RoboBuilder RQ-110 Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RQ-110 and is the answer not in the manual?

Questions and answers

Related Manuals for RoboBuilder RQ-110

Summary of Contents for RoboBuilder RQ-110

  • Page 2 Safety Instructions Warning : If user does not follow the instructions in this book properly, a serious injury, harm, or death may occur to user. Caution : If user does not follow the instructions in this book properly, an injury to user or physical damage to the product may be occurred.
  • Page 3 Usage - Do not assemble the product when you are tired or physically in a bad condition particularly while intoxicated. - Do not place your face too close to the robot. - Do not use dangerous tools such as a knife or a drill but only recommended tool. - Keep the remote control that contains batteries away from children’s reach.
  • Page 4 - Do not leave the product with power on. Battery damage may cause a product failure. - Do not give excessive force while a torque is applied to the robot. This could cause the gear damage of robot module and product failure. - When robot gets twisted by running wrong motions while programming, turn the power off quickly to prevent excessive torque from being transmitted to the robot.
  • Page 5 [ Notice for Assembly and Operation ] · All users should follow the instructions in this user manual. · The basic posture of standard platform (HUNO) robot is as shown in the below. If robot does not take the posture as the below after you press the center ( ) button of IR remote controller, it means that robot was assembled in wrong way.

  • Page 6: Table Of Contents

    < Table of Contents > 1. Basic Instruction ......................... 7 1.1 Product Introduction ........................... 7 1.2 Product Usage.............................. 8 1.3 Rivet Tool ..............................12 2. RQ-HUNO Assembly Guide....................16 2.1 Check Part List............................16 2.2 Smart servo connection and set basic posture position ..............17 2.3 Right LEG Assembly..........................

  • Page 7: Basic Instruction

    Entertainment. Design and build various robots simply by plugging together block-type robotic actuator modules. Without programming, users can download robotic motion files from the internet and play them on the RoboBuilder RQ platforms. FEATURES Quick & Simple Assembly : It can be assembled within one hour.

  • Page 8: Product Usage

    1.2 Product Usage Operating Smart Controller By manipulating the smart controller, you can select proper robot platform, and play motions. Also, you can change into various mode (such as PC direct control mode or firmware upgrade mode). 버 Button P : Power (ON/OFF) button / Run button In smart controller, ‘1’, ‘2’, ‘3’...
  • Page 9 IR remote controller registration ① Power-off the smart controller. ② Press button 2 then, press button P concurrently. → You can see LED2 - Green, Blue and Red lights together. Button P Button 2 ③ Make the IR remote controller close to smart controller towards <IR remote controller receiver>. ④...
  • Page 10 IR Remote Controller The best way to use the remote control is to have remote controller point to the center of smart controller. Press STOP ( ) button whenever power on RQ smart controller first to take the basic posture. Otherwise, IR remote controller button would not work on robot. Button Motion Button...
  • Page 11 W Cable and Smart Controller connection Smart controller has four port to connect for smart servo by using “W cable”. You can connect any port regardless smart servo IDs. * NOTE Rear side of COM port is for connection with PC or Bluetooth chip.

  • Page 12: Rivet Tool

    1.3 Rivet Tool * Rivet Tool Usage...

  • Page 16: Rq-Huno Assembly Guide

    2. RQ-HUNO Assembly Guide 2.1 Check Part List Place all the parts as the below for RQ-HUNO assembly.

  • Page 17: Smart Servo Connection And Set Basic Posture Position

    2.2 Smart servo connection and set basic posture position Set up the RQ-HUNO initial position value in advance before you assembly. This prevents confusion of smart servo position when you connect joint frame with smart servo. 1. Place all smart servos and other parts as the below. 2.
  • Page 18 3. After power-on smart controller (it is “stop” state), press STOP button of IR remote controller. If IR remote controller is not working, check whether IR remote controller is registered. (See the page 8 - IR remote controller registration) Button P STOP button 4.

  • Page 19: Right Leg Assembly

    2.3 Right LEG Assembly Smart Servo * 4 Foot Frame W Cable * 1 (ID 06, 07, 08, 09) ‘U’ Frame * 1 Joint Frame * 2 Front Horn * 1 Knee Frame * 1 Screw (P6) * 1, Bolt (B12) * 1 Bolt(B27)*4, Bolt (B35) *5, NUT * 10 3s rivet * 2 2s rivet * 8...
  • Page 20 STEP2. Insert “2s rivet” to the “Joint Frame” to connect with “Front Horn”. STEP3. Connect W Cable into smart servo “ID09” first, then connect foot frame by using Bolt and Nut. (Left) Foot Frame and (Right) Foot Frame is same.
  • Page 21 STEP4. Connect W Cable (that is already connected with ID09) with smart servo ID08 and ID07. STEP5. Connect ID09 and ID08 by using “3s rivet”. Rotate W Cable one time and fix it.
  • Page 22 STEP6. Use the Bolt (B35) and Nut to connect “ID08” and “ID07” with “Knee Frame”. STEP7. Twist cable 3~4 times between “ID08” and “ID07” and put into empty space.
  • Page 23 STEP8. Connect ID06 and ‘U’ frame by using Bolt (B27) and Nut. Then use the “2s rivet” to fix with “Joint Frame”. Be careful JOINT frame direction STEP9. Connect ID07 with “Joint Frame” by using “3s rivet”. Rotate W cable two times and connect to ID06.

  • Page 24: Left Leg Assembly

    2.4 LEFT LEG Assembly Foot Frame Smart Servo * 4 W Cable * 1 (ID 01, 02, 03, 04) Knee Frame * 1 Front Horn * 1 Joint Frame * 2 ‘U’ Frame * 1 Screw (P6) * 1, Bolt (B12) * 1 Bolt(B27)*4, Bolt (B35) *5, NUT * 10 3s rivet * 2 2s rivet * 8...
  • Page 25 STEP2. Connect Front Horn and Joint Frame by using 2s rivets. Be careful with Joint Frame direction. STEP3. Insert “W Cable” with ID04, then connect Foot Frame by using Bolt(B12, B27) and Nut. ⇦ W Cable connection to ID04 NUT connect position...
  • Page 26 STEP4. Connect W Cable with ID03 and ID02. STEP5. Connect “Joint Frame” with ID03 by using 3s rivet. Then, rotate W Cable1~2 times and fix it.
  • Page 27 STEP6. Connect ID03 and ID02 with “Knee Frame” by using Bolt (B35) and Nut. Then, rotate the W Cable 3~4 times and put into empty space. STEP7. Connect ID01 and ‘U’ frame by using Bolt (B27). Then use the 2s rivet to fix with “Joint Frame”. Be careful JOINT frame direction...
  • Page 28 STEP8. Connect ID02 and “Joint Frame” by using “3s rivet”. Then, rotate “W Cable” two times and connect with ID01.

  • Page 29: Right Arm Assembly

    2.5 RIGHT ARM Assembly 3*6 L type Frameⅹ2 Smart Servoⅹ2(ID14, ID15) ‘U’ Frame x 2 Joint Frameⅹ1 3s rivetⅹ1 2s rivetⅹ12 Bolt (B27) x 4, NUT x 4 STEP1. Make “Hand” part by using the two “3*6 L type Frame” and “2s rivets” as shown in the below. Becareful with “3*6 L type Frame”...
  • Page 30 STEP2. Connect ID15 and ‘U’ Frame by using Bolt (B27) and Nut, then connect with “Hand” part by using 2s rivets. STEP3. Connect ID14 and ‘U’ Frame by using Bolt (B27) and Nut, then, connect with Joint Frame. Be careful of Joint Frame direction when you connect with smart servo.
  • Page 31 STEP4. Connect “Joint Frame” that connected with ID14 and ID15 by using 3s rivet.

  • Page 32: Left Arm Assembly

    2.6 LEFT ARM Assembly 3*6 L type Frameⅹ2 Smart Servoⅹ2(ID11, ID12) ‘U’ Frame x 2 Joint Frameⅹ1 3s rivetⅹ1 2s rivetⅹ12 Bolt (B27) x 4, NUT x 4 STEP1. Make “Hand” part by using the two 3*6 L type Frame and “2s rivets” as shown in the below. Becareful with 3*6 L type Frame part direction because the both sides are not same.
  • Page 33 STEP2. Connect ID12 and ‘U’ Frame by using Bolt (B27) and Nut, then connect with “Hand” part by using 2s rivets. STEP3. Connect ID11 and ‘U’ Frame by using Bolt (B27) and Nut, then, connect with Joint Frame. Be careful of Joint Frame direction when you connect with smart servo.
  • Page 34 STEP4. Connect Joint Frame that connected with ID14 and ID15 by using 3s rivet.

  • Page 35: Body Assembly

    2.7 BODY Assembly Body Frameⅹ1 Smart Servoⅹ4 W Cable x 2 (ID00, ID05, ID10, ID13) 3*6 L type Frameⅹ2 Front Hornⅹ4 Joint Frameⅹ4 U Frameⅹ2 3*3 Frameⅹ1 3s rivetⅹ8 2s rivetⅹ20 double rivetⅹ10 IRⅹ1 Smart Controllerⅹ1 Li-Poly Batteryⅹ1 Charging Board*1 Screw(P6)ⅹ4, Bolt (B6)ⅹ2, Bolt (B27)ⅹ4, Bolt (B30)ⅹ4, Nutⅹ10 STEP1.
  • Page 36 STEP2. Connect “Front Horn” and “Joint Frame” by using “2s rivet” as the below. STEP3. Connect Front Horn and Joint Frame with ID00 same as the ID05 connection. Front horn chase mark should be in center position (12 o’clock direction)
  • Page 37 STEP4. Connect ID00 and ID05 with Body Frame by using Bolt (B27) and Nut. Check the ID05 and ID00 connect position well as shown in the below.
  • Page 38 STEP5. Connect “Front Horn” with ID10. Check the “Front Horn” and ID00 mark position. - Smart servo mark position is 11 o’clock while Front Horn mark position is 12 o’clock as shown in the below. STEP6. Connect “Joint Frame” with “Front Horn” by using “2s rivets” as shown in the below.
  • Page 39 STEP7. Connect Front Horn with ID13. Check the Front Horn and ID00 mark position. - Smart servo mark position is 1 o’clock while Front Horn mark position is 12 o’clock as shown in the below. STEP8. Connect Joint Frame with Front Horn by using 2s rivets as shown in the below.
  • Page 40 STEP9. Connect ‘U’ Frame with ID10 as shown in the below and connect with Body Frame by using Bolt (B30). STEP10. Connect ‘U’ Frame with ID13 as shown in the above and finish the RQ HUNO shoulder.
  • Page 41 STEP11. Assemble Head part. Connect 3*3 frame with Body Frame by using Bolt (B6) and Nut. 3*3 frame STEP12. Connect IR (Infrared Sensor) into 3*3 frame by using double rivets. .
  • Page 42 STEP13. Connect 3*6 L type frame onto chest part. STEP14. Connect “ID00 with ID01” and “ID05 with ID06” by using “3s rivet”, respectively . Then, pull the Cable outside from inside as shown in the below.
  • Page 43 STEP15. Connect “ID10 with ID11”, and “ID13 with ID14” by using “3s rivet”, respectively. STEP16. Put the first connector of W Cable into ID12, and rotate W Cable 1~2 times then put the second connector of W Cable into ID 11 as shown in the below.
  • Page 44 STEP17. Then, put the third connector of W Cable into ID 10. Put the fourth connector of W Cable Inside, then connect with ID00. STEP18. Put the first connector of W Cable into ID15, and rotate W Cable 1~2 times then put the second connector of W Cable into ID 14 as shown in the below.
  • Page 45 STEP19. Put the third connector of W Cable into ID13, and put the fourth connector of W Cable into ID05. STEP20. Arrange the “W Cabe” as shown in the below, and pull out the “W Cable” from the bottom side of “Body Frame”...
  • Page 46 STEP21. Insert four “3s rivets” to “Body frame” to fix Smart Controller as shown in the below. STEP22. Insert two “double rivets” to “Body frame” to fix “Battery” as shown in the below.
  • Page 47 STEP23. Put “Battery” to “Body Frame” as shown in the below. STEP24. Connect “W Cable” and fix Smart Controller with “Body Frame” as shown in the below.
  • Page 48 STEP25. Connect battery connector, then also connect “power cable of charing board” to the “Smart Controller power connector” as shown in the below. STEP26. Assembly completed.

  • Page 49: Check Assembled Robot

    2.8 Check Assembled Robot <Basic Posture> Let’s find out how Robot works after assembly. Firstly, power on (press button ‘P’) in smart controller. Then, press ‘stop’ button of IR remote controller towards IR remote controller receiver. IR remote controller receiver Then Robot will take the basic posture as shown in the below.
  • Page 50 <Attention Posture> Robot will take the “Attention!” posture if you press “button 1” in IR remote controller. Please check the assembly guide from the STEP1 again if robot posture is not the same as shown in the above.

  • Page 51: Zero Position Adjustment

    3. Zero Position Adjustment Zero position is robot standard posture information in order to know the difference of each robot basic posture. Every robot basic posture would be different a little because every smart servo has own tolerance. For instance, ‘A’...
  • Page 52 Press button 1 for selecting smart servo ID, then press button 2 or button 3 for smart servo rotating direction. Button 1 Button 2 Button 3 Every time you press button 1, Smart servo moves smart servo is selected in order. Smart servo moves counter clockwise “ID01, ID02, ID03….

  • Page 53: Download Cable (Uart) Driver Installation

    4. Download Cable (UART) driver Installation You need to install the download cable driver in order to use robot programming software, such as MotionBuilder, ActionBuilder, Diagnostic Tool and Firmware Upgrade Tool. 1) Download “USB Download Cable Driver” from www.RQWORLD.com and click to start installation. 2) Click “I accept the terms of license agreement”, then click “Next”.
  • Page 54 3) Click “Next” and finish the installation as shown in the below..

  • Page 55: Download Tool

    . COM Port : Designate available COM port for connection of RoboBuilder. . BaudRate : It shows data transferring speed. . OpenPort : Open PC COM port in order to connect a RoboBuilder. . ScanPort : Find available COM port and opens it automatically.

  • Page 56: Download File

    5.2 Download File In RoboBuilder Download Tool, it shows the folders and downloaded (made) motion files. Click “Delete All” in order to delete the previous downloaded files in the list. In order to insert into Download File List section, select the file then, click ‘>’ button.
  • Page 57 If you click a file in the Download File List, it shows file name, file size, robot platform, scene number, performance time. ※ If registered files are more than one in the ‘Download File List’, users can change the downloading sequence by clicking “Up” or “Down” button. ※...
  • Page 58 Click ‘ScanPort’ button in order to find available COM Port. RBC serial code and Firmware Version will be shown if connected properly. And “ClosePort” button will be shown as well. Click ‘Download” button, in order to all files in the “Download File List”. Then it starts downloading into RBC Box.

  • Page 59: Motionbuilder

    6. MotionBuilder 6.1 Introduction This document explains how to use MotionBuilder the motion building tool for RQ-HUNO. What are project file, motion file, scene, frame, transition time? Project file(*.prj) A project file contains the information such as the robot’s type and more. It is used to manage multiple motion files of a robot efficiently.
  • Page 60 Screen Layout This is the screen layout of the MotionBuilder.

  • Page 62: Motion Programming #1

    6.2 Motion Programming #1 Let’s try one simple motion programming for RQ-HUNO. 1) Run “MotionBuilder” and click “New”. Input “greeting” in Project Name, then select Robot Platform “RQ-HUNO”. 2) Click “OK”, then it shows as below.
  • Page 63 3) Connect RQ-HUNO with PC by using “Down Cable (UART)” then, power on smart controller (Button P) 4) Click “Scan Port” to search correct COM Port, or you can click “Open Port” if you know the COM Port No. 5) Click “New Motion”. Then input “hi” in Motion Name. If you want to use smart servo LED, check the “Enable External Port”, then, click “OK”.
  • Page 64 6) If you see the New Scene window, click “OK”. You can adjust “Frames”, and “Motion Run Time (ms)”. - Frames : If you increase the Frames, robot moves smoothly. -Motion Run Time : Each frame run time range is 20~1000msec. TIP.
  • Page 65 9) Move the Jog Dial of “ID11”. 10) For the next movement, add the third scene. 11) Move the Jog Dial of ID12.
  • Page 66 12) Then, let’s make the arm shaking motion like “saying Hi”. Copy the Scene 1 and Scene 2. 13) Paste the Scene 1 and Scene 2 to the next empty scene space, and do the paste again. Lastly, copy the “Scene 0” and paste to the last scene.
  • Page 67 14) Save the Motion file, Click “select All” and then click “Test” button. 15) Completed “Hi.rbm” motion movement is as follows.

  • Page 68: Change Motion Speed

    6.3 Change Motion Speed Let’s find out about frame and motion run time. We have applied basic frame and motion run time (30 frames, 1000 msec) in the previous motion 1) If you look at the scene part, you can see all the frame value is 30 and time value is 1000. you can change the frames and time as you double-click related scene.

  • Page 69: Motion Programming #2

    6.4 Motion Programming #2 In this section, we will make a deep bow HUNO motion. 1) Click “New Motion”, then input motion name as a “deep_bow”.
  • Page 70 2) Click “New Scene” to add new scene. 3) Click “Get Pose”, you can see “Motor Enable” window, then check “Check All”.
  • Page 71 4) Then, you can make the RQ-HUNO posture by using your hand (Not by Jog Dial) as shown in the below. 5) Then, click “Capture” to complete the above scene.
  • Page 72 6) Click “New Scene” to add new scene. 7) Click “Get Pose”, you can see “Motor Enable” window, then check “Check All”.
  • Page 73 8) Then, you can make the RQ-HUNO posture by using your hand (Not by Jog Dial) as shown in the below. 9) Then, click “Capture” to complete the above scene. 10) Now, Copy the “Scene_1” to ready get up.
  • Page 74 11) Mouse right click, then paste-insert to the next empty scene space after Scene_2. 12) Copy the “Scene_0” to take a basic posture. 13) Mouse right click, then paste-insert to the next empty scene space after Scene_1...
  • Page 75 14) Now, click “Select All” and then click “Test”. 15) Click “Save” to save a “deep_bow.rbm” file. 16) “deep_bow.rbm” motion is downloaded successfully.
  • Page 76 17) Click “Close Port” to control RQ-HUNO by IR remote controller ’ 18) Press button 1 of IR remote controller, “deep_bow.rbm” motion is played. 19) Completed “Hi.rbm” motion movement is as follows.

  • Page 77: Actionbuilder

    7. ActionBuilder 7.1 Introduction ActionBuilder is the robot action programming software that uses various sensors of robot. Layout ① Menu Bar New File : Create new action file. Open : Load existed action file. Save : Save action file. Save As : Save action file with new name. Config : Revise action file information.
  • Page 78 ④ Action list Index : Display action line index. St. Name : Display statement name. Condition : Display condition data. Execution : Display execution data. Description : Display description of statement. ⑤ Action Information Statement Name : Display statement name and user can revise it. Description : Display description of statement.

  • Page 79: Action Programming #1 (Continuous Motions)

    7.2 Action Programming #1 (Continuous Motions) Robot Action : Basic Posture => Go => Back => Left => Right. 1) Click “New” to create new action file, then input “Action Name, File Name” and select “RQ-HUNO” platform as the below. 2) Connect RQ-HUNO with PC by using “Down Cable (UART)”...
  • Page 80 4) Click as the below procedures (1,2,3,4,5) by number to add robot basic posture motion.. 5) Click as the below procedures (1,2,3,4,5) by number to add robot “go” motion.
  • Page 81 6) Click as the below procedures (1,2,3,4,5) by number to add robot “back” motion. 7) For “Left” and “Right” motion, it is same procedures except “Motion Play” section. 8) Click below procedures (1,2,3) to save action file and download to RO smart controller.

  • Page 82: Action Programming #1 (Using Sound Sensor)

    9) Press “#” + “1” of IR remote controller, then robot moves “Basic Posture => Go forward=> Backwards => Move Left => Move Right) 7.3 Action Programming #1 (Using Sound Sensor) Robot Action : Ready => If applause detected, move forward...
  • Page 83 1) Click “New” to create new action file, then input “Action Name, File Name” and select “RQ-HUNO” platform as the below. 2) Click as the below procedures (1,2,3,4,5) to add “basic posture” motion.
  • Page 84 3) Click as the below procedures (1,2,3,4,5) to detect applause sound and add “go forward” motion. 4) Click as the below procedures (1,2,3,4,5) to be in “infinite loop” state.
  • Page 85 5) Click below procedures (1,2,3) to save action file and download to RO smart controller. 6) Press “#” + “2” of IR remote controller, then clap near RQ smart controller.

  • Page 86: Appendix

    8. Appendix 8.1 Auto power-saving mode If there is no input or movement during certain time, RQ-HUNO goes into power-saving mode automatically. You can set the entry time as below. 1) Power-off the smart controller. 2) Press button 3 and then, press button P concurrently. →...

  • Page 87: How To Change Smart Servo Id Number

    8.2 How to change Smart Servo ID Number 1) Connect single smart servo cable as shown in the below. 2) Make sure that Smart Controller power is “OFF” state.
  • Page 88 3) Press “Button P” as “Button 1” and “Button 3” are pressed together. You can see “LED 1” is BLUE light. LED2 and LED3 indicates current Smart Servo ID. Yo You can change Smart Servo ID by pressing “Button 1” or “Button 3”. - Button 1 is to increase Smart Servo ID number.

  • Page 89: How To Charge

    8.3 How to charge...
