Summary of Contents for Svive LUNA S100
- Page 1 S100 LUNA CHASSIS SIDE WINDOW RADIATOR SUPPORT PSU SHROUD USB 3.0...
- Page 2 SPECIFICATIONS SPECIFICATIONS • Model: G1 • Expansion card slots: 7 slots • Case type: Middle tower ATX • Motherboard compatibility: ATX/M-ATX/Mini-ITX • Chassis size (LxWxH): 400x190x446 • Power Supply compatibility: • Weight: 4.3kg Standard ATX/ATX12V • Drive Bays: ODD Bay x 1 •...
- Page 3 3.5” / 2.5” DEVICES INSTALLATION How to Install 2.5“ SSD How to Install 3.5“ HDD • Use the screw to fix 2.5” SSD on the tray. • Fix 3.5” HDD into the 3.5” converter bracket. • Then mount it on the 2.5’’ bay area. •...
- Page 4 INSTALL POWER SUPPLY INSTALL MAINBOARD • Use 4 pcs 6x6 hexagon screw to fix the power • Lay down the case. supply. • Align the stand-off holes of the mainboard with the mainboard tray and screw in the stand-offs. • Make sure the holes on the mainboard and chassis line up properly before securing the screws.
- Page 5 INSTALL PCI • Take off the PCI slot and insert the PCI device. Put back the PCI slot and fasten the screw.
- Page 6 FAN/RADIATOR Cooling • Pull the CD cover and fix CD-ROM. 120mm Front 2 x (optional) 2 x (optional) Rear 1 x (optional) Liquid cooling (radiator thickness: up to 32mm) 120mm 240mm Front (optional) (optional) Rear (optional)
- Page 7 CABLE CONNECTION GUIDE USB 2.0 connector USB 3.0 connection HD Audio connection AUD_GND PORT1L PRESENCE# PORT1R SENSE1_RETURN PORT2R SENSE_SEND SENCE2_RETURN PORT2L AC’97 Audio connection ACCESSORY KIT AUD_GND MIC_BIAS FP_RET_R FP_OUT_R FP_OUT_L FP_RET_L Cabletie for cable management screw for HHD #6-32 screw for HDD and PSU Stand-off for mainboard M3 screw for SSD and Mainboard...
- Page 8 Imported by Svive, Østre Kullerød 4, N-3241 Sandefjord, Norway Made in China www.svivelife.com...
