  • Page 1 AIRSYS COM4T Wall Mounted Heat Pump Installation and Operation Manual Unit Models CV36H2A CV60H3A...
  • Page 2 AIRSYS. The information contained in this document is subject to change without notice. AIRSYS provides this material as is and makes no warranty of any kind, expressed or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. AIRSYS...
  • Page 3: Table Of Contents

    Complete the Installation Checklist ..........................24 Chapter 4: ......................................25 System Operation ....................................25 Sequence of Operation ................................. 25 Alarms ......................................26 Complete the Registration Card ............................27 Contact: AIRSYS North America Phone: (855) 874-5380 Page 3 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 4: Chapter 1: Introduction

    Userʼs guide For safety and to achieve the highest levels of performance, always follow the warnings and cautions in this manual when handling and operating the AIRSYS unit. Danger. Emphasizes hazardous conditions that could cause personal injury or death. Indicates where the operator must proceed with caution to avoid personal injury or Warning.
  • Page 5: Model Identification

    Model Identification Each unit is identified by a model number, such as CV36H2A-AWAXX-X2XX. The elements in the number are explained in Figure 1. Figure 1: Model Number Contact: AIRSYS North America Phone: (855) 874-5380 Page 5 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com...
  • Page 6: Acronyms And Abbreviations

    Table 2 lists acronyms and abbreviations used in this manual. Table 2 : Acronyms and Abbreviations Term Meaning Ampere, unit of electric current, or rate of flow of electricity AAST AIRSYS Authorized Service Technician AUT/MAN Automatic/Manual Building Monitoring System Cubic Feet per Minute Common...
  • Page 7: Chapter 2: Product Overview

    Figure 2 Basic Operating Modes Any grille that meets the 5/8" louver criteria may be used. It is recommended that AIRSYS Return Air Grille Kit installed when no return duct is used. If using a return air filter grille, filters must be of sufficient size to allow a maximum velocity of 400fpm.
  • Page 8: Ventilation Options

    The filter medium is designed to be pulled out for easy cleaning and replacement. Table 4: ERV Characteristics ERV characteristics Dial Position Efficiency Figure 5: Energy Recovery Ventilator Contact: AIRSYS North America Phone: (855) 874-5380 Page 8 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 9: Ptc Electrical Heater

    In the event the drain hose is connected to a drain system, it must be an open or vented type system to assure proper drainage. Contact: AIRSYS North America Phone: (855) 874-5380 Page 9 of 29 Email: ASNSupport@air-sys.us...
  • Page 10: Chapter 3: Installation

    Danger: All the installation work must be done by a licensed professional. Installation that does not comply with the instructions herein can result in the loss of warranty coverage. AIRSYS shall not be held liable for any damage caused to persons or objects due to incorrect installation or operation of the units.
  • Page 11: Required Materials

    Table 6: AIRSYS System Shipping Materials List has all the material supplied by AIRSYS. After opening the package, verify that all items are accounted for. If any material is missing, please contact an AIRSYS distribution center using the following information: AIRSYS North America Web: https://airsysnorthamerica.com...
  • Page 12 Table 6: AIRSYS Provided Materials System Shipping Materials List Part # Item Description Comments CV36H2A CV60H3A 4070142980 CV36H2A-AWAXX Main Unit 4070142960 CV60H3A-AWAXX Main Unit Shipping list In document pack Installation and operation manual In document pack Blank nameplate In document pack...
  • Page 13 Plain Washers, GB/T97.1,M4 8552906140 In document pack Single coil spring lock Washers, GB/T93, 8552905160 In document pack 8458716720 Cable ties, G370HDB L=370 In document pack Contact: AIRSYS North America Phone: (855) 874-5380 Page 13 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 14 Mode Heater Size CV36H2A 12kw CV60H3A 12kw Note: MCA = Minimum Circuit Ampacity (Wiring Amps) MOP = Maximum Overcurrent Protection (HACR Breaker Size) Contact: AIRSYS North America Phone: (855) 874-5380 Page 14 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 15: Physical Installation

    2. For any unit equipped with electrical heat, the supply grille should be at least three inches away from combustible material. NOTE: To assist in the installation process, the following figures provide the unit dimensions to a tolerance of ± 1/16” (2 mm). Contact: AIRSYS North America Phone: (855) 874-5380 Page 15 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com...
  • Page 16 45.67 27.56 92.91 9.84 29.92 15.87 29.92 38.07 15.83 6.69 35.04 1.57 2.17 47.24 48.82 0.79 10.55 17.72 8.66 5.59 40.2 42.24 Contact: AIRSYS North America Phone: (855) 874-5380 Page 16 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 17 φ0.47 1200 φ12 CV60H3A inch 24.49 15.87 9.84 29.92 4.84 2.05 47.24 17.72 φ1.38 φ0.47 Figure 7: Wall Opening and Hole Location View Contact: AIRSYS North America Phone: (855) 874-5380 Page 17 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 18 Figure 8:Wall Opening and Hole Location View application. Case 3: Curb mounting with extension Figure 9: Wall Opening and Hole Location View- Contact: AIRSYS North America Phone: (855) 874-5380 Page 18 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com...
  • Page 19 CASE 1 CASE 2 CASE 3 Contact: AIRSYS North America Phone: (855) 874-5380 Page 19 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 20 Figure 11: Install Weather Stripping. Weather stripping Weather stripping Figure 11: Install Weather Stripping Contact: AIRSYS North America Phone: (855) 874-5380 Page 20 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com...
  • Page 21: Complete Electrical Connections

    Important: Noncompliance with these instructions may cause damage to the WPU or the controller box. Not following instructions can void the warranty. Important: No modification to the unitʼs electric circuit is allowed. If a change is required, it must be authorized by AIRSYS in writing. Contact: AIRSYS North America Phone: (855) 874-5380 Page 21 of 29 Email: ASNSupport@air-sys.us...
  • Page 22 Function Dehum. Fan Only Low Speed Cool High Speed Cool Low Speed Heat High Speed Heat Electric Heat (Opt.) Dehum. (Opt.) Contact: AIRSYS North America Phone: (855) 874-5380 Page 22 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 23 Optional Optional Optional Optional Optional Optional Optional Default SW2 Max Supply Fan Setting SW1-1 SW1-2 SW1-3 Max Fan Speed Level Optional or Default Contact: AIRSYS North America Phone: (855) 874-5380 Page 23 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 24: Complete The Installation Checklist

    Turn on Primary Power Turn on the primary power breakers on the heat pump unit. Contact: AIRSYS North America Phone: (855) 874-5380 Page 24 of 29 Email: ASNSupport@air-sys.us...
  • Page 25: Chapter 4

    EEV and compressor will automatic adjust to maximum latent (moisture removal) capacity. The system can seamlessly transition between cooling/heating and dehumidification without restarting the system. Contact: AIRSYS North America Phone: (855) 874-5380 Page 25 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com...
  • Page 26: Alarms

    Alarm will be indicated Humidity sensor 1 error without stopping unit Alarm will be indicated Humidity sensor 2 error without stopping unit Contact: AIRSYS North America Phone: (855) 874-5380 Page 26 of 29 Email: ASNSupport@air-sys.us Web: http://airsysnorthamerica.com Rev 1.1...
  • Page 27: Complete The Registration Card

    The information on the registration card is critical for establishing the warranty start point. The nameplate with the required information can be found on the outside of the unit. Information must be recorded on the AIRSYS Product Warranty Registration Card. The registration card can also be submitted online at: https://airsysnorthamerica.com/support/warranty-registration/...
  • Page 28 Phone #: _______________________ Email: _______________________ OWNERSHIP INFORMATION Owner: _______________________________________________________ Site Supervisor Name: _______________________ Phone #: _______________________ Email: _______________________ REGISTRATION ONLINE: airsysnorthamerica.com/support/warranty-registration BY EMAIL: Scan and send to: ASNSupport@air-sys.com By MAIL: AIRSYS Product Registration, 915 De La Vina St, Santa Barbara, CA 93101...
