- Page 1 3-095-508-12(1) Micro HI-FI Component System Operating Instructions CMT-BX7DAB © 2007 Sony Corporation...
- Page 2 LASER product. This marking is located on the rear exterior. Notice for the customer in the countries applying EU Directives The manufacturer of this product is Sony Corporation, 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
- Page 3 CD standard and may not be playable by this product. “WALKMAN” and “WALKMAN” logo are registered trademarks of Sony Corporation. MICROVAULT is a trademark of Sony Corporation. ATRAC, ATRAC3, ATRAC3plus and their logos are trademarks of Sony Corporation.
-
Page 4: Table Of Contents
Table of Contents Guide to parts and controls ... 5 Information on the display ... 9 Getting Started Hooking up the system securely ...10 Setting the clock ...12 Basic Operations Playing a CD/MP3 disc ...13 Listening to the radio ...14 Listening to music of an USB device ...15 Using optional audio... -
Page 5: Guide To Parts And Controls
Guide to parts and controls This manual mainly explains operations using the remote, but the same operations can also be performed using the buttons on the unit having the same or similar names. Unit Front panel Top panel Continued... - Page 6 Remote / (power) button (page 12, 21, Press to turn on the system. STANDBY indicator (page 18, 22) Lights up when the system is turned off. Remote sensor (page 22) (open/close) button (page 13) Press to open or close the disc tray. ...
- Page 7 TUNER/BAND button (page 14) Press to select the TUNER function. Press to select FM or AM reception mode. Unit: AUDIO IN button (page 17) Press to select the AUDIO IN function. Remote: FUNCTION button Press to select the function. DISPLAY button (page 18) Press to change the information on the display.
- Page 8 Battery compartment lid (page 11) CLEAR button (page 19) Press to delete a pre-programmed track or file. TUNER MEMORY button (page Press to preset the radio station. PLAY MODE/TUNING MODE button (page 13, 14, 16, 19, 20) Press to select the play mode of a CD, MP3 disc or an optional USB device (Digital music player or USB storage...
-
Page 9: Information On The Display
Information on the display Function Label indication (page 18) Audio format DSGX (page 18) Tuner reception (page 14) Text information Timer (page 21) DAB service reception Lights up when secondary service is received. -
Page 10: Getting Started
Getting Started Hooking up the system securely Left speaker Right speaker DAB external antenna (not supplied) Speaker cord (Red/) Speaker cord (Black/) AM loop antenna FM/DAB lead antenna (Extend it horizontally.) Brown side for other regions ... - Page 11 DAB antenna With a DAB external antenna (not supplied), you can obtain higher DAB broadcast sound quality. We recommend that you use the supplied FM/DAB lead antenna only temporarily until you install a DAB external antenna. Power Connect the power cord to a wall socket. If the plug does not fit the wall socket, detach the supplied plug adaptor (only for models equipped with an adaptor).
-
Page 12: Setting The Clock
To run the DAB Automatic Scan When you turn on the system for the first time after you purchase the system, DAB Automatic Scan starts automatically and creates a list of available services. If you want to run the DAB Automatic Scan again, perform the procedure below. -
Page 13: Basic Operations
Basic Operations Playing a CD/MP3 disc Select the CD function. Press CD Place a disc. Press on the unit, and place a disc with the label side up on the disc tray. To close the disc tray, press the unit again. -
Page 14: Listening To The Radio
Notes on Repeat Play All tracks or files on a disc are played repeatedly up to five times. “REP1” indicates that a single track or file is repeated until you stop it. Notes on playing MP discs Do not save other types of files or unnecessary folders on a disc that has MP3 files. -
Page 15: Listening To Music Of An Usb Device
To reduce static noise on a weak FM stereo station Press FM MODE repeatedly until “MONO” appears to turn off stereo reception. Notes on listening to DAB stations When tuning in a DAB station, it may take a few seconds before you hear any sound. - Page 16 Select the USB function. Press USB Connect an optional USB device (Digital music player or USB storage media) to the port as shown below. USB device (Digital music player or USB storage media) When USB cable connection is necessary, connect the USB cable supplied with the USB device to be connected.
-
Page 17: Using Optional Audio Components
Notes on the USB device Do not connect the system and the USB device through a USB hub. With some connected USB devices, after an operation is performed, there may be a delay before it is performed by this system. ... -
Page 18: Adjusting The Sound
Adjusting the sound To add a sound effect Press Generate a DSGX more dynamic sound (Dynamic Sound Generator X-tra) Set the sound effect to select “BASS” or “TREBLE, ” and then press +/ repeatedly to adjust the level. Changing the display Change information on ... -
Page 19: Other Operations
Other Operations Creating your own program (Program Play) Use buttons on the remote to create your own program. Select the desired function. Press CD to select the CD function. Press USB to select the USB function. Press PLAY MODE repeatedly until “PGM”... -
Page 20: Presetting Radio Stations
Presetting radio stations You can preset your favorite radio stations and tune them in instantly by selecting the corresponding preset number. Use buttons on the remote to preset stations. Tune in the desired station (see “Listening to the radio” (page 14)). -
Page 21: Using The Timers
Using the Timers The system offers two timer functions. If you use the Play Timer with the Sleep Timer, the Sleep Timer has priority. Sleep Timer: You can fall asleep to music. This function works even if the clock is not set. -
Page 22: Others
Find your problem in the checklist below, and take the indicated corrective action. If the issue persists, contact your nearest Sony dealer. If the STANDBY indicator flashes Immediately unplug the power cord, and check the following items. If your system has a voltage... - Page 23 (USB) port . Make sure there is no problem with the USB device. If this display pattern persists, contact your nearest Sony dealer. There is no sound. The USB device is not connected correctly. Turn off the system, then...
- Page 24 USB cable to avoid picking up noise. Connect a commercially available external antenna. Consult your nearest Sony dealer if the supplied AM antenna has come off the plastic stand. Turn off nearby electrical equipment.
-
Page 25: Messages
: The preset operation ended normally. INVALID: You pressed an invalid button. LOCKED: The disc tray does not open. Contact your nearest Sony dealer. NO DISC: There is no disc in the system, or you have loaded a disc that cannot be played. -
Page 26: Precautions
Display examples Display indicates 2 (two) 5 (five) 6 (six) 8 (eight) 0 (zero) ” Precautions Discs that this system CAN play Audio CD CD-R/CD-RW (audio data/MP3 files) Discs that this system CANNOT play CD-ROM CD-R/CD-RW other than those recorded in music CD format or MP3 format conforming to ISO9660 Level 1/Level 2, Joliet or multisession... - Page 27 On safety Completely disconnect the power cord (mains lead) from the wall socket (mains) if it is not going to be used for an extended period of time. When unplugging the unit, always grip the plug. Never pull the cord itself. ...
-
Page 28: Specifications
Specifications Main unit Amplifier section DIN power output (rated): 18 + 18 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 25 + 25 watts (6 ohms at 1 kHz, 10% THD) Music power output (reference): 38 + 38 watts (6 ohms at 1 kHz, 10% THD) Inputs: AUDIO IN (stereo mini jack): voltage 250 mV, impedance... - Page 29 DAB frequency table (Band-III) Frequencies are displayed to two decimal places on this system. Frequency Label Frequency 174.928 MHz 5A 209.936 MHz 10A 176.640 MHz 5B 211.648 MHz 10B 178.352 MHz 5C 213.360 MHz 10C 180.064 MHz 5D 215.072 MHz 10D 181.936 MHz 6A 216.928 MHz 11A 183.648 MHz 6B...
-
Page 30: Playable Usb Devices
