• In no event will SONY be liable for any financial damage, or loss of profits, including claims made by third parties, arising out of the use of the software supplied with this player.
Table of Contents Overview ... 4 What you can do with your Network Walkman ... 4 Other features ... 5 Step 1: Checking the package contents ... 6 Step 2: Inserting the battery ... 7 Locating controls ... 8 Front side ... 8 Rear side ...
Overview What you can do with your Network Walkman First, you need to install the “SonicStage” software into your computer (MP3 file manager software is pre- installed in your Network Walkman). You can easily transfer digital audio files from your computer to the built-in flash memory and carry it anywhere to enjoy.
• The recorded music is limited to private use only. Use of the music beyond this limit requires permission of the copyright holders. • Sony is not responsible for incomplete recording/downloading or damaged data due to problems of the Network Walkman or computer.
Network Walkman. Record the serial number in the space provided below. Refer to it whenever you call upon your Sony dealer regarding this product. Earbuds (Size S) Serial No. _____________________ Earbuds (Size L)
Step 2: Inserting the battery Insert the LR03 (size AAA) alkaline battery with correct polarity. Be sure to insert it from the E side as illustrated. Battery duration * ATRAC3 format: Approximately 70 hours ATRAC3plus format: Approximately 60 hours MP3 format: Approximately 50 hours * The battery life may be shorter due to operating conditions and the temperature of the location.
Locating controls For details about each part, refer to the pages in parentheses. Front side 1 Strap hole for attaching the strap 2 REPEAT/SOUND button (page 15 to 16, 19) 3 MENU button (page 14, 17 to 20, 22 to 28) You can switch to the Time display by pressing the MENU button for a while.
Display 1 Text/graphic information display (page 14) Displays track number, track name, current date and time (page 17 to 23), MESSAGE (page 11, 33) and menu. Press the MENU button to switch the display mode. For details, refer to “Changing the display mode”...
Basic Operations Transferring audio files from the computer to your Network Walkman Note Before connecting your Network Walkman to the computer for the first time, be sure to install the “SonicStage” software from the supplied CD-ROM in your computer. Even if the SonicStage software is already installed, you need to install the SonicStage software supplied with this Network Walkman before connecting your Network Walkman to the computer (update programs may be available).
Transfer audio files to your Network Walkman. For information on transferring audio files to the built-in flash memory, refer to the separate manual “SonicStage operating instructions.” z Tip For information on transferring audio files back to the computer, refer to the manual “SonicStage operating instructions” or online Help for the SonicStage software.
Listening to music with your Network Walkman Please insert the battery before use (see page 7). Note When using Network Walkman, be sure do disconnect it from the computer. Connect the headphones. to i jack Start playback. 1 Press the Nx button. z Tip If your Network Walkman is not operated for 10 seconds while in stop mode, the display automatically turns off.
What is the Group function? The Group function enables you to select favorite music conveniently on your Network Walkman. You can transfer to audio files or play songs by album or artist using the Group function. Track1 Group1 Track2 Track3 Track1 Group2 Track2...
Advanced Operations Repeat mode There are three types of repeat mode: Track Repeat, A-B Repeat and Sentence Repeat. • Track Repeat (TRK Rep) This mode plays back tracks repeatedly in the following five ways. Track Repeat mode Operation All Repeat All tracks repeatedly Single Repeat Current track repeatedly...
Playing the tracks repeatedly (Track Repeat) The Track Repeat mode is changed by pressing the REPEAT/SOUND button. You can check the current Track Repeat mode with the icon of the display. Track Repeat icon Select the Track Repeat mode (TRK Rep) first (page 14).
Repeat mode (continued) z Tips • You can fast-forward or fast-rewind by rotating the Shuttle switch, after the start point (A) is set. If the track reaches the end while fast-forwarding, the end point is set as point (B) and fast-forwarding continues. A-B Repeat starts when you release the Shuttle switch.
Setting the repeat counts You can set the repeat counts (1-9) of one sentence for the Sentence Repeat mode. Shuttle switch Press (Confirm) to (+/>) to (./–) MENU button Press the MENU button. The menu screen is displayed. R E P E A T M O D E > Rotate the Shuttle switch to select “REPEAT MODE >”...
Changing the display mode (continued) Shuttle switch Press (Confirm) to (+/>) to (./–) Press the MENU button. The menu screen is displayed. R E P E A T M O D E > Rotate the Shuttle switch to select “DISPLAY >” and press the Nx button to confirm.
Adjusting treble and bass (Digital sound preset) You can adjust the treble and bass. You can preset two settings, which can be selected during playback. Selecting the Sound quality Default settings Sound SOUND 1 SOUND 2 SOUND OFF quality (S1) (S2) Bass Treble...
Adjusting treble and bass (Digital sound preset) (continued) Set the tone for “SOUND 1.” 1 Rotate the Shuttle switch to select “SOUND 1 >” and press the Nx button to confirm. 2 “BASS:+1” appears, rotate the Shuttle switch to adjust the emphasis level of bass sound and press the Nx button to confirm.
Storing non-audio data You can transfer data from the hard disk of your computer to the built-in flash memory using Windows Explorer. The built-in flash memory is displayed in Windows Explorer as an external drive (for example: as the D drive). Notes •...
Adjusting the settings of your Network Walkman Adjusting the time setting of your Network Walkman to a computer’s built-in clock If the function is set to “ON,” the time setting of your Network Walkman is automatically adjusted to the computer’s built-in clock when your Network Walkman is connected and audio file transferring is executed (the SonicStage software must be started).
Adjusting the current time setting (DATE- TIME) You can set and display the current time. You can also adjust the time setting of your Network Walkman to a computer’s built-in clock by connecting your Network Walkman to the computer (page 22). Shuttle switch Press (Confirm)
Limiting the volume (AVLS) You can set AVLS (Automatic Volume Limiter System) to limit the maximum volume to prevent auditory disturbance or distraction. With AVLS, you can listen to music at a comfortable volume level. Shuttle switch Press (Confirm) to (+/>) to (./–) Press the MENU button.
Rotate the Shuttle switch to select “SET >.” V O L : S E T > Press the Nx button to confirm. “VOL LO xx”* blinks. * “xx” stands for numeric values of the volume level. V O L L O x x Set volume levels of three preset levels: LO, MID, or HI.
Turning off the beep sound (BEEP) You can turn off the beep sounds of your Network Walkman. Shuttle switch Press (Confirm) to (+/>) to (./–) Press the MENU button. The menu screen is displayed. R E P E A T M O D E > Rotate the Shuttle switch to select “BEEP:”...
Other functions Regrouping songs (REGROUP) The songs group function may be disabled* when a song has been deleted from or added the built-in flash memory by operating the computer in which the SonicStage software is not installed (page 10). In such a case, you may enable the group function by regrouping audio file.
When you restore the MP3 file manager Nx button software, download it from the Sony customer service website. For details, refer to “MP3 file manager software operation” on page 37.
Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzene as it may mar the finish of the casing. If you have any questions or problems concerning your Network Walkman, please consult your nearest Sony dealer.
If you experience any of the following difficulties while using your Network Walkman, use this troubleshooting guide to help you to remedy the problem prior to consult a Sony dealer. Should any problem persist, consult your nearest Sony dealer. For trouble concerning operations while connected to your computer, please refer to “Troubleshooting”...
Page 31
On the display window Symptom The backlight is not turned on. “s” is displayed for a title. On the connection with the computer or supplied software Symptom The software cannot be installed. “CONNECT” is not displayed when connecting to the computer with the dedicated USB cable.
Page 32
Troubleshooting (continued) Symptom The number of audio files that can be transferred to is limited. (Available recording time is short.) The operation of the Network Walkman becomes unstable while it is connected to the computer. “Failed to authenticate Device/Media” is displayed on the computer screen while connecting the Network Walkman to the computer.
SonicStage or MP3 file manager software, but you cannot operate the controls on your Network Walkman. Please consult your nearest Sony dealer. • If the current time has not been set yet, set the current time in the menu mode (page 23).
Note is terminology denoting the copyright protection system developed by Sony. It does not guarantee conversion among other media. OpenMG Copyright protection technology that securely manages music content from the EMD/Audio CD on a personal computer.
Menu list Press the MENU button to display the menu mode and use the Shuttle switch (rotate: select/press: confirm) to change the settings of your Network Walkman. For details about each menu, refer to the pages in parentheses. The menu with a “>” mark will be followed by a detailed-setting screen when you press the Shuttle switch to confirm.
CD-ROM) first. If you use a computer that is not installed with the SonicStage software, you need to install the driver file for your Network Walkman from the Sony customer service website (http:// www.css.ap.sony.com/). System requirements • OS: Windows XP Professional...
Page 38
[MP3FileManager_1.1_Update_CHN.exe]). Installation starts. Follow the instructions of the installation wizard. (You can also download the MP3 File Manager software from the Sony customer service website [http://www.css.ap.sony.com/].) On language support The ability to display the languages on your MP3 File Manager will depend on the installed OS on your PC.
Display of MP3 file manager 1 Album list Double click this to show the included track list. Double click again to hide the track list. 2 Track list (Erase) Click this button to erase selected albums or tracks. (All erase) Click this button to erase all the albums or tracks.
Erasing audio file You can erase a song stored in the built-in flash memory by track or album using MP3 file manager. Open the MP3 file manager. Select the title you want to erase. Click the (Erase) button in the screen.
设定重复次数 您可以设定语音复读模式一句语句的重复次数 (1-9)。 往复开关 按(确认) 要 (+/>) 要 (./-) MENU 钮 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“REPEAT MODE >”,按 Nx 钮确认。 转动往复开关选择“SENTENCE Rep”,按 Nx 钮确认。 “COUNT:”显示在屏幕上。 C O U N T : 2 转动往复开关选择需要的重复次数, 按 Nx 钮确认。 按 MENU 钮。 显示屏返回正常屏幕。 取消菜单模式 选择菜单屏幕中的 [RETURN] 或按下 MENU...
更改显示模式(续) 往复开关 按(确认) 要 (+/>) 要 (./-) 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“DISPLAY >”, 并按 Nx 钮确认。 被选择的显示模式闪烁。 L a p T i m e 转动往复开关选择所需的显示模式, 并按 Nx 钮确认。 显示切换到选中的显示模式。 D I S P L A Y > 按 MENU 钮。...
调节 Network Walkman 设置 将 Network Walkman 时间设置调节至计算机 内置时钟 若此功能设置为“ON”,当 Network Walkman 连接到计算机并进行音频文件传送时(必须启 动 SonicStage 软件),Network Walkman 的 时间设置将自动调节为计算机的内置时钟。 “ON”为默认选择。 Network Walkman 不能在没有时间设置的状态 下播放有限定播放时间的歌曲。请确信时间设 置已调节。 要设置 Network Walkman 的日期和时间,请 参阅第 23 页上的“调节当前时间设置 (DATE-TIME)”。 往复开关 按(确认) 要 (+/>) 要 (./-) 将设置更改为 “OFF” 即使在 Network Walkman 与计算机处于连接 状态时,您的 Network Walkman 上的时间设 置也不会改变。 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“PC CLK:”,并 按 Nx 钮确认。 P C C L K : O N 转动往复开关选择“OFF”,并按...
调节当前时间设置 (DATE-TIME) 您可设置和显示当前时间。 您也可通过将 Network Walkman 与计算机连 接,将 Network Walkman 的时间设置调节为计 算机的内置时钟(第 22 页)。 往复开关 按(确认) 要 (+/>) 要 (./-) MENU 钮 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“DATE-TIME”, 并按 Nx 钮确认。 “年份”数字闪烁。 2 0 0 4 y 1 m 1 d 转动往复开关调节“年份”设置,并...
限制音量(AVLS) 您可通过设置 AVLS(自动音量限制系统)来限 制最大音量,以防止听觉干扰或分心。通过 AVLS,您可在舒适的音量电平上欣赏音乐。 往复开关 按(确认) 要 (+/>) 要 (./-) 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“AVLS”,按 Nx 钮确认。 “OFF”闪烁。 A V L S : O F F 转动往复开关选择“ON”,按 Nx 钮确认。 将显示 (AVLS)指示。 音量保持中等 电平。 按 MENU 钮。 将设置改变为“OFF”...
关闭操作音(BEEP) 您可关闭 Network Walkman 的操作音。 往复开关 按(确认) 要 (+/>) 要 (./-) 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“BEEP”,然后按 Nx 钮确认。 “ON”闪烁。 B E E P : O N 转动往复开关选择“O F F ”,然后按 Nx 钮确认。 B E E P : O F F 按 MENU 钮。...
格式化存储器 (FORMAT) 您可使用 Network Walkman 来格式化内置闪 存。 若对内存进行格式化,则先前储存在内存中的所 有数据将被删除。请确保在格式化之前核实内存 中储存的数据。 往复开关 按(确认) 要 (+/>) 要 (./-) 按 MENU 钮。 将显示菜单屏幕。 R E P E A T M O D E > 转动往复开关选择“F O R M A T ”,按 Nx 钮确认。 F O R M A T : N 您不能在播放音乐时将存储器格式化。...
