- Page 1 OPERATION MANUAL MODEL 805M1 ACCELEROMETER TE CONNECTIVITY SENSORS /// MODEL 805M1 ACCELEROMETER 05/2016 Page 1...
- Page 2 (Germany), COFRAC (France) traceable calibration services on sensitivity at 100 Hz (102 or 120 Hz in Europe) and full frequency sweeps are offered. Contact the regional headquarters for pricing information. TE CONNECTIVITY SENSORS /// MODEL 805M1 ACCELEROMETER 05/2016 Page 2...
-
Page 3: Installation
Note that the outer casing of the 805M1 accelerometer is connected to circuit ground. If ground isolation is required then a layer of adhesive or epoxy encapsulant should isolate the sensor casing from mounting surface. - Page 4 Full scale range (g) = [ExcV – 0.3V - (ExcV / 2)] / Sensitivity (V/g) WIRING For attaching wires to the header pins of the model 805M1, the following guidelines should be followed. Solder small lead wires to the header pins. The gage should be no larger than #32 AWG.
- Page 5 TE Connectivity‘s obligations shall only be as set forth in TE Connectivity‘s Standard Terms and Conditions of Sale for this product and in no case will TE Connectivity be liable for any incidental, indirect or consequential damages arising out of the sale, resale, use or misuse of the product.
