HP RP5000 Disassembly Instructions Manual page 3

HP-00007-01, Appendix 3
POWER SUPPLY PCA
1 To remove the power supply from the chassis:
a) Remove the screw on the left side that secures the rear panel to the chassis
(see Figure 11 below).
b) Remove the two screws on the right side that secure the rear panel to the chassis and
to the power supply (see Figure 12 below).
c) Remove the rear panel from the baseplate (see Figure 13 below).
d) Slide the power supply toward the back chassis, and then remove it from the chassis
(see Figures 14 & 15 below).
2 Remove all screws from the power supply and remove the top and side panels
(see Figure 16 below).
3 Unplug all cables connected to the PCA inside of the power supply.
4 Remove the power supply PCA using a Philips screw driver (see Figures 17 & 18 below).
BATTERY
1 Locate the battery and battery holder on the system board.
2 To release the battery from the holder, squeeze the metal clamp that extends above one
edge of the battery (see Figure 19 below).
3 When the battery pops up, lift it out
