References
Front face
B
White lacquered stainless steel
I
Brushed stainless steel
-
ATE-300
Pre-set units
Air velociy
m/s
fpm
Airflow
3
m /h
l/s
cfm
3
m /s
Temperature
°C
°F
Pressure
Pa
mmH O
2
mbar
Kpa
mmHg
inWg
PSI
Humidity
%RH
g/kg
(absolute hygro
(dew point Td)
°C
(dew point Td)
°F
(humid temp. Tw)
°C
°F (humid temp.
(Enthalpy i)
KJ/Kg
Technical Data Sheet
Presure • Temperature • Humidity • Air Velocity • Air Flow
Flush-mount multi-channel display
ATE 300
• Alternating display of 1 to 3 parameters
•
•
•
•
• Configuration via software or remote control
• Electroluminescent f
lacquered
ñ)
Tw
)
3 analogue inputs : 3 x 4-20mA or 3 x 0-10V
1 RS 232 digital input for KIMO external transmitter (
1 RS 485 digital input/output (Modbus protocol integrated)
22 pre-set units and 3 configurable units
ront display, made of brushed stainless steel or white
Display features
Display
....................................e
.................................................
1 line (measurement) ...........4 digits x 8 segments -
st
2 line (unit) ...........................4 digits x 14 segments -
nd
Comma position ....................configurable 0 / 0,0 / 0,00
Measurement value ...............from -9,99 to 99,99 and from -999 to 9999
Accuracy.................................±0,1 % of the measurement ±1 digit
Number of channels ..............from 1 to 3 channels, alternatively (3 seconds)
Location of channels.............with 3 LED: green, orange, red
Units available .......................22 pre-set units (see chart)
.................................................
Response time .......................< 1 sec.
Housing features
Front face...........................................316L wire brushed stainless steel
............................................................or white lacquered
Back housing ....................................flushmount, 304L stainless steel
Protection factor ...............................IP 65 in front face
Dimensions........................................see drawing
Weight ................................................600g
Technical specifications
Power supply....................................24 Vac / Vdc ±10%
Galvanic isolation ............................between input and power supply
Analogue inputs ...............................3 x 4-20 mA (4 wires) or 3 x 0-10 V
Consumption ....................................5 VA
Electro-magnetical compatibility
Electrical connection
.........................s
RS 485 communication....................digital: RTU Modbus protocol
...........................................................
...........................................................
RS 232 communication....................digital: ASCII, proprietary protocol
Working temperature .......................0 to +50°C
Storage temperature ........................-10 to +70°C
Environment .....................................air and neutral gases
* All accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranted for
measurements carried out in the same conditions, or carried out with calibration compensation.
class 200 & 300)
lectroluminescent alphanumeric (38 x 48mm)
protection screen made of PMMA
14 x 48 mm
14 x 48 mm
3 configurable units
EN 61 326
....
crew terminal block for ca
communication speed configurable
from 2400 to 115200 Bauds
bles Ø1.5 mm² max
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kimo ATE 300
Summary of Contents for Kimo ATE 300
-
Page 1: Display Features
• Alternating display of 1 to 3 parameters • 3 analogue inputs : 3 x 4-20mA or 3 x 0-10V • 1 RS 232 digital input for KIMO external transmitter ( class 200 & 300) • 1 RS 485 digital input/output (Modbus protocol integrated) •... - Page 2 Connection SUB-D15 connector Power supply Analogue inputs For 24 Vac power For 24 Vdc power Analogue input 1 Analogue input 2 supply models supply models Analogue input 3 1 2 3 1 2 3 4 5 6 7 8 9 10 11 12 Electrical connections - as per NFC15-100 norm This connection must be made by a qualified technician.
- Page 3 Analogue / Digital inputs Configuration ATE 300 displays 1 to 3 parameters that can be measured via the You can configure all parameters: units, analogue inputs, display following connections: channels … via the different methods shown below: • 3 analogue inputs: 3 x 4-20 mA or 3 x 0-10 V •...
-
Page 4: Optional Accessories
Mounting To install the display on a wall, make a cutting of 196 x 70 mm in the wall. Drill 4 holes around the cutting, as shown below. Insert the display into the wall and then, screw the 4 screws (supplied with the transmitter). Maintenance Avoid aggressive solvents.
