Summary of Contents for Stove Builder International AC02786
- Page 1 CORNER MODULAR FLOOR PROTECTION SYSTEM AC02786-AC02787 (54” x 54”) (60” x 60”) INSTALLATION INSTRUCTIONS Printed in Canada 46107A 09-04-2018...
- Page 2 Page 2...
- Page 3 SECTION 1- DIMENSIONS AC02786 AC02787 Page 3...
- Page 4 SECTION 2 – KITS CONTENTS Floor screen protection Floor screen protection Floor screen protection Floor screen protection AC02786 (PL36651) AC02786 (PL36652) AC02786 (PL36654) AC02786 (PL36650) AC02787 (PL36651) AC02787 (PL36657) AC02787 (PL36659) AC02787 (PL36658) Insulated with ½″ of Micore 300. Micore 300 is rated with a 1.03 R factor at ½″ thickness. The R factor of the floor protection must be equal or greater than the one required by the manufacturer of the appliance being installed.
- Page 5 The floor protection must cover the area mentioned in the following table: FLOOR PROTECTION CANADA 18" (457 mm) 16" (406 mm) From door opening From door opening 8" (203 mm) N/A (Canada only) 8" (203 mm)* N/A (Canada only) N/A (USA only) 8"...
- Page 6 SECTION 4 - INSTALLATION 1. Determine the appliance position following manufacturer’s recommendations. 2. Determine necessary dimensions for the floor protection. 3. Using masking tape, draw on the floor the contour where the floor protection will be installed. 4. Align one panel (A), matching the rear marks of step 3. Make sure the panel is centered with the corner of the wall.
- Page 7 7. Make sure the panels are placed inside one another correctly to protect the floor from hot embers that could fall from the appliance in between two panels that are not well fit together. Figure 4 : Correct installation Figure 5 : Incorrect installation 8.
- Page 8 Stove Builder International Inc. 250, rue de Copenhague Saint-Augustin-de-Desmaures Québec, Canada G3A 2H3 Page 8...
