Sony Ethernet Network Adapter User Manual

Sony network adapter user manual ethernet network adapter
Hide thumbs

Advertisement

Quick Links

SYSTEM REQUIREMENTS
PC running Windows XP, 2000, ME or 98 SE
ADSL connection, installed and ready for use
Game console:
RJ45 crossover Ethernet cable (included in the pack)
INSTALLATION AND SET UP
A.
Sharing your Internet connection (Windows XP and 2000)
B.
Setting up a PC to PC connection
C.
Setting up a PlayStation 2 connection to the Internet via the Central Station CD
D.
Setting up an Xbox connection to the Internet via the Xbox Live Starter Kit CD
A.
Sharing your Internet connection (Windows XP and 2000)
(Required to create a link between your modem and your game console or between 2 PCs)
WINDOWS XP
(for PS2 Online, Xbox Online or PC to PC connection)
1.
Connect the adapter to one of your computer's USB ports.
2.
Switch on your computer.
3.
Windows detects a USB to LAN Converter and installs it automatically.
A red LED on the Thrustmaster adapter lights up.
4.
Establish an Internet connection via your service provider (connect to the Web).
5.
Once a connection has been established, click Start/Settings/Control Panel.
6.
Double-click Network Connections.
All available network connections are displayed onscreen:
a.
b.
c.
A red X appears on the Local Area Connection icons.
7.
Right-click the icon for your service provider (e.g.: Wanadoo, AOL, etc.).
8.
Left-click Properties, then click Advanced.
9.
Select the Allow other network users to connect through this computer's Internet
connection check box (if a drop-down list appears below, select the Local Area
Connection entry that corresponds to your Thrustmaster USB to Ethernet Adapter). Click
OK twice.
Xbox
+ Microsoft Xbox Live Kit
or Xbox Live-enabled game with Xbox Live free trial
PlayStation 2
+ Sony Ethernet Network Adapter
+ Sony CENTRAL STATION Installation CD
+ 8MB Memory Card
An icon for your service provider (e.g.: Wanadoo, AOL, etc.).
Local Area Connection 1 icon (corresponds to your PC's Ethernet port, if
it has one, via the motherboard or PCI Ethernet card).
Local Area Connection 1, 2, or 3 icon (corresponds to your Thrustmaster
USB to Ethernet Adapter).
1/4

User Manual

Advertisement

loading

  Related Manuals for Sony Ethernet Network Adapter

  Summary of Contents for Sony Ethernet Network Adapter

  • Page 1: User Manual

    Xbox + Microsoft Xbox Live Kit or Xbox Live-enabled game with Xbox Live free trial PlayStation 2 + Sony Ethernet Network Adapter + Sony CENTRAL STATION Installation CD + 8MB Memory Card • RJ45 crossover Ethernet cable (included in the pack)
  • Page 2 A hand symbol appears beneath the icon for your service provider, indicating that your connection has been successfully shared. Close the dialog box. Your Internet connection is now shared. Restart your computer to complete the installation. WINDOWS 2000 (for PS2 Online, Xbox Online or PC to PC connection) Switch on your computer.
  • Page 3 Setting up a PlayStation 2 connection to the Internet via the Central Station CD Connect the Sony network adapter to the back of your console. Connect the Thrustmaster adapter to the back of your console (to the network adapter) using the RJ45 crossover Ethernet cable included in the pack.
  • Page 4: Technical Support

    Go into the game’s menu and select New Account. You arrive at the Welcome to XBOX LIVE menu. Select Continue, your Country, and Accept. Enter your Xbox Live ID, and select Done. Enter your 25-character subscription code (found inside the Starter Kit box or the game providing free access), then validate by clicking Continue (3 times).
  • Page 5: Manuel De L'utilisateur

    Jeu X-Box avec essai gratuit X-Box Live • PLAYSTATION 2 + Adaptateur Réseau (Ethernet Network Adapter) de Sony + CD d'installation CENTRAL STATION de Sony + 1 Memory Card 8Mb - 1 Câble de liaison Ethernet RJ45 croisé (fourni dans le pack) INSTALLATION ET CONFIGURATION A.
  • Page 6 WINDOWS 2000 (pour Connexion « PS2 Online », « X-Box Online » ou « PC à PC ») Allumez l’ordinateur Insérez le « Cd Driver » (fournit dans le pack) Connectez l’adaptateur au port USB de votre ordinateur (la diode rouge s’allume). Windows détecte un «...
  • Page 7 C. Configuration de la connexion PLAYSTATION 2 sur Internet via le « CD CENTRAL STATION » Connectez l’adaptateur réseau SONY à l’arrière de votre console. Reliez l’adaptateur Thrustmaster à l’arrière de votre console (sur l’adaptateur réseau) à l’aide du câble RJ45 croisé...
  • Page 8: Support Technique

    Entrez alors les différents éléments nécessaires à votre inscription : Mode de Paiement, Nom du titulaire de la carte, N° de Carte, Date d’Expiration et N° de téléphone. Validez le tout avec « Continuer ». Indiquez les autres informations nécessaires. VOUS ETES DESORMAIS CONNECTES SUR X-BOX LIVE…...
  • Page 9 Spielekonsole: Xbox + Microsoft Xbox Live Kit oder Xbox Live – ermöglicht das Spielen mit Xbox Live Free Trial PlayStation 2 + Sony Ethernet Network Adapter + Sony CENTRAL STATION Installation CD + 8 MB Memory Card • RJ45 - Ethernet Verbindungskabel (in der Verpackung enthalten)
  • Page 10 12. Starten Sie nun Ihren Computer neu, um die Installation abzuschließen. WINDOWS 2000 (für PS2-Online, Xbox-Online oder PC- zu PC-Verbindung) Schalten Sie Ihren Computer ein. Legen Sie die Treiber-CD (im Lieferumfang enthalten) in Ihr CD-ROM-Laufwerk. Stecken Sie nun den Adapter in einen freien USB-Anschluss Ihres Computers. Eine rote LED auf dem Thrustmaster-Adapter leuchtet auf.
  • Page 11 Ethernet-Adapter mit dem Ethernetanschluss Ihres zweiten PCs, falls dies noch nicht geschehen ist. Installation einer PlayStation 2-Internetverbindung mit der Central Station-CD Schließen Sie den Sony-Netzwerk-Adapter an Ihre Konsole an. Schließen Sie den Thrustmaster-Adapter an Ihre Konsole an (an den Netzwerk-Adapter) mit dem RJ45- Ethernet-Kabel, welches mitgeliefert wird.
  • Page 12: Technischer Support

    7. Geben Sie Ihre Xbox Live ID ein und wählen Fertig. 8. Geben Sie den 25-stelligen Abocode ein (ist in der Starter Kit Box oder das Spiel ist mit freiem Zugang), dann bestätigen durch Klick auf Weiter (dreimal). 9. Geben Sie die verschiedenen Elemente ein: Zahlungsmethode, Name des Karteninhabers, Kreditkartennummer, Verfallsdatum und Telefonnummer.
