27...30 MHz CB & 10m Base Station Antenna
Base station antenna working on CB & 10m band . It is made of anti-corodal aluminium tubes and supplied
with a strong die cast base and a plastic arms bracket to reinforce the radials. Thanks the enclosed diagram its
easy to tune at the desired working frequency.
TECHNICAL DATA
Electrical Data
Type
Frequency range
Impedance
Radiation (H-plane)
Polarization
Bandwidth @ SWR 2
SWR @ res. freq.
Max Power
Connector
Mechanical Data
Materials
Wind resistance
Length (approx.)
Weigth (approx.)
Radial lenght (approx.)
Mounting Mast
Strong die-cast base, b
UHF-female connector
STARDUSTER M-400
STARDUSTER M-400
: 1/4
Ground Plane
: 26.5...30 MHz tunable by diagram
: 50
: 360° omnidirectional
: Vertical
:
2000 KHz @ 26.5 MHz
:
1.5
: 1000 Watts
: UHF-female
: Aluminium, Chromed Brass, Nylon
: 130 Km/h
: 5040 mm
: 1230 gr
: 2690 mm
:
35-40 mm
ottom view
HI-QUALITY ANTENNAS MADE IN ITALY
DESCRIPTION
DESCRIPTION
SPECIFICATIONS
SPECIFICATIONS
ID387
