Azoteq ProxSense Series Quick Start Manual

uick-Start guide for the IQS227/8AS Evaluation Kit

Step 1:Insert a Module

Insert a module into the main board.

Check the Key!

Choose the correct number of overlay(s) for the chosen module board.

Make sure it pushed flat on the PCB (removing any air-gaps)

Place two 3V coin-cell batteries in the battery terminal at the back.

Move the Slide switch (S1) to the "ON" position.

Increase the CX surface area for increased proximity distance with a jumper on P4

Power

Cycle!

IQ Switch

ProxSense

Series

Figure 1.1

Main-board

Key

Table of Contents

Need help?

Do you have a question about the ProxSense Series and is the answer not in the manual?

Page 1 ® IQ Switch ® ProxSense Series uick-Start guide for the IQS227/8AS Evaluation Kit Step 1:Insert a Module Insert a module into the main board. Check the Key! Figure 1.1 Main-board Step 2: Choose Overlay(s) Choose the correct number of overlay(s) for the chosen module board. Make sure it pushed flat on the PCB (removing any air-gaps) Step 3: Power Place two 3V coin-cell batteries in the battery terminal at the back.
Page 2 ® IQ Switch ® ProxSense Series Remove the jumper on P4 and touch the battery terminal. Power Cycle! Increase GND surface and touch on the battery terminal again. Power Cycle! Evaluate the increased proximity sensitivity by increasing the ground reference (connecting external ground from power supply or PC).
