Unpacking
Please make sure the package contains the following items:
Universal Accessories :
FE-IPDS-20WM X
1
Rope X 1
M3x6 screw X 2
Rubber Plug X 3
（S,M,L）
FE-IPDS-20WM Quick Guide
Back cover X 1
Allen Wrench X 1
M4x30 screw X 2
Wall-mounting screw X 4
3/5000
Wandnagel
M2.5 x 6 screw X 6
Cable locking plate X
1
Wall-mounting bracket X 1
ST4x20 screw X 2
Screw fixing seat X 2
Advertisement
Related Manuals for Freund FE-IPDS-20WM
Summary of Contents for Freund FE-IPDS-20WM
- Page 1 FE-IPDS-20WM Quick Guide Unpacking Please make sure the package contains the following items: Universal Accessories : ST4x20 screw X 2 M2.5 x 6 screw X 6 FE-IPDS-20WM X Back cover X 1 Screw fixing seat X 2 Allen Wrench X 1...
-
Page 2: Product Overview
Product Overview Infrared LED Infrared sensor Camera Photosensitive sensor RF card reader Call button&Status LED Speaker FE-IPDS-20W... -
Page 3: Installation
Installation Step1: Bracket/Box Installation Wall Mounting With 86 embedded box in the wall Take down Mark the two holes wall-mounting M4x30 screws and of the wall-mounting bracket remove bracket on the wall. embedded box with wall-mounting two M4x30 screws. bracket. Use a hand drill Fix the wall-mounting with... - Page 4 Without 86 embedded box in the wall Mark the two holes of wall-mounting Use a hand drill with bracket on the wall for 5mm diameter bit to the screws. make four 25mm depth holes in the marked positions. Fix the wall-mounting Insert four screw fixing bracket with...
- Page 5 Step2：Back Cover Installation Make cables go through Fasten the back cover For convenient wiring, back cover, with four M2.5x6 hang FE-IPDS-20WM connecting screws, then fix four on the wall-mounting wall-mounting screws corresponding interfaces bracket with rope. of the main board. back FE-IPDS-20WM.
- Page 6 Application Network Topology (third party) SIP Video Phone Indoor Monitor Network Video Recorder (third party) FE-IPDS-20W FE-IPDS-20WM FE-IPDS-20WM FE-IPDS-20WM...
-
Page 7: Operation
Operation IP Announcement Make a call: 1. While FE-IPDS-20WM starts up normally, hold the call button for several seconds after the Status LED turns blue, voice system will enter IP 1. Press the call button to call indoor SIP Phone. - Page 8 0.25sec Receiving a call Note: For more LED settings, please refer 0.05sec 0.05sec to FE-IPDS-20WM webUI: Intercom -> LED Red/Blue Firmware upgrading Setting. FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Hercegovina...
