTOR> ¡ VD1101 1-801-268-51VARISTOR TNR14V471K660 <CRYSTAL> X1501 1-767-587-31 VIBRATOR, CRYSTAL 9-978-624-01 Les composants identifiés per un tramé ¡ et une marque sont critiques pour la sécurité.
